3. Install the power steering hoses. Tighten to 27 N.m (20 ft.lbs.).
4. Install the serpentine belt. Refer to INSTALLATION .
5. Refill the power steering fluid and check for leaks. See STANDARD PROCEDURE.
POWER STEERING PUMP - 4.0L ENGINE
Fig. 97: Identifying Power Steering Belt, Pressure Line & Power Steering Pump Mounting Bolts
Courtesy of CHRYSLER LLC
1. Install power steering pump back in engine compartment using reverse order of its removal.
2. Install three power steering pump mounting bolts (3) through pulley. Tighten pump mounting bolts to 28
N.m (21 ft. lbs.).
3. Install pressure line (2) into pump. Thread pressure line tube nut into pump and tighten to 27 N.m (20 ft.
lbs.).
4. Install return line into the reservoir.
5. Install power steering belt (1). Refer to INSTALLATION .
6. Install the fan shroud.
7. Install the washer/coolant reservoir assembly.
8. Install air cleaner housing. Refer to INSTALLATION .
9. Fill and bleed power steering system. See STANDARD PROCEDURE.
10. Inspect for leaks.
SPECIFICATIONS
TORQUE SPECIFICATIONS
NOTE:
Before installing power steering pressure hose on power steering pump,
replace O-ring on end of power steering pressure hose. Lubricate O-ring
using clean power steering fluid.
2007 Dodge Nitro R/T
2007 STEERING Steering System - Nitro
