Dodge Nitro. Manual - part 893

Fig. 7: Knee Blocker
Courtesy of CHRYSLER LLC

5. Remove steering column opening cover, refer to REMOVAL .



2007 Dodge Nitro R/T

2007 STEERING Steering System - Nitro



Fig. 8: Removing/Installing Shroud
Courtesy of CHRYSLER LLC

6. Remove screws from the lower column shroud (2) and remove both the upper and lower shrouds. See

Fig. 8.

1 - Upper Shroud
2 - Lower Shroud



2007 Dodge Nitro R/T

2007 STEERING Steering System - Nitro



Fig. 9: Steering Column Bolts
Courtesy of CHRYSLER LLC

7. Turn ignition key to the on position.

8. If vehicle is equipped with automatic transmission, disconnect shifter interlock cable from the column.

9. Remove the steering coupler bolt and column mounting nuts (2) then lower column (1) off the mounting

studs.



2007 Dodge Nitro R/T

2007 STEERING Steering System - Nitro



Fig. 10: Identifying Wiring Harness Column, Multi-Function Switch, Ignition Switch & Steering
Column
Courtesy of CHRYSLER LLC

10. Disconnect and remove the wiring harness (1) from the column. See Fig. 10.

11. Slide the shifter interlock cable from the tie straps.

1 - Column Wiring Harness
2 - Multi-function Switch
3 - Ignition Switch
4 - Steering Column



2007 Dodge Nitro R/T

2007 STEERING Steering System - Nitro
