Fig. 161: Removing Exhaust Manifold-To-EGR Valve Tube 3. Disconnect the battery ground cable. For additional information, refer to BATTERY, MOUNTING AND CABLES - F150 PICKUP . 4. Raise the vehicle on a hoist. For additional information, refer to JACKING & HOISTING . 5. Disconnect the RH Heated Oxygen Sensor (HO2S) electrical connector. Fig. 162: Disconnecting RH Heated Oxygen Sensor Electrical Connector 6. Remove the nuts and disconnect the Y-pipe from the RH exhaust manifold.
2003 Ford Pickup F150 2003 ENGINE Engine - 4.2L - F150 Pickup
|
