Transmission MT-26 10.Install the synchronizer backing block, spring seat, spring and lockpin in sequence; 11.Install the synchronizer lockpin assembly into the slot of the fixed gear seat; Note: accord to the turning direction of the fixed gear seat. 12.Install the 5th and 6th speed gear slide sleeve; Note: the lockpin assembly is not allowed. 13.Install the 5th and 6th speed gear synchronizer; 14.Install the spacer sleeve and lock shim, then tighten the locking nut with a special spanner; Tightening torque: 300N.m |
