6. Place a piece of paper approximately 22 by 28 centimeters (8.5 by 11 inches), oriented on the vehicle lengthwise from front to rear, on the center line of the roof at the windshield header. The purpose of the paper is to protect 7. Connect the degaussing tool to an electrical outlet, while keeping the tool at least 61 centimeters (2 feet) away from the compass unit. 8. Slowly approach the center line of the roof panel at the windshield header, with the degaussing tool connected. 9. Contact the roof panel with the plastic coated tip of the degaussing tool. Be sure that the template is in place to avoid scratching the roof panel. Using a slow, back-and-forth sweeping motion, and allowing 13 millimeters (0.50 10. With the degaussing tool still energized, slowly back it away from the roof panel. When the tip of the tool is at least 61 centimeters (2 feet) from the roof panel, disconnect the tool. 11. Calibrate the compass and adjust the compass variance. Refer to Compass Variation Adjustment and Com- pass Calibration in the Service Procedures section of this group for the procedures. REMOVAL OVERHEAD CONSOLE 1. Disconnect and isolate the battery negative cable. 2. Insert the fingertips of both hands between the headliner and the sides of the overhead console HB OVERHEAD CONSOLE - SERVICE INFORMATION 8M - 25 |
