Fig. 134: Transmission Mount - 2.4L Manual Trans
Courtesy of CHRYSLER LLC

1 - TRANSMISSION MOUNT
2 - MOUNTING BOLT



2007 Dodge Nitro R/T

2007 ENGINE 3.7L - Service Information - Nitro



Fig. 135: Transmission Mount - 3.7L Manual Trans 2WD
Courtesy of CHRYSLER LLC

1. Install the transmission mount (1) to the transmission. Install the bolts (2) and tighten.

2. Position the crossmember in the vehicle. Install the crossmember to mount through bolt and nut.

3. Install crossmember-to-sill bolts and tighten to 41 N.m (30 ft. lbs.)

1 - NUT
2 - BOLT
3 - TRANS MOUNT



2007 Dodge Nitro R/T

2007 ENGINE 3.7L - Service Information - Nitro



4. Remove the transmission support.

5. Lower the vehicle.

6. Connect negative cable to battery.

AUTOMATIC TRANSMISSION:

Fig. 136: Transmission Mount - 3.7L 2WD Auto Trans
Courtesy of CHRYSLER LLC

1 - BOLT
2 - MOUNT



2007 Dodge Nitro R/T

2007 ENGINE 3.7L - Service Information - Nitro



Fig. 137: Transmission Mount - 3.7L 4WD Auto Trans
Courtesy of CHRYSLER LLC

1. Install the transmission mount to transmission and See Fig. 136 and Fig. 137. Install the bolts.

2. Position the crossmember in the vehicle. Install the crossmember to mount through bolt and nut.

3. Remove the transmission support.

4. Lower the vehicle.

5. Connect negative cable to battery.

1 - MOUNT
2 - BOLT
