DAF CF65, CF75, CF85 Series . Manual - part 1186

©

 200423

1-1

Maintenance intervals

MAINTENANCE SCHEDULE

ΧΦ85 series

4

1. MAINTENANCE INTERVALS

1.1 MAINTENANCE SCHEDULE

The service intervals stated in the
maintenance schedule are based on use of
the oils and fuels specified by DAF.

+

+

Maintenance

 schedule

CF85

1x per YEAR

G000234

Intermediate  X service

 Y service

30.000 km

50.000 km

75.000 km

30.000 km

50.000 km

60.000 km

60.000 km

100.000 km

1 year

max. 100.000 km

1 year

max. 100.000 km

1 year

max. 150.000 km

3 year

max. 180.000 km

3 year

max. 300.000 km

3 year

max. 450.000 km

1 year

max. 100.000 km

1 year

max. 100.000 km

1 year

max. 200.000 km

2 year

max. 120.000 km

3 year

max. 300.000 km

3 year

max. 450.000 km

120.000 km

inspection

Ext.

Ext.

Ext.

(3)

(2)

(1)

(1)

(1)

Extended changing intervals not permitted on
1354 and 1355(T) rear axles.

(2)

1 year/maximum 100,000 km for:
- 1132(T), 1354 and 1355(T) rear axles

(3)

Extended changing intervals not permitted on 1354
and 1355(T) rear axles.
3 years/maximum 300,000 km for:
- 1132(T) rear axle

MAINTENANCE SCHEDULE

1-2

©

 200423

Maintenance intervals

4

ΧΦ85 series

1.2 EXPLANATORY NOTES ON THE MAINTENANCE SCHEDULE

Maintenance group classification
Depending on the use to which the vehicle is put,
the vehicle is placed in maintenance group I, II or
III.

Maintenance group I
Operation on building sites, in quarries, etc.

-

Operation on unmetalled roads

-

Traffic in dusty conditions

-

Sanitation department vehicles

-

Distribution transport with an annual mileage
up to 30,000 km.

Maintenance group II
Urban and regional transport

-

Distribution traffic in urban areas

-

Traffic between adjacent villages/cities

Maintenance group III
(Inter)national traffic

-

Long-distance/very long-distance traffic

Standard changing interval
This is the standard changing interval symbol.

See the "Fluids and lubricants" specifications
manual for the prescribed oil specification.

Extended changing interval
This is the extended changing interval symbol.

If the prescribed oil specification and any
additional conditions (see specification manual
"Fluids and lubricants") are complied with, an
extended changing interval may be applied.

Note:
An extended changing interval for engine oil may
be subject to additional conditions. The additional
conditions are included in the "Fluids and
lubricants" specification manual.

G0  00 230

Ext.

G0  00 229

©

 200423

1-3

Maintenance intervals

MAINTENANCE SCHEDULE

ΧΦ85 series

4

Intermediate inspection
This is the intermediate inspection symbol.

Intermediate inspections are based on several
visual inspections.

When an extended changing interval is
applicable to the engine oil (X-service), an
intermediate inspection should be carried out.

X-service
This is the symbol for an X-service.

An X-service is a mileage-dependent
maintenance check which consists of changing
the engine oil plus a number of visual inspections.

Note:
If the prescribed oil specification and additional
conditions (see specification manual "Fluids and
lubricants") are met, an extended changing
interval (X-service) may be applied.
An X service should be carried out at least once
every year.

Y-service
This is the symbol for a Y-service.

A Y-service is an annual maintenance check
consisting of several maintenance activities plus
changing of the gearbox and rear axle oil.

Note:
If the prescribed oil specification (see
specification manual "Fluids and lubricants") has
been met, an extended changing interval may be
applied.

G000088

Intermediate

inspection

G000086

+

 X service

G000087

+

1x per YEAR

 Y service

(1)

MAINTENANCE SCHEDULE

1-4

©

 200423

Maintenance intervals

4

ΧΦ85 series

1.3 EFFECT OF DIESEL FUEL AND PTO HOURS ON MAINTENANCE INTERVALS

Diesel fuels

PTO hours
PTO hours should be converted into mileage
according to the following formula:

1 PTO hour = 40 km

1.4 MAINTENANCE IN SPECIAL OPERATING CONDITIONS

Contact a DAF dealer/main branch or importer for
vehicles used in very specific or heavy
conditions.
The service intervals can be modified, if
necessary, in consultation with the dealer/main
branch or importer to fit the appropriate operating
conditions.

1.5 FIRST SERVICE INSPECTION

The first service inspection should be carried out
between the first 7,500 and 10,000 km or at most
8 weeks after delivery of the vehicle, whichever
comes first.

Note:
If the vehicle is equipped with a clutch wear
indicator, ensure that the lock nut makes contact
with the servo housing.
If necessary, make sure that the lock nut makes
contact with the housing.

The oil for the 1355 (T) axle must be renewed
between the 2,000 and 3,000 km.

Sulphur content

Engine oil change interval

> 0,2%

Halve interval to max. of 25,000 km
