DAF CF65, CF75, CF85 Series . Manual - part 430

©

 200416

5-29

Removal and installation

CE ENGINE FUEL SYSTEM

ΧΦ65/75/85 series

4

2

Low-pressure fuel pipes fitted with John
Guest quick-release couplings

Removing low-pressure fuel pipes
1.

Disconnect the fuel pipe by pressing in both
lips of the quick-release coupling and
removing the pipe from the quick-release
coupling.

2.

Plug the openings.

Fitting low-pressure fuel pipes
1.

Clean the quick-release coupling parts.

2.

Fit the pipe on the quick-release coupling of
the component and push the pipe onto it until
a clear resistance can be felt and the quick-
release coupling audibly clicks.

3.

Bleed the fuel system. See "Inspection and
adjustment".

4.

Start the engine and check the fuel system
for leaks.

CE ENGINE FUEL SYSTEM

5-30

©

 200416

Removal and installation

2

ΧΦ65/75/85 series

4

©

 200416

6-1

Cleaning

CE ENGINE FUEL SYSTEM

ΧΦ65/75/85 series

4

2

6. CLEANING

6.1 CLEANING INJECTOR

The injector must never be cleaned
with a steel brush or pressure
cleaning equipment. Never put the
brush in the injector bores when
cleaning the exterior of the injector
nozzle. If this happens, the nozzle
must be replaced.
Before cleaning the nozzle, cover the
injector bores. Only clean the
injector with a brass hand brush.

Note:
The use of steel brushes can cause deformation
of the injector bores, with the result that the wrong
amount of fuel is injected.
This deformation cannot be ascertained by
measurements or checks.

Note:
The disassembly and assembly of injectors is not
permitted. Only external cleaning is permitted.

1.

Remove the injector. See "Removal and
installation".

2.

Clean the injector hole in the cylinder head.
The metal surface of the hole must not be
damaged.

}

M2 00 040

CE ENGINE FUEL SYSTEM

6-2

©

 200416

Cleaning

2

ΧΦ65/75/85 series

4

3.

Wipe the exterior of the injector with a clean,
lint-free cloth. In the case of heavy soiling the
injector may be cleaned carefully with a
brass hand brush (not the apertures in the
injector nozzle!).

4.

Fit the injector. See "Removal and
installation".
