Fig. 14: Locating Input Speed, Output Speed and Transmission Range Sensors
Courtesy of CHRYSLER LLC

4. Mark propeller shaft and axle companion flanges for assembly alignment.

5. Remove the rear propeller shaft. Refer to REMOVAL .

6. Remove the front propeller shaft, if necessary. Refer to REMOVAL .

7. Disconnect wires from the input and output speed sensors (1, 2).

8. Disconnect wires from the transmission range sensor (3).

9. Disconnect wires from the Variable Line Pressure (VLP) electrical connector.

1 - INPUT SPEED SENSOR
2 - OUTPUT SPEED SENSOR
3 - TRANSMISSION RANGE SENSOR

2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro

Fig. 15: Identifying Solenoid/Pressure Switch Assembly
Courtesy of CHRYSLER LLC

10. Disconnect wires from the solenoid/pressure switch assembly (1). See Fig. 15.

1 - SOLENOID/PRESSURE SWITCH ASSEMBLY
CONNECTOR

2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro

Fig. 16: Removing/Installing Exhaust Flange Bolts
Courtesy of CHRYSLER LLC

11. Remove the bolts (1) holding the exhaust crossover pipe to the pre-catalytic converter pipe flanges. See

Fig. 16.

12. Remove the bolts holding the exhaust crossover pipe to the catalytic converter flange.

1 - EXHAUST FLANGE BOLTS

2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro

Fig. 17: Rear Transmission Mount & Crossmember
Courtesy of CHRYSLER LLC

13. Disconnect gearshift cable from transmission manual valve lever.

14. Disengage the shift cable from the cable support bracket.

15. Remove the starter motor.

16. Remove the engine to transmission collar.

17. Rotate crankshaft in clockwise direction until converter bolts are accessible. Then remove bolts one at a

time. Rotate crankshaft with socket wrench on dampener bolt.

1 - CROSSMEMBER
2 - REAR TRANSMISSION MOUNT

2007 Dodge Nitro R/T

2007 AUTOMATIC TRANSMISSION 42RLE - Service Information - Nitro
