CF65/75/85 series
Changes in the electrical system from chassis number 0E608863
CHANGES IN THE ELECTRICAL SYSTEM
3-1
3. CHANGES IN THE ELECTRICAL SYSTEM FROM CHASSIS
NUMBER 0E608863
3.1 OVERVIEW OF THE CHANGES IN THE ELECTRICAL SYSTEM
Section
diagram
Electrical system
Changes
From chassis
number
B
Overview of earthing
points
Various earthing points changed.
0E608863
C
CAN overview
Various connectors changed.
0E608863
2
Ignition/starter switch/
charging circuit
Various connectors and wire markings
changed.
0E608863
3
MTCO tachograph
Various connectors and wire markings
changed.
0E608863
8
VIC
Clutch protection added.
0E608863
Various connectors and wire markings
changed.
11
UPEC
Relay G469 added.
Wire 3435 withdrawn.
0E608863
18
Interior lighting, SH cab
Connector 610 changed to 570.
0E608863
22
Seat heating/accessories
Connector A038 added.
0E608863
23
Horn/cigar lighter/work
lamp/air dryer
Various connectors changed.
Wire 1103 added.
0E608863
24
ABS-ASC-D
Various connectors changed.
0E608863
29
EMAS
Connector 692 changed to 555.
0E608863
31
FAG
Connector 652 changed to 393.
0E608863
34A
ECAS-3 (4x2)
Various connectors changed.
0E608863
34B
ECAS-2 (6x2)
Various connectors changed.
0E608863
38
Mechanical lifting gear
Connector 878 changed to 568.
0E608863
39
Fuel pre-heating
Value of fuse E164 changed to 30 A.
0E608863
40
Windscreen wipe/
wash system
Connector 402 changed to 911.
0E608863
