1. Disconnect the battery negative cable.

2. Drain cooling system. Refer to STANDARD PROCEDURE .

3. Remove electric cooling fan and fan shroud assembly.

4. Remove fan and fan drive assembly.

5. Disconnect both heater hoses at timing cover.

6. Disconnect lower radiator hose at engine.

7. Remove accessory drive belt tensioner assembly (1). See Fig. 181.

Fig. 182: Timing Chain Cover Fastener Tightening Sequence
Courtesy of CHRYSLER LLC

8. Remove crankshaft damper. See REMOVAL.

9. Remove the generator. Refer to REMOVAL .

10. Remove the A/C compressor. Refer to REMOVAL .



2007 Dodge Nitro R/T

2007 ENGINE 3.7L - Service Information - Nitro



11. Remove the bolts holding the timing cover to engine block. See Fig. 182

12. Remove the timing cover.

INSTALLATION

TIMING CHAIN COVER

CAUTION: The 3.7L engine uses an anaerobic sealer instead of a gasket to seal

the front cover to the engine block, from the factory. For service,
Mopar® Grey Engine RTV sealant must be substituted.

NOTE:

It is not necessary to remove the water pump for timing cover removal.



2007 Dodge Nitro R/T

2007 ENGINE 3.7L - Service Information - Nitro



Fig. 183: Timing Cover, Water Passage O-ring & Mopar® Engine RTV Sealer
Courtesy of CHRYSLER LLC

1. Clean timing chain cover and block surface using rubbing alcohol.

2. Inspect the water passage o-rings for any damage, and replace as necessary.

3. Apply Mopar® Grey Engine RTV sealer (3) to the front cover following the path below, using a 3 to

4mm thick bead. See Fig. 183.

1 - TIMING CHAIN COVER
2 - WATER PASSAGE ORING
3 - MOPAR® ENGINE RTV SEALER

CAUTION: Do not use oil based liquids to clean timing cover or block surfaces. Use

only rubbing alcohol, along with plastic or wooden scrapers. Use no wire
brushes or abrasive wheels or metal scrapers, or damage to surfaces
could result.

CAUTION: The 3.7L uses a special anaerobic sealer instead of a gasket to seal

the timing cover to the engine block, from the factory. For service
repairs, Mopar® Grey Engine RTV must be used as a substitute.



2007 Dodge Nitro R/T

2007 ENGINE 3.7L - Service Information - Nitro



Fig. 184: Timing Chain Cover Fastener Tightening Sequence
Courtesy of CHRYSLER LLC

4. Install cover. Tighten flange head fasteners in sequence shown to 58 N.m (43 ft. lbs.). See Fig. 184.

5. Install crankshaft damper. See INSTALLATION.

6. Install the A/C compressor. Refer to INSTALLATION .

7. Install the generator. Refer to INSTALLATION .

8. Install accessory drive belt tensioner assembly. Refer to INSTALLATION .

9. Install radiator upper and lower hoses.

10. Install both heater hoses.

11. Install electric fan shroud and viscous fan drive assembly.

12. Fill cooling system. Refer to STANDARD PROCEDURE .

13. Connect the battery negative cable.

SHAFT-IDLER
