Lincoln Continental (2019 year). Manual - part 9

Pre-Collision Assist

Action

Message

You have a blocked sensor due to bad weather, ice, mud or water in front of the radar sensor.
You can typically clean the sensor to resolve.

Pre-Collision Assist Not Available Sensor

Blocked

A fault with the system has occurred. Contact an authorized dealer as soon as possible.

Pre-Collision Assist Not Available

Remote Start

Action

Message

Displays as a reminder to apply the brake and push the gear shift button to drive the vehicle

after a remote start.

To Drive: Press Brake and Gear Shift

Button

Seats

Action

Message

Displays as a reminder that memory seats are not available while driving.

Memory Recall Not Permitted While Driving

Displays to show where your memory setting has been saved.

Memory {0} Saved

135

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Information Displays

Stability Control

Action

Message

Displayed when the system has detected a condition that requires service. Contact your

authorized dealer as soon as possible.

Service AdvanceTrac

The traction control has been disabled or enabled by the driver.

AdvanceTrac Off On

Starting System

Action

Message

Displays when starting the vehicle as a reminder to apply the brake.

To START Press Brake

Displays when the starter has exceeded its cranking time in attempting to start the vehicle.

Cranking Time Exceeded

Displays when the starter is attempting to start the vehicle.

Engine Start Pending Please Wait

Displays when the pending start has been cancelled.

Pending Start Cancelled

136

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Information Displays

Tire Pressure Monitoring System

Action

Message

One or more tires on your vehicle have low tire pressure.   See Tire Pressure Monitoring System

(page 357).

Tire Pressure Low

The tire pressure monitoring system is malfunctioning. If the warning stays on or continues to

come on, contact an authorized dealer. See Tire Pressure Monitoring System (page 357).

Tire Pressure Monitor Fault

A tire pressure sensor is malfunctioning, or your spare tire is in use. For more information on

how the system operates under these conditions,  See Tire Pressure Monitoring System (page
357).  If the warning stays on or continues to come on, contact an authorized dealer as soon as

possible.

Tire Pressure Sensor Fault

Transmission

Action

Message

You switched the engine off and shift select lever is in any position other than park (P).

Shift to Park

Transmission is too cold. Wait for it to warm up before you drive.

Transmission Warming Up Please Wait

Displays when the brake pedal needs to be depressed.

Press Brake Pedal

The transmission is overheating and needs to cool.  Stop in a safe place as soon as it’s possible.

Transmission Over Temperature Stop

Safely

See an authorized dealer.

Transmission Service Required

137

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Information Displays

Action

Message

The transmission is overheating and needs to cool.  Stop in a safe place as soon as it’s possible.

Transmission Too Hot Press Brake

The transmission has limited functionality.  See an authorized dealer.

Transmission Limited Function See Manual

A reminder to shift into park. In addition, this message is typical after reconnecting or recharging

the battery until you cycle the ignition to the on mode.  See Changing the 12V Battery (page

325).

Transmission Not in Park

Displays when there is a system fault and the park brake needs to be depressed before exiting

the vehicle. See your authorized dealer.

SHIFT SYS FAULT Confirm Park Brake

Apply Before Exiting the Vehicle

See your authorized dealer.

SHIFT SYS FAULT Service Required

Displays when there is a system fault while the vehicle is shifting to park. See your authorized

dealer.

SHIFT SYS FAULT Vehicle is Shifting to

Park

Displays when there is a system fault while the vehicle is shifting to reverse. See your authorized

dealer.

SHIFT SYS FAULT Reverse Unavailable

Service Required

See an authorized dealer.

SHIFT SYS FAULT Drive Unavailable Select

S for Drive Service Required

See your authorized dealer.

SHIFT SYS FAULT Neutral Unavailable

Service Required

See your authorized dealer.

SHIFT SYS FAULT Sport Unavailable

Service Required

Displays when an invalid gear has been selected.

Invalid Gear Selection

138

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Information Displays

Action

Message

Displays when the brake pedal needs to be depressed to enable the transmission to shift from

park.

Depress Brake to Shift from Park

Displays when neutral hold is active. See Automatic Transmission (page 191).

Stay in Neutral Mode Engaged

Displays when the neutral button N needs to be pressed again to enter neutral hold. See Auto-

matic Transmission (page 191).

To Stay in Neutral When Exiting Vehicle

Select N Again

HEAD UP DISPLAY

 (IF EQUIPPED)

Head Up Display (HUD)

This is a visual system that shows information
in your field of view as you drive. The
information comes from various vehicle
systems and includes vehicle speed, speed
limit, navigation, and advanced driver
assistance systems (ADAS), such as adaptive
cruise control (ACC) and the lane keeping
system. This system projects the information
off the windshield, and focuses the image

near the end of the hood approximately 7 ft
(2 m) in front of the driver. Viewing this
information does not require you to
significantly move your head, allowing you
to keep your eyes on the road while having
quick and easy access to information.

Head Up Display Information

E228521

Signaling and Traffic Indication.

A

Left Information Group.

B

ADAS Display Area.

C

139

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Information Displays

Navigation Display Area.

D

Status Bar.

E

Speedometer Display Area.

F

Signaling and Traffic Indication

Displays direction indicators, blind spot
information (if direction indicators are active)
and cross traffic alert.

Left Information Group

Displays incoming call information.

ADAS Display Area

Displays ACC and lane keeping system
status and warnings.

Navigation Display Area

Displays navigation next turn instructions.

Status Bar

Displays distance to empty (DTE), time and
outside air temperature. Next to DTE, the
fuel gauge fill color changes to yellow in low
fuel conditions. You can switch off the status
bar in the HUD settings menu.

Speedometer Display Area

Displays current vehicle speed, speed limit
(if available in the map database) and your
transmission gear selection.

Configuring The Head Up Display

You can control the system's options through
the information display by using the HUD,
OK and arrow buttons on the right-hand side
of your steering wheel.  See General
Information (page 112).  You can adjust the
display according to your height to make
viewing the content easier. You can also
adjust what content displays and the
brightness of the content. The system's
options appear in the instrument cluster
while the updates happen in the HUD.

Note: If HUD On is unchecked, other options
of the system are hidden.

Note: The HUD menu automatically closes
after a certain period of inactivity.

Note: The HUD image brightness
automatically adjusts to the brightness of
the ambient environment. You have the
ability to adjust the brightness further
according to your preference.

Note: In some instances, sunlight can cause
some reflections in and around the HUD
image.

140

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Information Displays

Head-Up Display (HUD)

Turns the HUD on and off.

HUD On

Follow onscreen directions to confirm or modify your settings.

Brightness

Follow onscreen directions to confirm or
modify your settings.

Vertical Position

HUD Adjustments

Image Rotation

Turns the distance to empty, time and temperature on and off.

HUD Content

Select Your Setting

Cruise and Lane Control

Note: When you save a memory preset position, your current HUD settings are also saved to that memory preset position.  See Memory
Function (page 160).

141

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Information Displays

Maintaining Your Head Up Display

•

Do not place objects onto the transparent
cover, as they may block you from seeing
portions of the image. These objects
could also damage the cover and affect
the quality of the projected image.

•

The system uses a special windshield
designed to provide the optimum image
quality. You must replace the windshield
in a vehicle with this system with a
certified original equipment
manufactured (OEM) head up display
windshield. Replacing this system's
windshield with a non-head up display
windshield causes a double image or
distorted image. Have an authorized
dealer or authorized repair facility replace
the windshield.

•

Light conditions such as oncoming
headlamps, sunrise, sunset or reflections
off of wet road surfaces can affect the
driver's ability to see the HUD image.

•

Clean the windshield often for optimal
HUD performance.  See Cleaning the
Windows and Wiper Blades (page 335).

142

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Information Displays

AUTOMATIC CLIMATE CONTROL

Note: You can switch temperature units
between Fahrenheit and Celsius.

Directing Air to the Instrument Panel
Air Vents

Press and release the button to
direct airflow to instrument panel
air vents.

Directing Air to the Footwell Air Vents

Press and release the button to
direct airflow to footwell air vents.

Setting the Blower Motor Speed

E265389

Turn the control to adjust the volume of air
circulated in the vehicle.

Setting the Temperature

Press the toggle button on the left-hand side
of the climate control upward or downward
to set the left-hand temperature.

Note: This control also adjusts the right-hand
side temperature when you switch off dual
zone mode.

Press the toggle button on the right-hand
side of the climate control upward or
downward to set the right-hand temperature.

Switching Auto Mode On and Off

Press and release the button to
switch on automatic operation.
Repeatedly press the button to

adjust auto mode.

Adjust the blower motor control to turn auto
mode off.

When three indicators are on, the blower
motor adjusts to the highest speed to reach
the selected temperature as quickly as
possible.

When two indicators are on, the blower
motor adjusts to a medium speed to reach
the selected temperature with a reduced
amount of cabin noise.

When one indicator is on, the blower motor
adjusts to the lowest speed to reach the
selected temperature with the least amount
of cabin noise.

Note: The system starts at the previous
setting when you switch on AUTO.

143

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Climate Control

Note: You can also switch off dual zone
mode by pressing and holding the button for
more than two seconds.

Switching Defrost On and Off

Press and release the button to
distribute air through the
windshield air vents and de-mister.

Air directed to the instrument panel and
footwell air vents turns off. You can also use
this setting to defog and clear the windshield
of a thin covering of ice.

Switching the Air Conditioning On and
Off

Press and release the button.

Use air conditioning with recirculated air to
improve cooling performance and efficiency.

Note: In certain conditions (for example,
maximum defrost) the air conditioning
compressor may continue to operate even
though you switch off the air conditioning.

Switching the Climate Control On and
Off

Press and release the button.

Switching the Heated Seats On and Off

Press and release the button to
cycle through the various heat
settings and off.

See Heated Seats (page 163).

Switching Maximum Air Conditioning
On and Off

Press and release the button for
maximum cooling.

The left-hand and right-hand settings set to
LO, recirculated air flows through the
instrument panel air vents, air conditioning
turns on and the blower motor adjusts to the
highest speed.

Switching Maximum Defrost On and
Off

Press and release the button for
maximum defrosting.

The left-hand and right-hand settings set to
HI, air flows through the windshield air vents,
and the blower motor adjusts to the highest
speed.

You can also use this setting to defog and
clear the windshield of a thin covering of ice.

Note: To prevent window fogging, you
cannot select recirculated air when
maximum defrost is on.

Note: The heated rear window also turns on
when you select maximum defrost.

Switching Recirculated Air On and Off

Press and release the button to
switch between outside air and
recirculated air.

144

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Climate Control

The air currently in the passenger
compartment recirculates. This may reduce
the time needed to cool the interior (when
used with A/C) and reduce unwanted odors
from entering your vehicle.

Note: Recirculated air may turn off (or
prevent you from switching on) in all air flow
modes except MAX A/C to reduce the risk
of fogging. Recirculation may also turn on
and off in various air distribution control
combinations during hot weather to improve
cooling efficiency.

Switching the Ventilated Seats On and
Off

E268558

Press and release the button to
cycle through the various
ventilated seat settings and off.

See Climate Controlled Seats (page 165).

HINTS ON CONTROLLING THE
INTERIOR CLIMATE

General Hints

Note: Prolonged use of recirculated air may
cause the windows to fog up.

Note: You may feel a small amount of air
from the footwell air vents regardless of the
air distribution setting.

Note: To reduce humidity build-up inside
your vehicle, do not drive with the system
switched off or with recirculated air always
switched on.

Note: Do not place objects under the front
seats as this may interfere with the airflow
to the rear seats.

Note: Remove any snow, ice or leaves from
the air intake area at the base of the
windshield.

Note: To improve the time to reach a
comfortable temperature in hot weather,
drive with the windows open until you feel
cold air through the air vents.

Automatic Climate Control

Note: Adjusting the settings when your
vehicle interior is extremely hot or cold is not
necessary.

Note: The system adjusts to heat or cool the
interior to the temperature you select as
quickly as possible.

Note: For the system to function efficiently,
the instrument panel and side air vents
should be fully open.

Note: If you select AUTO during cold outside
temperatures, the system directs air flow to
the windshield and side window air vents. In
addition, the blower motor may run at a
slower speed until the engine warms up.

Note: If you select AUTO during hot
temperatures and the inside of the vehicle
is hot, the system uses recirculated air to
maximize interior cooling. Blower motor
speed may also reduce until the air cools.

Quickly Heating the Interior

1. Press and release AUTO.

145

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Climate Control

2. Adjust the temperature function to the

setting you prefer.

Recommended Settings for Heating

1. Press and release AUTO.

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as a
starting point, then adjust the setting as
necessary.

Quickly Cooling the Interior

1. Press and release MAX A/C.

Recommended Settings for Cooling

1. Press and release AUTO.

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as a
starting point, then adjust the setting as
necessary.

Defogging the Side Windows in Cold
Weather

1. Press and release defrost.

2. Adjust the temperature control to the

setting you prefer. Use 72°F (22°C) as a
starting point, then adjust the setting as
necessary.

REAR PASSENGER CLIMATE
CONTROLS

Directing Air to the Rear Console Air
Vents

Press and release the button to
direct airflow to the rear console
air vents.

Directing Air to the Rear Footwell Air
Vents

Press and release the button to
direct airflow to rear footwell air
vents.

Note: Air can be directed through any
combination of air vents.

Rear Climate Control Lock Indicator

Illuminates when the rear climate
controls are locked through the
front climate controls.

Note: If the rear climate controls are locked
and the rear climate system is turned off, the
indicator illuminates for a few seconds when
you try to use any of the rear climate
controls.

Setting the Rear Blower Motor Speed

E265389

146

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Climate Control

Turn the control to adjust the volume of air
circulated in the rear passenger
compartment.

Setting the Rear Temperature

E265862

Turn the control to set the temperature in
the rear passenger compartment.

Switching Rear Auto Mode On

Press and release the button to
switch rear automatic operation on,
then set the temperature.

The system adjusts the blower motor speed,
air distribution, air conditioning operation to
reach and maintain the temperature you
have set.

Switching the Rear Heated Seats On
and Off

Press and release the button to
cycle through the various heat
settings and off.

See Heated Seats (page 163).

Switching the Rear Ventilated Seats
On and Off

E268558

Press and release the button to
cycle through the various
ventilated seat settings and off.

See Climate Controlled Seats (page 165).

Switching the Rear Climate Control On
and Off

Press and release the button to
switch the rear climate control on
or off.

Note: If the system is on and Max Defrost is
switched on through the front climate
controls, the system turns off. It turns back
on when Max Defrost is switched off.

Note: If Max Defrost is switched on, the
system can be turned on at the same time.

HEATED WINDSHIELD

 (IF EQUIPPED)

Windshield Wiper De-Icer

When you switch the heated rear
window on, the windshield wiper
de-icer turns on.

HEATED REAR WINDOW

Press the button to clear the rear
window of thin ice and fog.  The
heated rear window turns off after

a short period of time.

Note: Make sure the engine is on before
operating the heated windows.

147

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Climate Control

Note: Do not use harsh chemicals, razor
blades or other sharp objects to clean or
remove decals from the inside of the heated
rear window. The vehicle warranty may not
cover damage to the heated rear window
grid lines.

HEATED EXTERIOR MIRRORS

When you switch the heated rear window
on, the heated exterior mirrors turn on.

Note: Do not remove ice from the mirrors
with a scraper or adjust the mirror glass
when it is frozen in place.

Note: Do not clean the mirror housing or
glass with harsh abrasives, fuel or other
petroleum-based cleaning products. The
vehicle warranty may not cover damage
caused to the mirror housing or glass.

CABIN AIR FILTER

Your vehicle is equipped with a cabin air
filter, which gives you and your passengers
the following benefits:
•

It improves your driving comfort by
reducing particle and odor concentration.

•

It improves the interior compartment
cleanliness.

•

It protects the climate control
components from particle deposits.

You can locate the cabin air filter behind the
glove box.

Note: Make sure you have a cabin air filter
installed at all times. This prevents foreign
objects from entering the system. Running
the system without a filter in place could
result in degradation or damage to the
system.

Replace the filter at regular intervals.  See
Scheduled Maintenance (page 528).

For additional cabin air filter information, or
to replace the filter, see a qualified
technician.

REMOTE START

The climate control system adjusts the
interior temperature during remote start.

You can switch this feature on or off and
adjust the settings using the information
display controls.  See Information Displays
(page 112).

You cannot adjust the climate control setting
during remote start operation.  Switch the
ignition on to make adjustments.

Based on your remote start settings, the
following vehicle-dependent features may
or may not remain on after remote starting
your vehicle:
•

Climate controlled seats.

•

Heated steering wheel.

•

Heated mirrors.

•

Heated rear window.

•

Windshield wiper de-icer.

Note: For dual zone climate controlled seats,
the passenger seat setting defaults to match
the driver seat during remote start.

148

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Climate Control

Automatic Settings

If Auto is on, the system sets the interior
temperature to 72°F (22°C) and heats or
cools the vehicle interior as required to
achieve comfort.

Note: In cold weather, the heated rear
window and heated mirrors turn on.

Last Settings

If Last Settings is on, the system uses the
settings last selected before you turned off
the vehicle.

Heated and Cooled Features

In Auto mode, certain heated features may
switch on during cold weather, and cooled
features during hot weather.

149

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Climate Control

SITTING IN THE CORRECT
POSITION

WARNING: Sitting improperly, out of

position or with the seatback reclined too
far can take weight off the seat cushion
and affect the decision of the passenger
sensing system, resulting in serious injury
or death in the event of a crash. Always sit
upright against your seat back, with your
feet on the floor.

WARNING: Do not recline the

seatback too far as this can cause the
occupant to slide under the seatbelt,
resulting in serious injury in the event of a
collision.

WARNING: Do not place objects

higher than the top of the seat backrest.
Failure to follow this instruction could result
in personal injury or death in the event of
a sudden stop or crash.

E68595

When you use them properly, the seat, head
restraint, seatbelt and airbags will provide
optimum protection in the event of a crash.

We recommend that you follow these
guidelines:
•

Sit in an upright position with the base of
your spine as far back as possible.

•

Do not recline the seat backrest so that
your torso is more than 30° from the
upright position.

•

Adjust the head restraint so that the top
of it is level with the top of your head and
as far forward as possible. Make sure that
you remain comfortable.

•

Keep sufficient distance between
yourself and the steering wheel. We
recommend a minimum of 10 in (25 cm)
between your breastbone and the airbag
cover.

•

Hold the steering wheel with your arms
slightly bent.

•

Bend your legs slightly so that you can
press the pedals fully.

•

Position the shoulder strap of the seatbelt
over the center of your shoulder and
position the lap strap tightly across your
hips.

Make sure that your driving position is
comfortable and that you can maintain full
control of your vehicle.

150

Continental (CPL) Canada/United States of America, enUSA, Edition date: 201807, Second-Printing

Seats
