SPECIAL TOOLS

3.7L ENGINE

Fig. 18: Spanner Wrench 6958
Courtesy of CHRYSLER LLC

Timing Chain Guide Bolts

28

-

250

Timing Chain Tensioner Arm Bolt

28

-

250

Hydraulic Tensioner Bolts

28

-

250

Timing Chain Primary Tensioner Bolts

28

-

250

Timing Drive Idler Sprocket Bolt

34

25

-

Thermostat Housing Bolts

12

-

105

Water Pump Bolts

58

43

-



2007 Dodge Nitro R/T

2007 ENGINE 3.7L - Service Information - Nitro



Fig. 19: Adapter Pins 8346
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 ENGINE 3.7L - Service Information - Nitro



Fig. 20: Front Crankshaft Seal Remover 8511
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 ENGINE 3.7L - Service Information - Nitro



Fig. 21: Front Crankshaft Seal Installer 8348
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 ENGINE 3.7L - Service Information - Nitro
