6. If quick connect fitting is damaged or leaking at transmission oil cooler or transmission, remove fitting.

CONNECT

Fig. 104: Oil Cooler Line Quick Connect Fitting - Assembly
Courtesy of CHRYSLER LLC

1. If removed, install quick connect fitting into transmission oil cooler or transmission. Tighten fitting to 15

N.m (132 in. lbs.).

2. Align transmission cooler line (3) with quick connect fitting while pushing straight into the fitting.

3. Push in on transmission cooler line until a "click" is heard or felt.

4. Slide dust cap (4) down the transmission cooler line and snap it over the quick connect fitting until it is

fully seated and rotates freely. Dust cap will only snap over quick connect fitting when the transmission
cooler line is properly installed.

1 - QUICK CONNECT FITTING
2 - CLIP
3 - OIL COOLER LINE
4 - DUST CAP

NOTE:

If dust cap will not snap into place, repeat assembly step #2.



2007 Dodge Nitro R/T

2007 ENGINE Cooling - Nitro



2007 ACCESSORIES AND EQUIPMENT

Speed Control - Nitro

SPEED CONTROL

SWITCH

REMOVAL

REMOVAL

Fig. 1: Speed Control Switch
Courtesy of CHRYSLER LLC

Mounting hole (1) uses a screw. Depending on model line, mounting holes (2) may use either two screws, or
one screw and a locating pin.

The speed control switch is mounted in the steering wheel and wired through the clock spring device under the
airbag module.

1. Adjust steering wheel until tires are in STRAIGHT-AHEAD position.

WARNING:

Do not place a non-deployed airbag face down on a hard surface as
the airbag will propel into the air if accidentally deployed, and could
result in serious or fatal injury.

Disconnect and isolate the battery negative (ground) cable before
beginning steering wheel removal or installation. This will disable
the front airbag system. Failure to disconnect the battery could
result in accidental front airbag module deployment and possible
personal injury.

Allow the front airbag system capacitor to discharge for two minutes
before removing the steering wheel or any front airbag system
component.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Speed Control - Nitro





2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Speed Control - Nitro



2. Remove negative battery cable.

3. Turn off ignition.

4. Remove air bag. Refer to REMOVAL .

Fig. 2: Horn Switch
Courtesy of CHRYSLER LLC

5. Disconnect connector from clockspring.

6. Remove three mounting fasteners.

7. Remove horn switch.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Speed Control - Nitro



Fig. 3: Speed Control Switch Mounting Screws
Courtesy of CHRYSLER LLC

8. Remove either two or three speed control switch mounting screws (1).

9. Disconnect electrical connector.

10. Remove switch.

INSTALLATION

INSTALLATION
