Emergency running function The transmission effects will be: • The last gear shifted remains in that position • The modulating pressure and shift pressure in- • The torque converter clutch is disengaged (turned off) Shifting manually after a DTC detection NOTE: The vehicle can still be shifted To accomplish these shifts you must Stop the vehicle 3.3.3 TROUBLE CODE ERASURE Diagnostic Trouble Codes can be erased in two ways. The first is to erase the DTC with the DRBIII When there are no diagnostic trouble codes t will display (NO DTC’s DETECTED( 3.4 USING THE DRBIII T Refer to the DRBIII t user’s guide for instructions and assistance with reading trouble codes, erasing t functions. 3.5 DRBIII T ERROR MESSAGES Under normal operation, the DRBIII t will display one of only two error messages: – User-Requested WARM Boot – User-Requested COLD Boot If the DRBIII t should display any other error message, record the entire display and call the 3.5.1 DRBIII T DOES NOT POWER UP (BLANK SCREEN) If the LED’s do not light or no sound is emitted at start up, check for loose cable connections or a bad t. If all connections are proper between the DRBI- II t and the vehicle or other devices, and the vehicle battery is fully charged, an inoperative DRBIII t may be the result of faulty cable or vehicle wiring. 3.5.2 DISPLAY IS NOT VISIBLE Low temperatures will affect the visibility of the display. Adjust the contrast to compensate for this 4.0 DISCLAIMERS, SAFETY, 4.1 DISCLAIMERS All information, illustrations, and specifications contained in this manual are based on the latest 5 GENERAL INFORMATION |
