Fiat Bravo (2015 year). Manual - part 6





ASHTRAY
STORAGE COMPARTMENTS
(for versions/markets, where provided)
These are located next to the cigar lighter fig. 60,
The ashtray is a removable spring-loaded plastic box
near the handbrake lever fig. 61, on the front and
fig. 58 that can be fitted into the cup/can holders
rear doors fig. 62 and fig. 63.
on the central tunnel.
IMPORTANT Do not use the ashtray as a waste
paper basket: it may catch fire in contact with
cigarette stubs.
GLASS HOLDER
The central tunnel has two cup and/or can holders
fig. 59.
fig. 59
F0Q0671
fig. 58
F0Q0630
fig. 60
F0Q0672
70
SUN VISORS
Passenger side
A courtesy mirror is fitted to the sun visor (on some
Driver's side
versions, the mirror is lit by a courtesy light).
A courtesy mirror may be fitted to the sun visor on
The driver and passenger sun visors can be moved
some versions.
back and forth and to the side fig. 64.
fig. 61
F0Q0673
fig. 63
F0Q0676
fig. 62
F0Q0674
fig. 64
F0Q0675
71
On some versions, a courtesy mirror with courtesy
SUN ROOF
light is fitted on the back of the visors. The light
(for versions/markets, where provided)
allows the mirror to be used even in poor visibility
The large electric sun roof comprises two panes of
conditions.
glass, one of which is mobile and the other fixed.
Lift cover A to access the mirror.
These are equipped with two
If the ignition key is at STOP position, the light stays
sun blinds (front and rear) that can be moved
on for about 15 minutes. If, during this period, a
manually.
door or the tailgate is opened, the 15 minute timing
The sun blinds be used in "fully closed" or "fully
is reset.
open" positions (they have no fixed intermediate
IMPORTANT On both sides of the sun visor there is
positions).
a label remembering that it is compulsory to
To open the sun blinds: grip handle A fig. 65, release
deactivate the airbags if a rearward facing child
it and move it in the direction of the arrows to
restraint system is fitted. Always comply with the
the "fully open" position.
instructions on the sun visor. (see the "Front airbags"
To close them, carry out the procedure in reverse.
paragraph in chapter "Safety").
The sun roof can be operated only with the ignition
key turned to MAR-ON. The controls A and B fig. 66
on the trim next to the front roof light operate the
sun roof opening/closing functions.
fig. 65
F0Q0737
72
Opening
If the button is operated again for about half a
second the roof will assume the spoiler position.
Press and hold down button B fig. 66. The front glass
Lastly, if the closing button is pressed again, the roof
panel will move into the spoiler position; press
will assume the fully closed position.
button B once again and hold down for more than
half a second to automatically move the sun roof to
an intermediate position (“Comfort” position).
Use the sun roof only at “spoiler” position
If the opening control is pressed again for more than
if a transverse roof rack is fitted.
half a second, the roof will automatically continue
until it reaches the end of travel position; the roof
glass can be stopped in an intermediate position
Do not open the sun roof if there is snow
by operating the button again.
or ice on it: you may damage it.
Closing
WARNING
With the roof in the fully open position, press
When leaving the vehicle, always remove
button A fig. 66 and, if the button is operated for
the key from the ignition switch to
more than half a second, the front roof glass with
avoid the risk of injury to those still inside the
automatically assume the intermediate position
car due to accidental operation of the sun roof.
(“Comfort” position).
Improper use of the roof can be dangerous.
Before and during operation, always check that
no one is exposed to the risk of being injured
by the moving sun roof or by objects getting
caught or hit by it.
fig. 66
F0Q0678
73
ANTI-PINCH SAFETY DEVICE
EMERGENCY MANOEUVRE
The sun roof has an anti-pinch safety system capable
If the switch does not work, the sun roof can be
of detecting the presence of an obstacle whilst the
operated manually as follows:
roof is closing: if this happens, the system intervenes
remove the protective cap A fig. 67 located on the
and the movement of the glass is immediately
rear of the inner trim;
reversed.
take the Allen key supplied located in the
container housing the documentation or in the
INITIALISATION PROCEDURE
luggage compartment (versions with automatic
After the battery has been disconnected or a fuse
Fix&Go);
has blown, the operation of the sun roof must be
introduce the Allen key into housing B and turn:
initialised again.
-
clockwise to open the roof;
Proceed as follows:
- anti-clockwise to close the roof.
press button A fig. 66 until the roof is completely
closed. Release the button;
press button A and keep it pressed for at least 10
seconds and/or until the glass panel clicks
forwards. Release the button at this point;
press button A within 5 seconds of this operation
and keep it pressed: the glass panel will complete a
full opening and closing cycle. Only release the
button at the end of this cycle.
fig. 67
F0Q0738
74
DOORS
CHILD LOCK DEVICE
This prevents the rear doors from being opened
CENTRAL LOCKING
from the inside.
Device fig. 69 can only be engaged with the doors
From outside
open:
With the doors closed, insert and turn the key in
position 1 - device engaged (door locked);
one of the front door locks.
position 2 - device not engaged (door may be
opened from the inside).
From inside
The device remains on even if the doors are
Press the door lock/release button fig. 68 located in
unlocked electrically.
the dashboard, from inside the car (with the doors
shut).
If the electrical system has failed, it is still possible to
Always use this device when carrying
lock the doors manually.
children.
IMPORTANT The rear doors cannot be opened
from the inside when the child lock device is
engaged.
fig. 68
F0Q0641
fig. 69
F0Q0677
75
The door lock knob can be realigned (only when the
WARNING
battery charge has been restored) as follows:
After engaging the child lock on both
press the button on the key;
rear doors, check for proper engagement
press the button on the dashboard to
by trying to open a rear door with the internal
lock/unlock the doors;
handle.
open a front door by inserting the key into the
door catch;
REAR DOOR EMERGENCY LOCKING
operate the internal door handle.
DEVICE
IMPORTANT If the child lock device was engaged
The rear doors are fitted with an emergency device
and the previously described locking procedure
that allows the doors to be locked when there is
carried out, operating the internal handle will not
no current.
open the door but will only realign the door lock
Proceed as follows:
knobs. To open the door, the outside handle must be
insert the metal insert of the ignition key into
used. The door central locking/unlocking button
housing A fig. 70;
is not disabled by the engagement of the
emergency lock.
turn the key clockwise and then remove it from
housing A.
IMPORTANT If the battery is disconnected or the
protection fuse blows, the door opening/closing
mechanism must be initialised as follows:
close all the doors;
press button on the key or button for
locking/unlocking the doors on the dashboard;
press button on the key or button for
locking/unlocking the doors on the dashboard.
fig. 70
F0Q0679
76
ELECTRIC WINDOWS
WARNING
Do not activate the child lock device if
They are fitted with a security system that can detect
the rear doors emergency lock device
the presence of an obstacle whilst the window is
is already activated. If both have been
closing; when this happens, the system kicks in and
activated, you need to use the interior handle to
the movement of the glass is immediately reversed.
disengage the rear doors emergency locking
system and then open the door from the
IMPORTANT In the event that the anti-crushing
outside.
function is activated 5 times in only 1 minute, the
system will automatically enter the “recovery” mode
(self-protection). This condition is apparent from
the window closing in stages.
If this occurs, restore the system as follows:
open the windows;
or
turn the ignition key to the STOP position and
then to MAR-ON.
If no malfunction is present, the window returns to
its normal operation automatically.
IMPORTANT With the ignition key at STOP or
removed, the electric windows remain activated for
about two minutes and are deactivated as soon as
a door is opened.
WARNING
The system conforms to the 2000/4/EC
standard concerning the safety of
passengers leaning out of the passenger
compartment.
77
IMPORTANT On some versions, when the button
C enabling/disabling of rear door electric window
on the key with remote control is pressed for longer
controls;
than 2 seconds the windows will open, whilst if the
D opening/closing rear left window (for versions/
button is pressed for longer than 2 seconds the
markets, where provided); “continuous automatic”
windows will close.
operation during window opening/closing stage;
E opening/closing rear right window (for versions/
CONTROLS
markets, where provided); “continuous automatic”
operation during window opening/closing stage.
Driver side front door fig. 71
Buttons have been provided on the driver's door
Window opening
panel to control the following functions with the
Push the buttons to open/close the desired window.
ignition key turned to MAR-ON:
When one of the two buttons is pressed briefly,
A opening/closing front left window; “continuous
the window moves in "stages"; if the button is held
automatic” operation during window opening/
down, "continuous automatic" operation is activated.
closing stage;
If the button is pressed again the window will stop
B opening/closing front right window; “continuous
in its current position.
automatic” operation during window opening/
closing stage;
Window closing
Lift the buttons to close the desired window.
The window closing stage occurs following the same
logics described for the opening stage.
fig. 71
F0Q0622
78
ELECTRIC WINDOWS SYSTEM
WARNING
INITIALISATION
Improper use of the electric windows
The system must be re-initialised after disconnecting
can be dangerous. Before and during
the battery or if the relevant protection fuse is
their operation ensure that any passengers are
blown.
not at risk from the moving glass either by
personal objects getting caught in the
Proceed as follows to start the electric window
mechanism or by being hit by it directly.When
initialisation:
leaving the car, always remove the ignition
fully close the window to be initialised manually;
key to prevent the electric windows from being
after the window has reached the upper end
inadvertently activated, as this could present
of travel, hold the up button pressed for at least
a danger for the passengers remaining in the
one second.
vehicle.
MANUAL REAR WINDOW MECHANISM
(for versions/markets, where provided)
Passenger side front door/rear doors
To open and to close the window, use the relevant
On the passenger side front door panel, and on
handle.
some versions also on the rear doors, buttons
A fig. 72 are provided to control the associated
windows.
fig. 72
F0Q0743
79
LUGGAGE COMPARTMENT
The light will stay on for about 15 minutes after
turning the key to STOP: if during this time, a door
or the tailgate is opened, the light will switch on
OPENING
again for 15 minutes.
When unlocked, the luggage compartment can be
opened from the outside the car by pressing the
Opening the tailgate using the key with
electric logo fig. 73.
remote control
The tailgate can be opened at any time, if the doors
Press button
even with alarm (for versions/
are unlocked.
markets where provided) on.
The key with remote control should be used to open
Luggage compartment opening is indicated by the
the tailgate.
double flashing of the direction indicators; tailgate
If the tailgate is not closed properly, the warning light
closing is indicated by single flashing (only with
or the symbol
switch on in the instrument
the alarm switched on).
panel (together with the dedicated message on the
If the tailgate is opened when the alarm is on, the
display) (see “Warning lights and messages” chapter).
system will:
Opening the tailgate will switch the luggage
switch off the volume sensing protection;
compartment light on: the light will go off
automatically when closing the tailgate.
switch off the anti-lift protection;
switch off the tailgate control sensor.
When the tailgate is closed again, all the functions
are restored.
CLOSING
Lower the tailgate, pressing near the lock until you
hear it click into place.
fig. 73
F0Q0680
80
WARNING
Do not fit additional objects onto the rear
parcel shelf or tailgate (speakers,
When travelling, do not put any object
spoilers, etc.), except when contemplated
on the rear parcel shelf because they
by the manufacturer, to ensure the correct
can injure passengers in the event of an
operation of the side gas shock absorbers of the
accident or sudden braking.
tailgate itself.
EXTENDING THE LUGGAGE
WARNING
COMPARTMENT
Never exceed the maximum allowed
The luggage compartment can be partially (1/3 or
load in the luggage compartment (see
the "Technical data" chapter). Also make sure
2/3) or totally extended by splitting the rear seat.
that the objects you placed in the luggage
compartment have been properly secured, to
avoid them from being projected forward
following sudden braking, causing injury to
passengers.
81
Partial extension (1/3 or 2/3) Fig. fig. 74-fig. 75
Proceed as follows:
completely lower the rear seat head restraints;
Extending the luggage compartment on the right
side makes it possible to carry two passengers
move the seat belt to the side, making sure that it
on the left part of the rear seat. Extending the left
is fully extended and not twisted;
side of the luggage compartment allows you to carry
fold the desired cushion forwards fig. 76 working
one passenger on the right part of the rear seat.
in the point shown by the arrow;
lift lever A fig. 77 retaining the backrest and fold
the latter forwards. When you lift the lever, you
will see a red band B.
Full extension
Tilting the rear seat completely forwards allows
maximum loading volume.
Proceed as follows:
completely lower the rear seat head restraints;
move the seat belts to the side, making sure that
they are correctly extended and not twisted;
fig. 74
F0Q0681
fig. 75
F0Q0682
fig. 76
F0Q0684
82
fold the cushions forwards as described above;
The red band B indicates that the backrest is not
secured. Return the cushions to the horizontal
remove the rear parcel shelf fig. 78 and release the
position holding the central seat fastening tongue
upper ends of links A fig. 79 by removing the
raised.
eyelets from the pins and pushing them in the
direction indicated by the arrow;
when the cushion is folded down, tilt the rear seat
backrests completely forwards as described above
so as to obtain a continuous loading surface.
REPOSITIONING THE REAR SEAT
Move the seat belts to the side, making sure that
they are correctly extended and not twisted.
Lift the backrests and push them back until you hear
both fastening mechanisms click in. Check that the
red band B fig. 80 on the side of levers A is no longer
visible.
fig. 78
F0Q0686
fig. 77
F0Q0683
fig. 79
F0Q0687
83















Content      ..     4      5      6      7     ..
