TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS
DESCRIPTION
SPECIFICATION
Front Disc Brake Rotor Diameter
302 x 28 mm (11.9 x 1.1 in)
Rear Disc Brake Rotor Diameter
316 x 12 mm (12.04 x 0.472 in)
Front Ventilated Disc Brake Rotor
Max. Runout 0.020 mm (0.001 in.)
Rear Solid Disc Brake Rotor
Max. Runout 0.020 mm (0.001 in.)
Front Ventilated Disc Brake Rotor
Max. Thickness Variation 0.009 mm (0.0004 in.)
Rear Solid Disc Brake Rotor
Max. Thickness Variation 0.009 mm (0.0004 in.)
Front Ventilated Disc Brake Rotor
Min. Thickness 26.4 mm (1.039 in.)
Rear Solid Disc Brake Rotor
Min. Thickness 10.4 mm (0.409 in.)
Disc Brake Calipers
Single piston floating
Brake Booster
Dual Diaphragm
DESCRIPTION
N.m
Ft. Lbs.
In. Lbs.
Brake Booster Mounting
Nuts
25
-
220
Brake Pedal Shaft to
Steering Column Support
Bracket Nut & Washer
Assembly
22.6
-
200
Master Cylinder
Mounting Nuts
25
-
220
Master Cylinder Brake
Lines
20
15
180
ESP Module Bolt
10
-
85
ESP Module Nut
10
-
85
Front Caliper Adapter
Mounting Bolts
136
100
-
Front Caliper to Adapter
Mounting Bolts
37
28
-
Rear Caliper Adapter
Mounting Bolts
102
75
-
Rear Caliper to Adapter
Mounting Bolts
37
28
-
Front Caliper Brake Hose
Banjo Bolt
31
23
-
Rear Caliper Brake Hose
Banjo Bolt
31
23
-
Parking Brake Lever Nuts
16
-
140
Parking Brake Lever
Bracket Screws
10-14
7-10
-
