B140B-REAR LEFT AUDIO SPEAKER OUTPUT CIRCUIT OPEN (CONTINUED) 3. Speaker Turn the ignition off. Disconnect the Rear Left Audio Speaker. Turn the ignition on. Turn the Radio on. With the Scan Tool, clear all Audio DTC’s. With the Scan Tool, read the DTC information. Does the Scan Tool read: B140B-REAR LEFT AUDIO SPEAKER OUTPUT CIRCUIT OPEN? Yes >> Replace the Speaker in accordance with the service information. Perform the BODY VERIFICATION TEST VER 1. No >> Test Complete. HB AUDIO/VIDEO SYSTEMS - ELECTRICAL DIAGNOSIS 8A - 29 |
