Maintenance Schedule
10—8
Fuel
The qualified light diesel oil specified by GB252-87 could be applied
for, and the users choose different qualified light diesel oil according to
the local temperature.
Temperature range of the recommended light diesel oil:
Type
Temperature
0# Light diesel oil
Local temperature above 4 ℃
10# Light diesel oil
Local temperature above -5 ℃
20# Light diesel oil
Local temperature between -5 ℃ ~ -14 ℃
35# Light diesel oil
Local temperature between -14 ℃ ~ -29 ℃
50# Light diesel oil
Local temperature between -29 ℃ ~ -44 ℃
Grease Application Place and Schedule
Greasing should be performed periodically for all parts of the
vehicle.
Before filling up, clean all dust and dirty from the grease nipples and
other parts which are needed to lubricated, then apply grease.
After greasing, wipe off the excess grease. Be sure to put the caps
back on.
Free play of brake pedal
35~40mm
Front/rear brake air chamber push rod travel
25~40mm
Final reduction planetary gear side clearance
0.20~0.30mm
Differential gear clearance
≤
0.8mm
Front/back adjusting distance of steering wheel
35mm
Upper/down adjusting distance of steering wheel
±
15mm
Battery electrolyte gravity
1.26~1.265
Chassis
Adjusting Items
Standard
