200423
1
Contents
STEERED TRAILING SWIVEL AXLE
ΧΦ65/75/85 series
7
7
7 Steered trailing swivel axle
CONTENTS
Page
Date
1.
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 . . . . . 200423
1.1
Overview drawing, wheel hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 . . . . . 200423
1.2
Overview drawing, swivel axle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 . . . . . 200423
1.3
Description of wheel hub unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 . . . . . 200423
1.4
Description of wheel settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 . . . . . 200423
2.
INSPECTION AND ADJUSTMENT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1 . . . . . 200423
2.1
Inspection and adjustment, swivel axle play . . . . . . . . . . . . . . . . . . . . . . . 2-1 . . . . . 200423
2.2
Inspection and adjustment, caster. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5 . . . . . 200423
2.3
Inspection of camber angle and king pin inclination . . . . . . . . . . . . . . . . . 2-6 . . . . . 200423
2.4
Inspection and adjustment, toe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7 . . . . . 200423
2.5
Inspection and adjustment, alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9 . . . . . 200423
2.6
Inspection of the steering ball joint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12 . . . . 200423
2.7
Inspection of axle housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14 . . . . 200423
2.8
Inspection of wheel rim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16 . . . . 200423
3.
REMOVAL AND INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 . . . . . 200423
3.1
Removal and installation, wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 . . . . . 200423
3.2
Removal and installation, track rod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5 . . . . . 200423
3.3
Removal and installation, track rod arm and steering cylinder arm . . . . . . 3-6 . . . . . 200423
3.4
Removal and installation, wheel hub unit . . . . . . . . . . . . . . . . . . . . . . . . . 3-8 . . . . . 200423
3.5
Removal and installation, swivel axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11 . . . . 200423
3.6
Removal and installation, thrust bearing, split version. . . . . . . . . . . . . . . . 3-15 . . . . 200423
3.7
Removal and installation, thrust bearing, assembled version . . . . . . . . . . 3-17 . . . . 200423
3.8
Removal and installation, needle bearings . . . . . . . . . . . . . . . . . . . . . . . . 3-18 . . . . 200423
