Dodge Challenger (2019 year). Manual

FLUIDS AND LUBRICANTS

Engine

Component

Fluid, Lubricant, or Genuine Part

Engine Coolant

We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000
(240,000 km)Mile Formula OAT (Organic Additive Technology).

Engine Oil – 3.6L & 5.7L Engine

We recommend you use API Certified SAE 5W-20 Engine Oil, meeting the
requirements of FCA Material Standard MS-6395 such as Mopar SAE 5W-20,
Pennzoil SAE 5W-20, and Pennzoil gold 5W-20 semi-synthetic oil. Refer to
your engine oil filler cap for correct SAE grade.

Engine Oil – 6.4L Engine

For best performance and maximum protection under all types of operating
conditions, the manufacturer only recommends full synthetic engine oils.
The manufacturer recommends the use of Pennzoil Ultra Platinum 0W-40 or
equivalent Mopar engine oil meeting the requirements of FCA Material Stan-
dard MS-12633 for use in all operating temperatures.

Engine Oil Filter

We recommend you use Mopar Engine Oil Filters.

Spark Plugs

We recommend you use Mopar Spark Plugs.

Fuel Selection – 3.6 Engine

87 Octane, 0-15% Ethanol.

Fuel Selection – 5.7 Engine With Au-
tomatic Transmission

89 Octane recommended – 87 Octane acceptable, 0-15% Ethanol.

Fuel Selection – 6.4L Engine & 5.7
Engine With Manual Transmission

91 Octane or higher, 0-15% Ethanol.

TECHNICAL SPECIFICATIONS

413

CAUTION!

• Mixing of engine coolant (antifreeze) other than

specified Organic Additive Technology (OAT) en-
gine coolant (antifreeze), may result in engine dam-
age and may decrease corrosion protection. Organic
Additive Technology (OAT) engine coolant is differ-
ent and should not be mixed with Hybrid Organic
Additive Technology (HOAT) engine coolant (anti-
freeze) or any “globally compatible” coolant (anti-
freeze). If a non-OAT engine coolant (antifreeze) is
introduced into the cooling system in an emergency,
the cooling system will need to be drained, flushed,

(Continued)

CAUTION! (Continued)

and refilled with fresh OAT coolant (conforming to
MS.90032), by an authorized dealer as soon as pos-
sible.

• Do not use water alone or alcohol-based engine

coolant (antifreeze) products. Do not use additional
rust inhibitors or antirust products, as they may not
be compatible with the radiator engine coolant and
may plug the radiator.

• This vehicle has not been designed for use with

propylene glycol-based engine coolant (antifreeze).
Use of propylene glycol-based engine coolant (anti-
freeze) is not recommended.

414

TECHNICAL SPECIFICATIONS

Chassis

Component

Fluid, Lubricant, or Genuine Part

8-Speed Automatic Transmission

Use only Mopar ZF 8&9 Speed ATF Automatic Transmission Fluid, or equiva-
lent. Failure to use the correct fluid may affect the function or performance of
your transmission.

Manual Transmission –
If Equipped

We recommend you use Mopar ATF+4 Automatic Transmission Fluid.

Brake Master Cylinder

We recommend you use Mopar DOT 3, SAE J1703. If DOT 3 brake fluid is not
available, then DOT 4 is acceptable.

Front Axle

We recommend you use Mopar Synthetic Gear Lubricant SAE 75W90
(API GL-5).

Rear Axle – 3.6L/5.7L Engine With
Automatic Transmission

We recommend you use Mopar OD Synthetic Gear Lubricant SAE 75W85
(API GL-5).

Rear Axle – 6.4 Engine or 5.7 With
Manual Transmission

We recommend you use Mopar LSD Synthetic Gear Lubricant SAE 75W85
(API GL-5).

Transfer Case – AWD (If Equipped)

We recommend you use Mopar Transfer Case Lubricant for BorgWarner 44–40.

TECHNICAL SPECIFICATIONS

415

UCONNECT SYSTEMS

For detailed information about your Uconnect system,
refer to your Uconnect Owner’s Manual Supplement.

NOTE:

Uconnect screen images are for illustration pur-

poses only and may not reflect exact software for your
vehicle.

DRAG & DROP MENU BAR

The Uconnect features and services in the main menu bar
are easily changed for your convenience. Simply follow
these steps:

1. Press the “Apps

” button to open the App screen.

2. Press and hold, then drag the selected App to replace an

existing shortcut in the main menu bar.

The new app shortcut, that was dragged down onto the
main menu bar, will now be an active App/shortcut.

NOTE:

This feature is only available if the vehicle is in

park.

Uconnect 4 Main Menu

Uconnect 4C/4C NAV Main Menu

MULTIMEDIA

419

CYBERSECURITY

Your vehicle may be a connected vehicle and may be
equipped with both wired and wireless networks. These
networks allow your vehicle to send and receive informa-
tion. This information allows systems and features in your
vehicle to function properly.

Your vehicle may be equipped with certain security fea-
tures to reduce the risk of unauthorized and unlawful
access to vehicle systems and wireless communications.
Vehicle software technology continues to evolve over time
and FCA US LLC, working with its suppliers, evaluates
and takes appropriate steps as needed. Similar to a com-
puter or other devices, your vehicle may require software
updates to improve the usability and performance of your
systems or to reduce the potential risk of unauthorized and
unlawful access to your vehicle systems.

The risk of unauthorized and unlawful access to your
vehicle systems may still exist, even if the most recent
version of vehicle software (such as Uconnect software) is
installed.

WARNING!

• It is not possible to know or to predict all of the

possible outcomes if your vehicle’s systems are
breached. It may be possible that vehicle systems,
including safety related systems, could be impaired
or a loss of vehicle control could occur that may
result in an accident involving serious injury or
death.

• ONLY insert media (e.g., USB, SD card, or CD) into

your vehicle if it came from a trusted source. Media
of unknown origin could possibly contain malicious
software, and if installed in your vehicle, it may
increase the possibility for vehicle systems to be
breached.

• As always, if you experience unusual vehicle behav-

ior, take your vehicle to your nearest authorized
dealer immediately.

420

MULTIMEDIA

NOTE:
• FCA US LLC or your dealer may contact you directly

regarding software updates.

• To help further improve vehicle security and minimize

the potential risk of a security breach, vehicle owners
should:

• Routinely check www.driveuconnect.com (U.S. Resi-

dents) or www.driveuconnect.ca (Canadian Residents)
to learn about available Uconnect software updates.

• Only connect and use trusted media devices (e.g.

personal mobile phones, USBs, CDs).

Privacy of any wireless and wired communications cannot
be assured. Third parties may unlawfully intercept infor-
mation and private communications without your consent.
For further information, refer to “Data Collection & Pri-
vacy” in your Uconnect Owner’s Manual Supplement or
“Onboard Diagnostic System (OBD II) Cybersecurity” in
“Getting To Know Your Instrument Panel”.

UCONNECT SETTINGS

The Uconnect system uses a combination of buttons on the
touchscreen and buttons on the faceplate located on the
center of the instrument panel that allows you to access
and change the customer programmable features.

Uconnect 4 Buttons On Touchscreen And Buttons On

Faceplate

1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate

MULTIMEDIA

421

NOTE:

Interior trims may vary. 6.4L vehicles will receive a

“SRT” button rather than a “Sport” button on the Instru-
ment Panel.

Customer Programmable Features — Uconnect 4
Settings

Press the “Settings” button on the bottom bar, or press the
“Apps

” button, then press the “Settings” button on

the touchscreen to display the menu setting screen. In
this mode the Uconnect system allows you to access all
of the available programmable features.

NOTE:

Depending on the vehicle’s options, feature set-

tings may vary.

When making a selection, press the button on the touch-
screen to enter the desired mode. Once in the desired
mode, press and release the preferred setting “option” until
a check-mark appears next to the setting, showing that
setting has been selected. Once the setting is complete,
press the “X” button on the touchscreen to close out of the
settings screen. Pressing the Up or Down Arrow button on
the right side of the screen will allow you to toggle up or
down through the available settings.

The following tables list the settings that may be found
within the Uconnect 4 radio, along with the selectable
options pertaining to each setting.

Uconnect 4C/4C NAV Buttons On Touchscreen And

Buttons On Faceplate

1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate

422

MULTIMEDIA

Display

After pressing the “Display” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Display Mode

Manual

Auto

Display Brightness With Headlights

–

NOTE:

• When in the “Display Brightness With Headlights ON” display, you may select the brightness with the headlights

on. Adjust the brightness from (1–10) with the “+” and “–” buttons on the touchscreen.

• To make changes to the ⬙Display Brightness with Headlights ON⬙ setting, the headlights must be on and the inte-

rior dimmer switch must not be in the

⬙party⬙ or ⬙parade⬙ positions.

Display Brightness With Headlights

OFF

–

NOTE:

• When in the “Display Brightness With Headlights OFF” display, you may select the brightness with the headlights

off. Adjust the brightness from (1–10) with the “+” and “–” buttons on the touchscreen.

• To make changes to the ⬙Display Brightness with Headlights OFF⬙ setting, the headlights must be off and the inte-

rior dimmer switch must not be in the

⬙party⬙ or ⬙parade⬙ positions.

MULTIMEDIA

423

Setting Name

Selectable Options

Set Theme

Off

NOTE:
When in the “Set Theme” display, you may select the theme for the display screen. To make your selection, press the

⬙Set Theme⬙ button on the touchscreen, then select the desired theme option button until a check-mark appears show-
ing that the setting has been selected.

AutoShow Smartphone Display

Upon Connection

Off

Touchscreen Beep

Off

Controls Screen Time-Out — If

Equipped

Off

NOTE:
When the “Control Screen Time Out” feature is selected, the controls screen will stay open for five seconds before the
screen times out. With the feature deselected, the screen will stay open until it is manually closed.

Navigation Turn-By-Turn Displayed

In Cluster — If Equipped

Off

NOTE:
When the “Navigation Turn-By-Turn Displayed In Cluster” feature is selected, the turn-by-turn directions will appear
in the instrument cluster display as the vehicle approaches a designated turn within a programmed route.

424

MULTIMEDIA

Units

After pressing the “Units” button on the touchscreen you
may select each unit of measure independently displayed
in the instrument cluster display, and navigation system (if
equipped). The following selectable units of measure are
listed below:

Setting Name

Selectable Options

Units

Metric

Custom

Speed

MPH

km/h

Distance

Fuel Consumption

MPG (US)

MPG (UK)

L/100 km

km/L

Pressure

psi

kPa

bar

Temperature

°F

°C

Voice

After pressing the “Voice” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Voice Response Length

Brief

Detailed

Show Command List

Always

With Help

Never

MULTIMEDIA

425

Clock

After pressing the “Clock” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Sync Time With GPS — If

Equipped

Off

NOTE:
The “Sync Time With GPS” feature will allow you to automatically have the radio set the time.

Set Time Hours

–

Set Time Minutes

–

Time Format

12 hrs

24 hrs

Show Time In Status Bar — If

Equipped

Off

NOTE:
The “Show Time In Status Bar” feature will allow you to turn on or shut off the digital clock in the status bar.

426

MULTIMEDIA

Camera

After pressing the “Camera” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Parkview Backup Camera Delay

Off

NOTE:
The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image
with dynamic grid lines for up to ten seconds after the vehicle is shifted out of REVERSE. This delay will be canceled
if the vehicle’s speed exceeds 8 mph (13 km/h), the transmission is shifted into PARK, or the ignition is switched to
the OFF position.

Active Parkview Backup Camera

Guidelines

Off

NOTE:
The “Active ParkView Backup Camera Guidelines” feature overlays the Rear Backup Camera image with active, or
dynamic, grid lines to help illustrate the width of the vehicle and its projected back up path, based on the steering
wheel position when the option is checked. A dashed center line overlay indicates the center of the vehicle to assist
with parking or aligning to a hitch/receiver.

MULTIMEDIA

427

Safety & Driving Assistance

After pressing the “Safety & Driving Assistance” button on
the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Forward Collision Warn-

ing Sensitivity— If

Equipped

Near

Far

NOTE:
The Front Collision Warning (FCW) feature provides an audible and/or visual warning to potential forward colli-
sions. The feature can be set to Far, or set to Near. The default status of FCW is the Far setting. This means the sys-
tem will warn you of a possible collision with the vehicle in front of you when you are farther away. This gives you
the most reaction time. To change the setting for more dynamic driving, select the Near setting. This warns you of a
possible collision when you are much closer to the vehicle in front of you.

Forward Collision Warn-

ing Active Braking — If

Equipped

Low

Medium

High

NOTE:
The “Forward Collision Warning Plus (FCW+)” setting includes Advanced Brake Assist (ABA). The ABA applies ad-
ditional brake pressure when the driver requests insufficient brake pressure to avoid a potential frontal collision.

428

MULTIMEDIA

Dodge Challenger (2019 year). Manual - part 26
