1D2-16 M161 ENGINE COOLING Removal & Installation Procedure 1. Drain coolant from the radiator. 2. Remove the coolant thermo connector from the radiator. 3. Remove the each coolant hoses. Tightening Torque 14 Nm 4. Remove the automatic transmission oil cooling hose. Installation Notice 5. Unscrew the bolts from radiator bracket and remove the bracket and insulator. Installation Notice Tightening Torque 3 - 7 Nm 6. Remove the radiator upper mounting bolts and then remove the bracket and insulator. 7. Remove the radiator. 8. Check the radiator pin for crack, damage, leakage and bending and replace if necessary. 9. Installation should follow the removal procedure in the reverse order. 10. Berform the cooling system leakage test. |
