Fig. 97: Measuring Resistance Of (X205) Amplified Left Rear Speaker (+) Circuit Between Turn the ignition off. Disconnect the Amplifier C2 harness connector. Measure the resistance of the (X205) Amplified Left Rear Speaker (+) circuit between the Amplifier C2 Is the resistance below 5.0 ohms? Yes Go to 4). No Repair the (X205) Amplified Left Rear Speaker (+) circuit for an open.
2007 Dodge Nitro R/T 2007 ACCESSORIES AND EQUIPMENT Audio/Video Systems - Electrical Diagnostics - Nitro
|
