Dodge Nitro. Manual - part 439

Fig. 402: Rear Door Scuff Plate
Courtesy of CHRYSLER LLC

1. Align the trim clips and use hand pressure to install the scuff plate (1) to the body (2).

2. Close the lift gate.

SUPPORT - SUN VISOR

REMOVAL

SUPPORT - SUN VISOR



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 403: Removing/Installing Sun Visor Support
Courtesy of CHRYSLER LLC

1. Disengage the sun visor (1) from the sun visor support (2).

2. Remove the screw that secures the support to the roof panel and remove the support from the headliner

(3).

INSTALLATION

SUPPORT - SUN VISOR



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 404: Removing/Installing Sun Visor Support
Courtesy of CHRYSLER LLC

1. Position the sun visor support (2) on the headliner (3) and install the screw that secures the support to the

roof panel.

2. Engage the sun visor (1) and sun visor support.

VISOR - SUN

REMOVAL

VISOR - SUN



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 405: Removing/Installing Sun Visor
Courtesy of CHRYSLER LLC

1. Remove the two screws and remove the sun visor (2) from the headliner/roof assembly (1).

2. If equipped, disconnect the illuminated vanity mirror wire harness connector.

INSTALLATION

VISOR - SUN



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro
