Dongfeng DFA1101GZ5AD6J-907. Manual - part 4





Construction and Operation

 3—1

Construction and Operation

Arrangement of the Cab

1. Hazard waring lamp switch
2. In strument panel
3. Front fog lamp switch
4. Wind channel
5. Radio cassette
6. Heater and air-conditioner switch
7. Glove box
8. Windshield washer fluid reservoir

9. Fuse box
10. Cigarette lighter
11. Ashtray
12. Windshield wiper and washer

controlling rod

13. Ignition lock
14. Combined light switch
15. Combination switch

Construction and Operation

3—2



Doors

 Opening doors

From the outside

From the inside

Note:
After closing the door,please double check

whether the door is really closed.  Driving  with
the door half closed can be very dangerous.

 Closing doors

From the outside
Turn the key forward to lock the

door, while turn it backward to unlock
the door.

From the inside
Set  the  lock  ball  to  the  locked

place, and pull the door handle to close
the door.

Construction and Operation

 3—3

Seats

 Driver's seat forward and back-

ward adjustment

Raise the adjusting  lever  on  the

front side of the seat, and  move  the
seat  forward and backward till to the
optimum, then release the adjusting
lever and  lock  the  seat  in  the  desired
position.

  Driver's seat back angle adjust-

ment

Raise the adjusting lever on the left

side of the seat,  and  adjust  the  seat
back to an angle most appropriate for
holding the steering wheel,  then
release the lever to lock the seatback in
the desired position.

 Assistant's seat back adjustment

Turn the knob located on the right

side of the seat, the  seatback  will  be
adjusted to the desired position or
putted down face to the seat.

Construction and Operation

3—4



 Center seat back adjustment

Turn the knob located on the left

side of the seat, the  seatback  will  be
adjusted to the desired position or
putted down face to the seat.

 Safety belts

Slowly  pull  out  the  safety  belt  and

make it throught your body from the left
side  of  your  neck  to  the  right  side  of
your waist and press the button, then
insert the locking hook into the latch
hook. Adjust the length of the safty belt
to the optimum.

Note:
Adjust the position of the seat correctly;
Make sure that the safty belt is not winded

or rubbed by hard edge, and far away from the
chemical and battery acid;

One belt for one person;
After being overused, invalid or damaged,

the whole belt should be changed;

If the safty belt retractor does not work well,

the whole belt should be changed immediately.

Instruments

1.Fuel Gauge

The fuel gauge use to indicate the

approximate level of fuel remaining in
the fue tank. The needle will change
because  of  vehicle  braking,  turning,
accelerating or climbing.
