ALARM
IMPORTANT The engine stop function is guaranteed
(for versions/markets, where provided)
by the Fiat CODE which is automatically activated
when the key is extracted from the ignition switch.
The alarm, in addition to all the remote control
functions described previously, is controlled by the
TURNING THE ALARM ON
receiver located under the dashboard near the
fuse box.
With the doors, bonnet and tailgate closed and the
ignition key either turned to STOP or removed,
ALARM ACTIVATION
point the key with remote control towards the
vehicle and press and release button
The alarm intervenes in the following instances:
Excluding some markets, the system produces an
when a door, the bonnet or the tailgate is opened
acoustic signal (beep) and enables door locking.
illegally (perimeter protection);
The switching on of the alarm is preceded by a
when the ignition system is started up (ignition key
self-diagnosis stage: if a fault is detected, the system
turned to MAR-ON);
emits a new acoustic signal together with the display
cutting of the battery leads;
of a message (see “Warning lights and messages”
chapter).
movement inside the passenger compartment
(volume sensing protection);
In this case switch off the alarm by pressing
, check
that all the doors, bonnet and tailgate are closed
anomalous lifting/tilting of the vehicle.
correctly; then switch the alarm back on by pressing
Depending on the market, the activation of the alarm
the button.
causes the activation of the siren and the direction
If a door, the bonnet and the tailgate are not
indicators (for about 26 seconds). Alarm tripping and
properly shut, they will be excluded from the check
the number of cycles depend on the sales market.
by the alarm system.
There is a maximum number of acoustic/visual cycles.
If the alarm emits an acoustic signal even when the
When this is reached the system returns to normal
doors, bonnet and tailgate are correctly closed, a
operation.
failure has occurred in system operation. Go to a Fiat
The volume sensing and anti-lift protection can be
Dealership.
excluded by adjusting the dedicated control on
the front roof light (see “Volume sensing/Anti-lift
IMPORTANT The alarm does not come on when the
protection”).
central locking is activated using the metal insert in
the key.
14
IMPORTANT The alarm is adapted to meet
BREAK-IN ATTEMPT INDICATION
requirements in various countries.
Any break-in attempt is indicated by the warning light
(or symbol in the display) lighting up, together
TURNING THE ALARM OFF
with a message shown in the display (see “Warning
Press button on the key with remote control.
lights and messages” chapter).
The following operations are performed (excluding
DISABLING THE ALARM
some versions for specific markets):
direction indicators flash twice;
To turn the alarm off completely (for example, if the
vehicle is not being used for a long time), the vehicle
there are two short acoustic signals (beeps);
must be closed by turning the metal insert of the
doors are unlocked.
key with remote control in the lock.
IMPORTANT The alarm does not switch off when
IMPORTANT If the batteries of the key with remote
the central opening is activated using the metal insert
control run out or the system fails, the alarm can
in the key.
be switched off by placing the key in the ignition
switch and turning it to MAR-ON.
VOLUME SENSING/ANTI-LIFT
PROTECTION
To guarantee the correct operation of the protection
system it is advisable to shut all the side windows
and the sun roof (for versions/markets, where
provided).
If necessary, the function can be turned off (if, for
example, you are leaving an animal in the car) by
pressing button A fig. 12, located in the front roof
light, before activating the alarm itself.
When the function is disabled, this is indicated by the
LED on the button flashing for several seconds. Any
disabling of the volume sensing/anti-lift protection
must be repeated each time the instrument panel is
switched off.
fig.
12
F0Q0752
15
IGNITION SWITCH
STEERING LOCK
The key can be turned to 3 different positionsfig. 13:
Engagement
STOP: engine off, key can be removed, steering
When at STOP, remove the key and turn the steering
column locked. Some electrical devices (e.g. radio,
wheel until it locks.
central door locking system, electronic alarm,
etc.) are enabled.
Disengagement
MAR-ON: driving position. All electrical devices
Move the steering wheel slightly as you turn the
are enabled.
ignition key to MAR-ON.
AVV: engine start-up.
IMPORTANT In some parking conditions (e.g.:
The ignition switch is fitted with a safety system that
wheels turned) the effort required to move the
requires the ignition key to be turned back to STOP
steering wheel and disengage the steering lock may
if the engine does not start, before the starting
be increased.
operation can be repeated.
WARNING
If the ignition switch is tampered with
(e.g. attempted theft), have it checked
over by a Fiat Dealership before driving again.
WARNING
Always remove the key when you leave
your car to prevent someone from
accidentally operating the controls. Remember
to engage the handbrake. If the car is parked on
uphill slope, engage the first gear; if the car is
facing downhill, engage the reverse gear. Never
leave children unattended in the car.
fig. 13
F0Q0642
16
DISPLAY
WARNING
It is absolutely forbidden to carry out
The car is equipped with a multifunction display that,
any aftermarket operation involving
according to the previously applied settings, will
steering system or steering column
show useful driving information.
modifications (e.g.: installation of anti-theft
When one of the front doors is opened, the display
device) that could badly affect performance and
is activated, showing the time and mileage for a
safety, invalidate the warranty and also result
few seconds.
in non-compliance of the car with type-
approval requirements.
Note With a low outside temperature (below 0°C)
it may take longer than normal for information to
appear on the display.
WARNING
Never remove the key while the car is
moving.The steering wheel will lock
as soon as it is turned.This holds true for cars
being towed as well.
17
MULTIFUNCTION DISPLAY “STANDARD”
CONTROL BUTTONS
SCREEN
fig. 15: to scroll through the screen and the
options upwards or to increase the value
The standard screen fig. 14 can display the following
displayed.
information:
MODE: press briefly to access the menu and/or go
A Date
to next screen or confirm the desired
B Possible Dualdrive electric power steering
selection. Hold down to go back to the
engagement
standard screen.
C Sport driving mode indication (for versions/
: to scroll through the screen and the options
markets, where provided)
downwards or to decrease the value displayed.
D Time
IMPORTANT The and buttons activate different
E Milometer (display of distance travelled in
functions according to the following situations:
kilometres/miles)
F Possible ice on the road indication
within the menu, they allow you to scroll up and
down through the options;
G Outside temperature
during settings operations, they increase or
H Scheduled servicing interval
decrease values.
I Headlight alignment position (only with dipped
headlights on)
fig. 14
F0Q3245
fig. 15
F0Q0643
18
IMPORTANT When one of the front doors is
SEE RADIO
opened, the display is activated, showing the time
AUTOCLOSE
and mileage for a few seconds.
UNITS OF MEASUREMENT
SETUP MENU
LANGUAGE
The menu comprises a series of functions which can
WARNINGS VOLUME
be selected using the and buttons to access
BUTTON VOLUME
the different selection and setting (setup) operations
SEAT BELT BEEP/BUZZ.
indicated below.
SERVICE
Some options have a submenu.
AIRBAG/PASSENGER BAG
The Setup Menu can be activated by pressing the
MODE button briefly.
CORNERING LIGHTS (for versions/markets,
where provided)
If the Radionavigator is installed, only the following
functions can be adjusted/set from the instrument
EXIT MENU
panel: "Lighting", “Speed beep”, "Headlight sensor"
(for versions/markets, where provided), "Belt buzzer"
Selecting an option from the main menu
and "Passenger airbag". The other functions are
without a submenu:
shown on the Radionavigator display. You can set and
briefly press the MODE button to select the main
adjust them there.
menu option that needs to be changed;
The menu comprises the following options:
press buttons or
(with single presses) to
LIGHTING
select the new setting;
SPEED BEEP
briefly press the MODE button to store the new
setting and at the same time go back to the
HEADLIGHT SENSOR (for versions/markets,
previously selected menu option.
where provided)
TRIP B ACTIVATION/DATA
SET TIME
SET DATE
FIRST PAGE (for versions/markets, where
provided)
19
Selecting an option from the main menu with
MENU ITEMS
a submenu:
Lighting (Interior light adjustment)
briefly press the MODE button to display the first
submenu option;
With the side lights on, this function is used to set
press buttons or
(with single presses) to
the brightness of the instrument panel, radio
scroll through all the submenu options;
controls and dual zone automatic climate control
system controls (for versions/markets where
briefly press the MODE button to select the
provided) to 8 levels.
displayed submenu option and to open the
relevant settings menu;
Proceed as follows to adjust the brightness:
press buttons or
(with single presses) to
briefly press the MODE button: the previously set
select the new setting for this submenu option;
level flashes on the display;
briefly press the MODE button to store the new
press button or to set the required brightness
setting and at the same time go back to the
level;
previously selected submenu option.
briefly press the MODE button to return to the
menu screen or hold the button down to return
to the standard screen without storing.
Speed Beep (Speed limit)
This function is used to set the car speed limit (km/h
or mph); the driver is immediately alerted when
this limit is exceeded (see section “Warning lights
and messages”).
To set the desired speed limit, proceed as follows:
press the MODE button briefly, the display shows
the dedicated message;
press the or button to select speed limit
activation (On) or deactivation (Off );
if the function has been activated (On), press the
or buttons to select the desired speed limit
and then press MODE to confirm.
20
IMPORTANT Setting is possible between 30 and 200
the lights on (e.g. with a setting on level 3 at sunset
km/h, or 20 and 125 mph, according to the
the headlights come on in advance in relation to
previously set unit. See the "Units of measurement
levels 1 and 2).
adjustment (Units of measurement)" paragraph
Proceed as follows to set the desired adjustment:
described below. The setting will increase/decrease
briefly press the MODE button: the previously set
by 5 units each time button
/
is pressed. Hold
level flashes on the display;
down the
/
button to automatically increase/
decrease the setting rapidly. Complete the
press or to make your choice;
adjustment with single presses of the button when
press the MODE button briefly to return to the
you approach the desired value.
menu screen or hold the button down to return
Briefly press the MODE button to return to the
to the standard screen without storing.
menu screen or hold the button down to return to
the standard screen without storing.
Cornering lights (Activation/deactivation of
“Cornering lights”)
To cancel the setting, proceed as follows:
(fog light with cornering function)
briefly press button MODE, (On) will flash on the
(for versions/markets where provided)
display;
This function activates/deactivates the cornering
press button
, (Off ) will flash on the display;
lights.
press the MODE button briefly to return to the
To activate/deactivate (On/Off ) the lights, proceed as
menu screen or hold the button down to return
follows:
to the standard screen without storing.
press the MODE button briefly, the display will
show “On” or “Off” flashing depending on the
Headlight sensor (Automatic headlight/dusk
previous setting;
sensor sensitivity adjustment)
(for versions/markets, where provided)
press or to make your choice;
This function is used to turn the headlights on or off
briefly press the MODE button to return to the
according to external lighting conditions.
menu screen or hold the button down to return
to the standard screen without storing.
The headlight sensor sensitivity can be adjusted
according to 3 levels (level 1 = minimum sensitivity,
level 2 = average sensitivity, level 3 = maximum
sensitivity). The higher the sensitivity set, the lesser
is the external light variation needed to switch
21
Activation/Trip B data (Activating Trip B)
briefly press the MODE button: “minutes” starts
flashing on the display;
This function can be used to activate (On) or
press the button or for setting.
deactivate (Off ) the Trip B display (partial trip). For
further information see “Trip computer” in this
IMPORTANT The setting will increase or decrease
section.
by one unit each time the button or is pressed.
Proceed as follows to switch the function on/off:
Hold down the button to increase/decrease the
briefly press the MODE button: On or Off flashes
setting rapidly and automatically. Complete the
on the display (according to the previous setting);
adjustment with single presses of the button when
you approach the desired value.
press or to make your choice;
If you enter the "Format" submenu, pressing the
briefly press the MODE button to return to the
MODE button briefly makes the display format flash
menu screen or hold the button down to return
on the display;
to the standard screen without storing.
Press button or to select “24h” or “12h”.
Time adjustment (Clock adjustment)
when you have made the adjustment, briefly press
the MODE button to go back to the submenu
This function enables to set the clock through two
screen or hold the button down to go back to the
submenus: “Time” and “Format”.
main menu screen without storing.
To carry out the adjustment, proceed as follows:
hold down the MODE button again to return to
briefly press the MODE button and two
the standard screen or to the main menu
submenus, "Time" and "Format", are displayed;
according to where you are in the menu.
press the or button to switch between the
When you have made the adjustment, briefly press
two submenus;
the MODE button to go back to the submenu screen
once you have selected the submenu to be
or hold the button down to go back to the main
changed, press the MODE button briefly;
menu screen without storing.
when you select “Time”, briefly pressing the
MODE button makes the hours flash on the
display;
press the or button to make the adjustment;
22
Set date (Setting the date)
First page (display of information on the main
screen)
Using this function it is possible to update the date
(for versions/markets, where provided)
(day - month - year).
This function allows you to choose the information
Proceed as follows to start the update:
you would like to display on the main screen.
briefly press the SET button: the “year” will flash
You can choose to display the date or the
on the display;
turbocharger boost pressure.
press the or button to make the adjustment;
To make your choice, proceed as follows:
briefly press the SET button: the “month” will flash
briefly press the MODE button: "First page" will
on the display;
appear on the display;
press the or button to make the adjustment;
briefly press the MODE button again to display the
briefly press the SET button: the “day” will flash on
"Date" and "Engine info" options;
the display;
press or to select the information you wish to
press the button or for setting.
see on the main page of the display;
IMPORTANT The setting will increase or decrease
press the MODE button briefly to return to the
by one unit each time the button or is pressed.
menu screen or hold the button down to return
Hold down the button to increase/decrease the
to the standard screen without storing.
setting rapidly and automatically. Complete the
When the key is turned to MAR-ON and the initial
adjustment with single presses of the button when
check stage is over, the display will show the
you approach the desired value.
information set previously via the “First page” menu
Briefly press the MODE button to return to the
function.
menu screen or hold the button down to return to
the standard screen without storing.
23
See radio (Audio information display)
briefly press the MODE button: "On" or "Off"
flashes on the display according to the previous
With this function the display shows information
setting;
about the sound system.
press or to make your choice;
Radio: selected radio station frequency or RDS
message, automatic tuning activation or
press the MODE button briefly to return to the
AutoSTore;
submenu screen or hold the button down to
return to the main menu screen without storing;
Audio CD, MP3 CDs: track number;
hold down the MODE button again to return to
CD Changer: CD number and track number;
the standard screen or to the main menu
To show the radio information on the display (On)
according to where you are in the menu.
or clear it (Off ), proceed as follows:
briefly press the MODE button, the display will
Unit of measurement (Setting the unit of
show "On" or "Off" flashing depending on the
measurement)
previous setting;
With this function it is possible to set the units
press or to make your choice;
through three submenus: "Distances",
"Consumption" and "Temperature". To set the
briefly press the MODE button to return to the
desired unit, proceed as follows:
menu screen or hold the button down to return
to the standard screen without storing.
briefly press the MODE button to display the
three submenus;
Autoclose (Automatic central locking with
press button or to navigate through the three
the car in motion)
submenus;
When activated (On), this function locks the doors
once you have selected the submenu to be
automatically when the vehicle speed exceeds 20
changed, press the MODE button briefly;
km/h.
when you select the “Distances” submenu, briefly
Proceed as follows to activate or deactivate this
pressing the MODE button makes the display
function:
show “km” or “mi” depending on the previous
setting;
briefly press the MODE button to display a
submenu;
24
press or to make your choice;
Language (Language selection)
when you select the “Consumption” submenu,
Display messages can be shown in different
pressing the MODE button makes "km/l", "l/100
languages: Italian, German, English, Spanish, French,
km" or "mpg" appear on the display depending on
Portuguese and Dutch.
the previous setting;
To set the desired language, proceed as follows:
If the set distance unit is "km", the fuel consumption
briefly press the MODE button: the previously set
unit will be displayed in km/l or l/100 km.
language starts flashing on the display;
If the set distance unit is “mi” the fuel consumption
press or to make your choice;
unit will be displayed in “mpg”.
briefly press the MODE button to return to the
press or to make your choice;
menu screen or hold the button down to return
when you enter the “Temperature” submenu,
to the standard screen without storing.
briefly pressing the MODE button makes "°C" or
"°F" appear on the display depending on the
Warnings volume (Adjusting the failure/
previous setting;
warning acoustic signal volume)
press or to make your choice;
With this function the volume of the buzzer which
When you have made the adjustment, briefly press
accompanies the display of any failure/warning can be
the MODE button to go back to the submenu screen
adjusted to 8 levels.
or hold the button down to go back to the main
To set the desired volume, proceed as follows:
menu screen without storing.
press the MODE button briefly, making the display
Hold down the MODE button again to return to the
flash the previously set volume "level";
standard screen or to the main menu according to
press the or button to make the adjustment;
where you are in the menu.
briefly press the MODE button to return to the
menu screen or hold the button down to return
to the standard screen without storing.
25
Button volume (adjusting the button volume)
To consult this information, proceed as follows:
This function allows the volume of the acoustic
briefly press the MODE button: the display shows
signal that accompanies MODE, and button
when servicing is due in km/mi or days (where
presses to 8 levels
provided) or mi or days (where provided)
according to the previous setting (see paragraph
To set the desired volume, proceed as follows:
"Units of measurement");
press the MODE button briefly, making the display
briefly press the MODE button to go back to the
flash the previously set volume "level";
menu screen or hold the button down to go back
press the or button to make the adjustment;
to the standard screen.
press the MODE button briefly to return to the
menu screen or hold the button down to return
Note The “Scheduled Servicing Plan” includes car
to the standard screen without storing.
maintenance at fixed intervals (refer to the
"Maintenance and care" chapter). This is displayed
automatically, with ignition key at MAR-ON, 2000
Seat belt buzzer (Buzzer activation for SBR
km (or equivalent value in miles) before servicing or,
indication)
where provided, 30 days before servicing. It is also
This function can be displayed only after a Fiat
displayed each time the key is turned to MAR-ON or,
Dealership has deactivated the SBR system (see the
for versions/markets, where provided, every 200 km
“Safety” section in the “SBR system” paragraph).
(or equivalent value in miles). Below this threshold
To reactivate this function, proceed as follows:
servicing indications are more frequent. The display
will be in km or miles according to the unit of
briefly press the MODE button, the display shows
measurement set. When the following scheduled
"Off" flashing. Press the or button and "On"
servicing is approaching, the word “Service” will
will appear;
appear on the display, followed by the number of
briefly press the MODE button to return to the
kilometres/miles or days (where provided) left, when
submenu screen or hold the button down to
the key is turned to MAR-ON. Go to a Fiat
return to the main menu screen without storing.
Dealership, where the "Scheduled Servicing Plan"
operations will be performed and the message will
Service (Scheduled servicing)
be reset.
This function allows you to display the information
When the service interval is reached and for about
about km/mileage intervals or, for versions/markets,
1000 km/600 mi or 30 days, a service due message is
where provided, time intervals for car servicing.
displayed.
26
Airbag/Passenger bag
Exit menu
This function is used to activate/deactivate the
The last function closing the cycle of settings listed in
passenger side airbag.
the menu screen.
Proceed as follows:
Press the MODE button briefly to return to the
standard screen without storing.
press the MODE button and, after the message
"Bag pass: Off" (to deactivate) or "Bag pass: On"
Press the button to go back to the first menu
(to activate) is displayed by pressing the and
option ("Speed Beep").
buttons, press the MODE button again;
a confirmation request message will appear on the
display;
by pressing the or buttons, select ("Yes") (to
confirm activation/deactivation) or ("No") (to
cancel);
press the MODE button briefly and a message
confirming the selection will be displayed, then you
will return to the menu screen, or hold the
button down to return to the standard screen
without storing.
27















Content      ..      1      2      3      ..
