Dodge Diesel (2004 year). Manual

Auto Unlock Feature Programming
This feature is enabled when your vehicle is shipped
from the assembly plant and can be disabled by using the
following procedure:

Customer Programming sequence to disable or enable:

1. Enter your vehicle and close all doors.

2. Fasten your seat belt (fastening the seat belt will cancel
any chiming that may be confusing during this program-
ming procedure).

3. Insert the key into the ignition.

4. Within 4 seconds, cycle the key from the OFF position
to the ON position four times ending in the ON position
(do not start the engine)

5. Within 30 seconds, press the driver’s door lock switch
in the UNLOCK direction.

6. A single chime will sound to indicate the feature has
been changed.

7. To reactivate the feature, repeat the above steps.

8. If a chime is not heard, program mode was canceled
before the feature could be changed. If necessary repeat
the above procedure.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Child Protection Door Lock

To provide a safer environment for children riding in the
rear seat, the rear doors of your vehicle have the child-
protection door lock system.

To use the system, open each rear door and slide the
control UP to engage the locks and DOWN to disengage
the child-protection locks. When the system on a door is
engaged, that door can only be opened by using the
outside door handle even if the inside door lock is in the
unlocked position.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

Avoid trapping anyone in a vehicle in a collision.
Remember that the rear doors can only be opened
from the outside when the child protection locks are
engaged.

NOTE:

After setting the child protection door lock

system, always test the door from the inside to make
certain it is in the desired position.

NOTE:

For emergency exit with the system engaged,

move the door lock switch to the UNLOCK position, roll
down the window and open the door with the outside
door handle.

REMOTE KEYLESS ENTRY — IF EQUIPPED

This system allows you to lock or unlock the doors from
distances up to about 23 feet (7 meters) using a hand held
radio transmitter. The transmitter need not be pointed at
the vehicle to activate the system.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To unlock the doors:

Press and release the UNLOCK button on the key fob
once to unlock only the driver’s door or twice to unlock
all the doors. When the UNLOCK button is pressed, the
illuminated entry will initiate, the parking lights will
flash on twice and if installed, the cargo lamp will turn on
for 30 seconds.

The system can be programmed to unlock all the doors
upon the first UNLOCK button press by using the
following procedure:

1. Enter your vehicle and close all doors.

2. Fasten your seat belt.(Fastening the seat belt will
cancel any chiming that may confuse you during this
programming procedure).

3. Place the key into the ignition.

4. Turn the ignition to the ON position ( Do not start the
engine

5. Press and hold the UNLOCK button on a programmed
(i.e. functional) key fob.

6. Continue to hold the UNLOCK button, wait at least 4
seconds, but no longer than 10 seconds, then press and
hold the LOCK button.

7. When a single chime is heard, release both buttons.

8. Turn the ignition to the OFF position or wait 60
seconds.

9. To reactivate this feature, repeat the above steps.

10. If a chime is not heard, program mode was canceled
before the feature could be changed. If necessary, repeat
the above procedure.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To lock the doors:

Press and release the LOCK button on the transmitter to
lock all doors. If the ignition is OFF, when the doors are
locked, the parking lights will flash on once and the horn
will chirp once.

The horn chirp feature will be shipped from the assembly
plants activated. If desired this feature can be disabled by
using the following procedure:

1. Enter your vehicle and close all doors.

2. Fasten your seat belt (fastening the seat belt will cancel
any chiming that may confuse you during this program-
ming procedure).

3. Place the key into the ignition.

4. Turn the ignition to the ON position ( Do not start the
engine

5. Press and hold the LOCK button on a programmed
(i.e. functional) key fob.

6. Continue to hold the LOCK button, wait at least 4
seconds, but no longer than 10 seconds, then press and
hold the UNLOCK button.

7. When a single chime is heard, release both buttons.

8. Turn the ignition to the OFF position or wait 60
seconds.

9. Test the horn chirp feature by pressing the LOCK
button on the key fob with the ignition in the OFF
position, or the key removed.

10. To reactivate this feature, repeat the above steps.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Vehicles will be shipped from the assembly plants with
the park lamp flash feature activated. If desired, this
feature can be disabled by using the following procedure:

1. Enter your vehicle and close all doors.

2. Fasten your seat belt (fastening the seat belt will cancel
any chiming that may confuse you during this program-
ming procedure).

3. Place the key into the ignition.

4. Turn the ignition to the ON position ( Do not start the
engine

5. Press and hold the LOCK button on a programmed
(i.e. functional) key fob.

6. Continue to hold the LOCK button, wait at least 4
seconds, but no longer than 10 seconds, then press and
hold the PANIC button.

7. When a single chime is heard, release both buttons.

8. Turn the ignition to the OFF position or wait 60
seconds.

9. Test the park lamp flash feature by pressing the LOCK
button on the key fob with the ignition in the OFF
position or the key removed.

10. To reactivate this feature, repeat the above steps.

11. If a chime is not heard, program mode was canceled
before the feature could be disabled. If necessary, repeat
the above procedure.

Using the Panic Alarm

To activate the Panic mode while the ignition is OFF press
and release the PANIC button on the transmitter once.
When the Panic mode is activated, the interior lights will
illuminate, the headlamps and parking lights will flash,
and the horn will sound.

To cancel the Panic mode press and release the PANIC
button on the transmitter a second time. Panic mode will

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

automatically cancel after 3 minutes or if the vehicle is
started and exceeds 15 mph. During the Panic Mode, the
door locks and remote keyless entry systems will func-
tion normally. Panic mode will not disarm the security
system on vehicles so equipped.

Programming Additional Transmitters

Vehicles with the keyless entry option will be shipped
from the assembly plants with two key fob transmitters
programmed only for that vehicle. A total of four fobs can
be programmed for your vehicle. Additional fobs can be
programmed to your vehicle through the use of a cur-
rently programmed fob.

NOTE:

When entering program mode using that fob,

ALL currently programmed fobs will be erased and you
will have to reprogram them for your vehicle. However,
if program mode is entered and no action is performed,
the previously programmed fobs will continue to func-
tion.

1. Enter your vehicle and close all doors.

2. Fasten your seat belt (fastening the seat belt will cancel
any chiming that may confuse you during this program-
ming procedure).

3. Place the key into the ignition.

4. Turn the ignition to the ON position ( Do not start the
engine

5. Press and hold the UNLOCK button on a programmed
(i.e. functional) key fob.

6. Continue to hold the UNLOCK button, wait at least 4
seconds, but no longer than 10 seconds, then press and
hold the PANIC button.

7. When a single chime is heard, release both buttons.
The chime indicates that the system is in program mode.

8. Press and release both the LOCK and UNLOCK
buttons, simultaneously on the fob to be programmed.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

9. A single chime will be heard. The chime indicates that
the fob has been recognized.

10. Within 4 seconds of hearing the chime, press and
release any button on the fob being programmed.

11. A single chime will be heard. The chime indicates
that the fob has been programmed.

12. Repeat steps 8 to 11 for a total of 4 fobs.

13. Turn the ignition to the OFF position or wait 60
seconds to exit program mode.

14. Your vehicle will remain in program mode for up to
60 seconds from when the original chime (i.e. Step #7)
was heard. After 60 seconds, all programmed fobs will
function normally.

NOTE:

If you do not have a programmed transmitter,

contact your dealer for details.

General Information

This device complies with part 15 of FCC rules and with
RS-210 of Industry Canada. Operation is subject to the
following conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference that may be
received including interference that may cause undesired
operation.

NOTE:

Changes or modifications not expressly ap-

proved by the party responsible for compliance could
void the user’s authority to operate the equipment.

If your Keyless Entry Transmitter fails to operate from a
normal distance, check for these two conditions.

1. Weak batteries in transmitter. The expected life of the
batteries is from one to two years.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

2. Closeness to a radio transmitter such as a radio station
tower, airport transmitter, and some mobile or CB radios.

Transmitter Battery Service

The recommended replacement battery is a 3V lithium
2016 cell. This transmitter requires two batteries.

NOTE:

Do not touch the battery terminals that are on

the back housing or the printed circuit board.

1. With transmitter buttons facing down, use a flat blade
or dime to pry the two halves of the transmitter apart.
Make sure not to damage the rubber gasket during
removal.

2. Remove and replace the batteries. Be careful not to
disturb the metal terminal near the batteries. Install the
batteries with the positive terminal up, reference the note

9+ SIDE UP9 on the inside of the bottom half of the
transmitter case. Avoid touching the new batteries with
your fingers. Skin oils may cause battery deterioration. If
you touch a battery, clean it with rubbing alcohol.

3. To reassemble the transmitter case snap the two halves
together. Make sure there is an even gap between the two
halves. Test transmitter operation.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

SECURITY ALARM SYSTEM — IF EQUIPPED

This system monitors the vehicle doors and ignition for
unauthorized operation. When the alarm is activated, the
system provides both audible and visual signals. For the
first 3 minutes the horn will sound and the headlights
and security telltale will flash repeatedly. For an addi-
tional 15 minutes only the headlights and security telltale
will flash. The engine will run only if a valid Sentry Key
is used to start the vehicle. Use of the Sentry Key will
disable the alarm.

Rearming of the System:

The security system will rearm itself after the 15 addi-
tional minutes of headlights and security telltale flashing,
if the system has not been disabled. If the condition
which initiated the alarm is still present, the system will
ignore that condition and monitor the remaining doors
and ignition.

To Set the Alarm:

The alarm will set when you use the power door locks,
turn the key in the driver’s door lock cylinder, or use the
Keyless Entry transmitter to lock the doors. After all the
doors are locked and closed the SECURITY light in the
instrument cluster will flash rapidly to signal that the
system is arming. The security light in the instrument
panel cluster will flash rapidly for about 16 seconds to
indicate that the alarm is being set. After the alarm is set,
the security light will flash at a slower rate to indicate
that the system is armed.

NOTE:

If the SECURITY light stays on continuously

during vehicle operation, have the system checked by
your dealer.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To Disarm the System:

Use the Keyless Entry transmitter or the key to turn the
driver’s door lock to the unlock position. If something
has triggered the system in your absence, the horn will
sound three times when you unlock the doors and the
security lamp will flash for 30 seconds. Check the vehicle
for tampering.

The Security system will also disarm, if the vehicle is
started with a programmed Sentry Key. If an unpro-
grammed Sentry Key is used to start a vehicle, the engine
will run for 2 seconds and then the security alarm will be
initiated. To exit alarming mode, press the transmitter
Unlock button, unlock the driver’s door using the key
cylinder, or start the vehicle with a programmed Sentry
Key.

The Security Alarm System is designed to protect your
vehicle; however, you can create conditions where the
system will arm unexpectedly. If you remain in the
vehicle and lock the doors with the transmitter, the alarm
will sound when you pull the door handle to exit. You
may also accidentally disarm the system by unlocking
the driver’s door with the door key and then locking it
manually with the lock plunger. The door will be locked
but the Security Alarm will not arm.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WINDOWS

Power Windows—If Equipped

The control on the left front door panel has up-down
switches that give you fingertip control of all power
windows. There is a single opening and closing switch on
the front passenger door for passenger window control
and on the rear doors of Quad Cab models. The windows
will operate only when the ignition switch is turned to
the ON or ACC (Accessory) position.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Auto Down (Driver’s Side Only)
The driver’s window switch has an Auto Down feature.
Press the window switch past the detent, release, and the
window will go down automatically.

Window Lockout Switch (4 Door Models Only)
The window lockout switch on the driver’s door allows
you to disable the window control on the other doors. To
disable the window controls on the other doors, press the
window lock button. To enable the window controls,
press the window control button again.

Sliding Rear Window—If Equipped

A locking device in the center of the window helps to
prevent entry from the rear of the vehicle. Squeeze the
lock to release the window.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WIND BUFFETING

Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down or partially open positions. This is a
normal occurrence and can be minimized. If the buffeting
occurs with the rear windows open, open the front and
rear windows together to minimize the buffeting.

OCCUPANT RESTRAINTS

Some of the most important safety features in your
vehicle are the restraint systems. These include the front
and rear seat belts for the driver and all passengers, front
airbags for both the driver and front passenger and, if so
equipped, window bags for the driver and passengers
seated next to a window. If you will be carrying children
too small for adult-size belts, your seat belts also can be
used to hold infant and child restraint systems.

Please pay close attention to the information in this
section. It tells you how to use your restraint system
properly to keep you and your passengers as safe as
possible.

WARNING!

In a collision, you and your passengers can suffer
much greater injuries if you are not properly buck-
led up. You can strike the interior of your vehicle or
other passengers, or you can be thrown out of the
vehicle. Always be sure you and others in your
vehicle are buckled up properly.

Buckle up even though you are an excellent driver, even
on short trips. Someone on the road may be a poor driver
and cause a collision that includes you. This can happen
far away from home or on your own street.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Research has shown that seat belts save lives, and that
they can reduce the seriousness of injuries in a collision.
Some of the worst injuries happen when people are
thrown from the vehicle. Seat belts reduce the possibility
of ejection and the risk of injury caused by striking the
inside of the vehicle. Everyone in a motor vehicle should
be belted at all times.

Lap/Shoulder Belts

All seating positions except the Quad Cab front center
seating position have combination lap/shoulder belts.
The belt webbing retractor is designed to lock during
very sudden stops or collisions. This feature allows the
shoulder part of the belt to move freely with you under
normal conditions. But in a collision, the belt will lock
and reduce the risk of your striking the inside of the
vehicle or being thrown out.

WARNING!

It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.

Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.

Be sure everyone in your vehicle is in a seat and
using a seat belt properly.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

• Wearing a seat belt incorrectly is dangerous. Seat

belts are designed to go around the large bones of
your body. These are the strongest parts of your
body and can take the forces of a collision the
best. Wearing your belt in the wrong place could
make your injuries in a collision much worse. You
might suffer internal injuries, or you could even
slide out of part of the belt. Follow these instruc-
tions to wear your seat belt safely and to keep
your passengers safe, too.

• Two people should never be belted into a single

seat belt. People belted together can crash into one
another in an accident, hurting one another badly.
Never use a lap/shoulder belt or a lap belt for
more than one person, no matter what their size.

Lap/Shoulder Belt Operating Instructions

1. Enter the vehicle and close the door. Sit back and
adjust the seat.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Dodge Diesel (2004 year). Manual - part 2
