3-1

Inspection and adjustment

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ65/65 (II) series

5

3. INSPECTION AND ADJUSTMENT

3.1 CHECKING PEDAL RUBBERS

1.

Check that the pedal rubbers are still

securely mounted on the pedal.

2.

Check that the pedal rubbers are not worn

out and there is still sufficient tread.

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

3-2

©

 200518

Inspection and adjustment

5

ΧΦ65/65 (II) series

3.2 CHECKING THE BATTERY FLUID LEVEL

Avoid sparks and open flames in the

vicinity of batteries.

Battery acid is an aggressive fluid.

In the event of contact with the skin:

rinse the skin with plenty of water for

a sustained period. If redness or

pain persists, consult a doctor.

Remove any clothing affected and

rinse with water.

In the event of contact with the eyes:

rinse with plenty of water for at least

15 minutes and consult a doctor.

If swallowed: do NOT induce

vomiting. Rinse the mouth, drink two

glasses of water and consult a

doctor.

In the event of inhalation: get fresh

air, rest and consult a doctor.

1.

Check the electrolyte level. The electrolyte

level must be approx. 10 mm above the

plates or up to the level indicator if available.

2.

If necessary, top up the batteries, see

chapter "Draining and filling".

3.3 CHECKING THE BATTERY TERMINALS

1.

Visually check the battery terminals for

corrosion. Clean the battery terminals if

necessary, see chapter on "Cleaning".

2.

Check the attachment of the battery

terminals.

}

G000380-2

CF65

CF65 (II)

©

 200518

3-3

Inspection and adjustment

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ65/65 (II) series

5

3.4 CHECKING THE FLUID LEVEL OF THE CAB TILTING PUMP

1.

The fluid level must be checked when the

cab is in the driving position.

2.

The cock (2) should be in the "tilting back"

position (anti-clockwise).

3.

Unscrew the filler plug (1) 3 to 4 turns. Wait

until the overpressure, if any, has left the

reservoir. Remove filler plug (1).

4.

Start pumping (maximum 5 pump strokes).

Ensure that the pump lever is in the lowest

position.

5.

Check the fluid level. This level should be no

more than 2 cm below the top of the filling

opening. Top up if necessary.

6.

Fit the filler plug (1) and hand tighten it.

3.5 CHECK CAB FASTENING

1.

Check that all attachment bolts are in place.

2.

Visually inspect the attachment of the cab to

the tilting mechanism.

3.

Visually inspect the seals and condition of

the tilting mechanism.

Engine, cooling system and fuel system

M201062

N

!

1

2

K1 01 660

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

3-4

©

 200518

Inspection and adjustment

5

ΧΦ65/65 (II) series

3.6 BLEEDING THE FUEL SYSTEM

When venting the fuel system, a

quantity of fuel will escape. Collect

the fuel and avoid the risk of fire.

Stop pumping as soon as a

resistance is felt. If you continue

pumping, the fuel system may

become internally damaged.

Note:

When the hand pump is used, the fuel system will

be automatically bled. Air will be fed back to the

tank through the return pipe.

Racor fuel prefilter/water separator
1.

Open the vent plug (2) a couple of turns.

2.

Pump the primer pump (1) until fuel comes

out of the vent plug (2).

3.

Close the vent plug (2).

4.

Use the primer pump until a clearly higher

resistance is felt.

}

}

1

2

3

4

5

7

6

8
