Lincoln MKX (2018 year). Manual - part 8

Trip 1 & 2

You can access the menu using the
information display control.

Trip 1 & 2

Trip Odometer

Average Fuel Economy

Trip Timer

Press and hold OK to reset the currently displayed trip information.

•

Trip odometer — Shows the accumulated trip distance.

•

Average fuel economy — Shows the average fuel economy for a given trip.

•

Trip Timer— Timer stops when you switch off the vehicle and restarts when you restart the vehicle.

Fuel Economy

Use the left or right arrow buttons to choose
the desired fuel economy display.

119

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Fuel Economy

Instant Fuel Economy

Fuel History

Average Speed

•

Instant Fuel Economy - Shows a visual graph of your instantaneous fuel economy since the function was last reset.

•

Fuel History - Shows a bar chart of your fuel history.

•

Average Speed - Displays the average speed you have driven.

Driver Assist

In this mode, you can configure different
driver setting choices.

Note: Some items are optional and may not
appear.

Driver Assist

Traction Control

Comfort, Normal or Sport

Steering in "D"

Adaptive Steering

Sport or Normal

Steering in "S"

System

Blindspot

120

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Driver Assist

Cross Traffic

Adaptive or Normal

Cruise Control

On

Driver Alert

Driver Alert Display

Intelligent AWD

Alert, Aid or Alert + Aid

Mode

Lane Keeping Sys

High, Normal or Low

Intensity

Alert Sensitivity

Pre-Collision

Distance Indication

Active Braking

Front Park Aid

Rear Park Aid

Tire Pressure

Tire Monitor

Reset

Trailer Sway

121

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Settings

In this mode, you can configure different
driver setting choices.

Note: Some items are optional and may not
appear.

Settings

Comfort, Normal or Sport

Handling in D

Drive Control

Vehicle

Normal or Sport

Handling in S

Performance in S

Easy Entry/Exit

Auto Engine Off

Right Hand Traffic or Left Hand

Traffic

Traffic Setup

Adaptive Headlamps

Lighting

Auto Highbeam

Select time interval

Autolamp Delay

Daytime Lights

Welcome Lighting

Autounlock

Locks

Audible

Feedback

Exterior Lights

122

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Settings

Mislock

All Doors or Driver's Door

Remote Unlock

Switches Inhibit

Autofold

Mirror

Hold OK to Initialize

Neutral Tow

Remaining Life XXX% - Hold OK to Reset

Oil Life

Enable Switch or Disable Switch

Power Liftgate

Auto or Last Setting

Climate Control

Remote Start

Auto or Off

Front Seats & Wheel

5, 10 or 15 minutes

Duration

System

Seatbelts

Remote

Windows

Courtesy Wipe

Wipers

Rain Sensing

MyKey Status

MyKey

123

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Settings

Hold OK to Create MyKey

Create MyKey

Always On or User Selectable

911 Assist

Do Not Disturb

Traction Control

Choose desired speed or off

Max Speed

Speed Minder

Volume Limiter

Hold OK to Clear All MyKeys

Clear MyKeys

Miles & Gallons, L/100 km or km/L

Distance Unit

Display

°Fahrenheit or °Celsius

Temperature Unit

psi, kPa or bar

Tire Pressure

Choose your applicable setting

Language

Speedo in km/h

Note: Some MyKey items only appear if a MyKey is set.

124

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

INFORMATION MESSAGES

Note: Depending on the vehicle options
equipped with your vehicle, not all of the
messages display or are available. Certain
messages may be abbreviated or shortened
depending upon which cluster type you
have.

E145981

Press the OK button to acknowledge and
remove some messages from the information
display. Other messages are removed
automatically after a short time.

Certain messages need to be confirmed
before you can access the menus.

Active Park

Action

Message

Displayed when the system needs service. Contact an authorized dealer as soon as possible.

Active Park Fault

125

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Adaptive Cruise Control

Action

Message

Displayed when a radar malfunction is preventing the ACC from engaging.  See Using Adaptive

Cruise Control (page 231).

Adaptive Cruise Malfunction

Displayed when conditions exist such that the adaptive cruise cannot function properly.  See

Using Adaptive Cruise Control (page 231).

Adaptive Cruise Not Available

Displayed when the radar is blocked because of poor radar visibility due to bad weather or ice/
mud/water in front of radar. Driver can typically clean the sensor to resolve.  See Using Adaptive

Cruise Control (page 231).

Adaptive Cruise Not Available Sensor

Blocked See Manual

Displayed when the automatic braking has been disabled.

Normal Cruise Active Automatic Braking

Turned Off

Displayed when a radar malfunction is preventing the ACC from engaging.

Front Sensor Not Aligned

Displayed when the adaptive cruise has reinstated controls to the driver.

Adaptive Cruise - Driver Resume Control

Displays when the vehicle speed is too slow to activate the adaptive cruise.

Adaptive Cruise Speed Too Low to

Activate

Displays when the adaptive cruise is automatically adjusting the gap distance and the driver

needs to shift the transmission into a lower gear.

Adaptive Cruise Shift Down

126

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Adaptive Steering

Action

Message

The adaptive steering system has detected a difference between steering wheel angle and the

desired road wheel angle. The steering wheel adjusts itself to correct this difference. This

adjustment is part of normal system operation.

Adaptive Steering Initialization

The adaptive steering system is off. It is possible that the steering wheel may not be straight

when the vehicle is driving straight ahead. If this message persists, see an authorized dealer.

Adaptive Steering Fault Service Required

The adaptive steering system integrity cannot be verified. Do not drive the vehicle and contact

an authorized dealer immediately.

Adaptive Steering Loss Do Not Drive

AdvanceTrac™

Action

Message

Displays when the system detects a malfunction due to a blocked sensor.

Service AdvanceTrac

Displayed when the traction control has been disabled or enabled by the driver.

AdvanceTrac Off On

127

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Airbag

Action

Message

Displays when the system detects a malfunction due to a blocked sensor.

Occupant Sensor BLOCKED Remove

Objects Near Passenger Seat

Alarm

Action

Message

Displays when the alarm has been triggered due to unauthorized entry.  See Anti-Theft Alarm

(page 87).

Vehicle Alarm To Stop Alarm, Start Vehicle.

Automatic Engine Shutdown

Action

Message

Displays when the engine is getting ready to shut off.

Engine Shuts Off In {seconds to shut off:#0}

Seconds

Displays when the engine has shut off to help increase fuel economy.

Engine Shut Off For Fuel Economy

Displays when the engine is getting ready to shut off. You can press OK on the left steering

wheel button to override the shut down.

Engine Shuts Off in {seconds to shut off:#0}

Seconds Press Ok to Override

128

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

AWD

Action

Message

Displayed when the AWD system has been temporarily disabled to protect itself from overheating.

AWD Temporarily Disabled

Displayed when the AWD system has been automatically disabled to protect itself. This is caused

by operating the vehicle with the compact spare tire installed or if the system is overheating.

AWD OFF

The AWD system resumes normal function and clears this message after driving a short distance

with the road tire re-installed or after the system is allowed to cool.

AWD Restored

Displayed in conjunction with the Throttle Control/Transmission/AWD light when the AWD system
is not operating properly. If the warning stays on or continues to come on, contact an authorized

dealer as soon as possible.

AWD Malfunction Service Required

129

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Battery and Charging System

Action

Message

Displayed when the charging system needs servicing. If the warning stays on or continues to

come on, contact an authorized dealer as soon as possible.

Check Charging System

Displayed when the battery management system detects an extended low-voltage condition.

Various vehicle features are disabled to help preserve the battery. Turn off as many of the

electrical loads as soon as possible to improve system voltage. If the system voltage has

recovered, the disabled features operate again as normal

Low Battery Features Temporarily Turned

Off

Displayed when the battery management system determines that the battery is at a low state of
charge. Turn the ignition off as soon as possible to protect the battery. This message clears once
the vehicle has been started and the battery state of charge has recovered. Turning off unneces-

sary electrical loads allows faster battery state-of-charge recovery.

Turn Power Off To Save Battery

130

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Blind Spot Information and Cross Traffic Alert System

Action

Message

Displayed when a fault with the system has occurred. Contact an authorized dealer as soon as

possible.

Blindspot System Fault

Displayed when the system sensors are blocked. Contact an authorized dealer as soon as

possible.  See Blind Spot Information System (page 245).

Blindspot Not Available Sensor Blocked

See Manual

Displayed when the system detects a vehicle.  See Cross Traffic Alert (page 247).

Cross Traffic Vehicle Coming From X

Displayed when the system sensors are blocked.  See Cross Traffic Alert (page 247).

Cross Traffic Not Available Sensor Blocked

See Manual

Displays when a fault with the system has occurred. Contact an authorized dealer as soon as

possible.

Cross Traffic System Fault

131

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Collision Warning System

Action

Message

Displayed when there is a system malfunction with the collision warning system. The system is

disabled. Contact an authorized dealer as soon as possible.

Collision Warning Malfunction

Displayed when the collision warning system radar is blocked because of poor radar visibility

due to bad weather or ice/mud/water in front of the radar. You can typically clean the sensor to

resolve. If the concern persists, contact an authorized dealer as soon as possible.

Collision Warning Not Available Sensor

Blocked See Manual

Displayed when there is a system malfunction with the collision warning system. The system is

disabled. Contact an authorized dealer as soon as possible.

Collision Warning Not Available

Doors and Locks

Action

Message

Displays when the door(s) listed is not completely closed and the vehicle is moving.

X Door Ajar

Displays when the door(s) listed is not completely closed.

Displays when the liftgate is not completely closed.

Liftgate Ajar

132

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Action

Message

Displays when the hood is not completely closed.

Hood Ajar

Displays when the door switches have been disabled.

Switches Inhibited Security Mode

Displays the factory keypad code after the keypad has been reset.  See Keyless Entry (page

76).

Factory Keypad Code {X X X X X}

Driver Alert

Action

Message

Stop and rest as soon as it is safe to do so.

Driver Alert Warning Rest Now

Take a rest break soon.

Driver Alert Warning Rest Suggested

Fuel

Action

Message

Displayed as an early reminder of a low fuel condition.

Fuel Level Low

Displayed when the fuel fill inlet may not be properly closed.

Check Fuel Fill Inlet

133

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays

Hill Start Assist

Action

Message

Displays when hill start assist is not available. Contact an authorized dealer.

Hill Start Assist Not Available

Keys and Intelligent Access

Action

Message

Displayed as a reminder to press the brake while starting the vehicle.

To START Press Brake

Displayed if the key is not detected by the system.  See Keyless Starting (page 172).

No Key Detected

Displayed when the start/stop button is pressed to shut off the engine and an Intelligent Access

key is not detected inside the vehicle.

Restart Now or Key is Needed

Displayed when the vehicle is in the run ignition state.

Run Power Active

This message is displayed when there is a problem with your vehicle’s starting system. See an

authorized dealer for service.

Starting System Fault

Displayed during spare key programming, when an intelligent access key is programmed to the

system.

Key Program Successful

Displayed during spare key programming, when an intelligent access key has failed to be

programmed.

Key Program Failure

134

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Information Displays
