(8) Reconnect the battery negative cable. REMOVAL WARNING: To avoid personal injury or death, on restraint system before attempting any steering wheel, steering column, airbag, seat belt (1) Disconnect and isolate the battery negative cable. (2) Unsnap the base covers from each other and remove them from the rear view mirror arm at the (3) Using a small thin-bladed screwdriver, gently pry the retaining collar slightly upward while press- (4) Separate and remove the two halves of the wire cover from the rain sensor pigtail wires. (5) Loosen the screws securing both inner sun visor hinges to the windshield header. (6) Pull the headliner down from the windshield header far enough to pull the rain sensor pigtail wire (7) Remove the anti-rattle felt from the wire con- nector insulators. (8) Disconnect the sensor pigtail wire connector from the roof wire harness connector. CAUTION: Do not touch the gel-like surface of the (9) Remove the rain sensor from the center of the bracket. INSTALLATION WARNING: To avoid personal injury or death, on restraint system before attempting any steering wheel, steering column, airbag, seat belt CAUTION: Do not touch the gel-like surface of the (1) Position the rain sensor into the center of the bracket on the windshield (Fig. 10). (2) Reconnect the sensor pigtail wire connector to the roof wire harness connector. (3) Reinstall the anti-rattle felt over the wire con- nector insulators. (4) Pull the headliner down from the windshield header far enough to tuck the rain sensor pigtail (5) Tighten the screws securing both inner sun visor hinges to the windshield header. (6) Align and install the two halves of the wire cover over the rain sensor pigtail wires. (7) Press the rear view mirror arm upward paral- lel to the windshield until the mirror arm snaps onto (8) Align and position the base covers to each other and snap them over the rear view mirror arm (9) Reconnect the battery negative cable. Fig. 10 Rain Sensor Remove/Install 1 - FELT 8R - 14 WIPERS/WASHERS VA |
