Dodge Nitro. Manual - part 450

Fig. 455: Removing/Installing Seat Weight Sensor
Courtesy of CHRYSLER LLC

1. Remove the passenger or drivers front seat, see REMOVAL.

2. Remove the seat weight sensors if equipped, passenger seat only, refer to REMOVAL .

WARNING:

Before proceeding with the following repair procedure, review all
warnings and cautions. See WARNING.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 456: Occupant Classification Module
Courtesy of CHRYSLER LLC

3. Disconnect the electrical connectors and remove the occupant classification module, refer to

REMOVAL .

Fig. 457: OCS Electrical Connectors
Courtesy of CHRYSLER LLC

4. Remove the electrical harness connectors from the OCS mounting plate.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 458: Heated Seat Element Electrical Connectors
Courtesy of CHRYSLER LLC

5. Remove the electrical connectors for both the heated seat back and seat elements.

Fig. 459: Passenger Outer Trim Screws
Courtesy of CHRYSLER LLC

6. Remove the recliner handle.

7. Remove the two screws from the side of the outer seat trim.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 460: Rear Seat Screws
Courtesy of CHRYSLER LLC

8. Remove the two screws from the rear of the outer seat trim and remove the trim panel.

9. Remove the seat position sensor.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro
