10 46 ALARM SYSTEM/BA TTER Y CHARGER FOR B V3 ALARM SYSTEM SEE THE SYSTEM MANUAL FOR M ORE INFORMA T ION VARIANTS Location 18 Wire 4004: fitted if NO alarm syst em inst alled. 23 G185: only for AS Tr onic. 49, 57 NOT fit te do nH 1v er si on 64 For m ore information on D783, see section diagram 17 & 18. 60, 69, 71 NOT fitted on BV02 vers ion. 90 -> 95 Connector 873 on vehicle ty pe FA . Connector 874 on vehicle ty pe FT . 90 -> 95 Connector A 001: on vehicle ty pe FA . Connector A 003 on vehicle ty pe FT . 105 Only on vehicle type FA. 11 5 C onnection for F 686 (this is optional). Only applies to an SL cab and for versions BV2, BV3 or H1. Only applies to S L cab. NOT fit te do nH 1v er si on 153 D931: only if NO alarm syst em fitted. 154 E035: only if NO alarm syst em fitted. 157 E023: only if NO alarm syst em fitted. 200404 2-188 5 ELECTRICAL SYSTEM Electrical system CF65/75/85 series ≥0E621376 |
