Citroen C5 Dag (2010 year). Instruction

285

* The services available depend on the network, the SIM card and the

compatibility of the Bluetooth telephone used. Check the telephone
manual and with your network provider for details of the services
available to you. A list of mobile telephones with the best level of
compatibility is available from the dealer network.

BLUETOOTH TELEPHONE

CONNECTING A TELEPHONE

For reasons of safety and because they require prolonged attention

on the part of the driver, the operations for pairing the Bluetooth

mobile telephone to the hands-free system of the MyWay must be

carried out with the vehicle stationary. The ignition must be on.

Activate the telephone's Bluetooth function.
The last telephone connected is reconnected
automatically.

Enter the authentication code on the

telephone. The code to be entered is
displayed on the screen.

To change the telephone connected,

press the PHONE button, then select

Phone Menu and press the dial to

conﬁ rm.

Once the telephone has been connected, MyWay can synchronise
the address book and the call list. This synchronisation may take a

few minutes * .

Select "Connect phone". Select the

telephone and press to conﬁ rm.

The list of telephones connected previously (4 maximum) appears

on the multifunction screen. Select the telephone required for a new
connection.

Press the PHONE button.

For a ﬁ rst connection, select

"Search phone" and press the dial to

conﬁ rm. Then select the name of the

telephone.

Search phone

Connect phone

286

Select the "Yes" tab to accept or "No"

to refuse and conﬁ rm by pressing

the dial.

RECEIVING A CALL

MAKING A CALL

An incoming call is announced by a ring and a superimposed

display on the multifunction screen.

Yes

To hang up, press the PHONE button

or press the dial and select "End call"

then conﬁ rm by pressing the dial.

End call

Press the PHONE button.

Select "Dial number", then dial the

telephone number using the virtual

keypad.

Select the Phone Menu function and

press the dial to conﬁ rm.

The list of the last 20 calls made and received in the vehicle

appears under Phone Menu. You can select a number and press

the dial to make the call.

It is also possible to select a number from the address book. You

can select "Dial from address book". The MyWay can record up to

4 000 entries.
Press the end of the steering mounted control for more than two

seconds to gain access to the address book.

Phone Menu

Dial number

To delete a number, press the PHONE button then press and hold

on a call number to display a list of actions including:

Delete entry

Delete list

BLUETOOTH TELEPHONE

A short press on the steering

mounted TEL button accepts the

incoming call or ends the call in

progress. A long press rejects the

incoming call.

287

CONFIGURATION

SETTING THE DATE AND TIME

The SETUP function gives access to the following options: System

language, Date & Time, Display (Brightness, Colour, Map colour), Vehicle,

Units, System.

Adjust the settings one by one using

the direction arrows and conﬁ rm by

means of the dial.

Select the "Date format" function and

press the dial to conﬁ rm.

Select the "Set date & time" function

and press the dial to conﬁ rm.

Conﬁ rm the format required using the dial.

Pressing the SET UP button for more than 2 seconds gives

access to:

These settings must be entered again if the battery has been

disconnected.

Press the SET UP button.

Conﬁ rm the format required using

the dial.
Select the "Time format" function and

press the dial to conﬁ rm.

Set date & time

Select the "Date & Time" function

and press the dial to conﬁ rm.

Demo mode

GPS coverage

Description of the unit

Date & Time

288

TRIP COMPUTER/VEHICLE PARAMETERS

TRIP COMPUTER

Press the MAIN button or press

the MODE button several times in

succession until the trip computer is
displayed.

Range: displays the distance which can travelled with the

remaining fuel detected in the tank, based on the average fuel

consumption over the last few miles (kilometres).

This displayed value may vary signiﬁ cantly following a change in

the vehicle speed or the relief of the route.
When the range falls below 20 miles (30 km), dashes are

displayed. After ﬁ lling with at least 5 litres of fuel, the range is

recalculated and is displayed when it exceeds 60 miles (100 km).

If, whilst driving, dashes are displayed continuously in place of the

digits, contact a CITROËN dealer.

If, whilst driving, dashes are displayed continuously in place of the

Each press of the button at the end of the wiper stalk displays the

different trip computer information in succession, according to the

screen.

A FEW DEFINITIONS

The "vehicle" tab:

The range, the current fuel

consumption and the distance

remaining or the Stop & Start

time counter.

- The "1" (trip 1) tab with:

The average speed, the average

fuel consumption and the
distance travelled calculated
over trip "1".

- The "2" (trip 2) tab with the same

functions for a second trip.

Current fuel consumption: only calculated and displayed above

20 mph (30 km/h).
Average fuel consumption:

this is the average fuel consumption

since the last trip computer zero reset.

Distance travelled: calculated since the last trip computer zero
reset.

Distance remaining to the destination: calculated with reference

to the ﬁ nal destination, entered by the user. If guidance is activated,

the navigation system calculates it as a current value.

Average speed:

this is the average speed calculated since the last

trip computer zero reset (ignition on).

Stop & Start time counter
(minutes/seconds or hours/minutes)

If your vehicle is ﬁ tted with Stop & Start, a time counter calculates

the time spent in STOP mode during a journey.

It resets to zero every time the ignition is switched on with the key.

289

RADIO

SCREEN MENU MAP

"Traffic" Menu

Messages on route

Only warnings on route

All warning messages

All messages

Within 2 miles (3 km)

Geo. Filter

Within 3 miles (5 km)

Within 6 miles (10 km)

Within 30 miles (50 km)

Within 60 miles (100 km)

"Music" Menu

Select music

Sound settings

Balance/Fader

Bass/Treble

Linear

Equalizer

Classic

Jazz

Rock/Pop

Techno

Vocal

Loudness

Speed dependent volume

Reset sound settings

"Radio" Menu

Waveband

Linear

Manual tune

Sound settings

Balance/Fader

Bass/Treble

Equalizer

MAIN FUNCTION

CHOICE A

choice A1

choice A2

CHOICE B...

290

Abort guidance/Resume guidance

Destination input

Geo position

Map

Stopovers

Add stopover

Navigate HOME

Choose from address book

Rearrange route

Choose from last destinations

Replace stopover

Delete stopover

Recalculate

Fast route

Short route

Optimized route

POI search

POI nearby

Route options

Route type

Short route

Fast route

"Navigation" Menu

City

Street

Enter new address

Country

Navigate HOME

City district

House number

Start route guidance

Postal code

Save to address book

Intersection

Address input

POI near destination

POI in city

POI in country

POI near route

Choose from address book

Choose from last destinations

TMC station information

Loudness

Speed dependent volume

Reset sound settings

Classic

Jazz

Rock/Pop

Techno

Vocal

291

Avoid ferries

Recalculate

Settings

Navi volume

POI categories on Map

Set parameters for risk areas

Display on map

Visual alert

Sound alert

Dial from address book

"Phone" Menu

Search phone

Call lists

Connect phone

Select ring tone

Phone/Ring tone volume

Phones connected

Enter mailbox number

Settings

Disconnect phone

Rename phone

Delete pairing

Delete all pairings

Show details

"SETUP" menu

System language *

English

Español

Deutsch

Italiano

Français

Nederlands

Polski

Portuguese

Date & Time *

Set date & time

Date format

Time format

Avoid motorways

Route dynamics

Trafﬁ c independent

Semi-dynamic

Avoidance criteria

Avoid toll roads

Optimized route

* Available according to model.

292

* Available according to model.

Dark blue

Map colour

Night mode for map

Units

Day mode for map

Vehicle *

Vehicle information

Alert log

Status of functions

Temperature

Celsius

Fahrenheit

Metric/Imperial

Kilometres (Consumption: l/100)

Kilometres (Consumption: km/l)

Miles (Consumption: MPG)

System

Auto. Day/Night for map

Factory reset

Software version

Automatic scrolling

Colour

Pop titanium

Toffee

Blue steel

Technogrey

Display

Brightness

293

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

There is a difference in
sound quality between
the different audio

sources (radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the Linear musical ambience and
set the loudness correction to the "Active" position

in CD mode or to the "Inactive" position in radio

mode.

The CD is ejected

automatically or is not
played by the player.

The CD is inserted upside down, is unplayable, does not contain any

audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

- Check that the CD is inserted in the player the

right way up.

- Check the condition of the CD: the CD cannot

be played if it is too damaged.

Check the content in the case of a recorded

CD: consult the advice in the Audio section.

- The audio equipment's CD player does not

play DVDs.

Because of their quality level, certain

writeable CDs will not be played by the audio

system.

The CD player sound is

poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable

conditions.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

294

QUESTION

ANSWER

SOLUTION

The stored stations do
not function (no sound,

87.5 Mhz is displayed...)

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

The quality of reception
of the radio station

listened to gradually

deteriorates or the stored
stations do not function
(no sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate
a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Have the aerial checked by a CITROËN dealer.

Sound cut-outs of 1 to
2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

With the engine off,

the audio equipment
switches off after a few
minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.
The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

295

QUESTION

ANSWER

SOLUTION

TA is selected. However,

certain trafﬁ c jams

along the route are not

indicated in real time.

On starting, it is several minutes before the system begins to receive the

trafﬁ c information.

Wait until the trafﬁ c information is being received

correctly (displaying of the trafﬁ c information

symbols on the map).

In certain countries, only major routes (motorways...) are listed for the

trafﬁ c information.

This phenomenon is normal. The system is

dependent on the trafﬁ c information available.

I receive a speed camera
alert for a camera which
is not on my route.

The system announces all speed cameras located in a conical zone
forward of the vehicle. It may detect speed cameras on nearby or parallel
roads.

Zoom the map to view the exact position of the
speed camera.

The audible speed
camera alert is not

working.

Audible alerts are not active.

Activate audible alerts in Navigation Menu,

Settings, Set parameters for risk areas.

The alert volume level is set to minimum.

Increase the speed camera alert volume.

The altitude is not
displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to

receive more than 3 satellites correctly.

Wait until the system has started up completely.

Check that there is a GPS coverage of at least

3 satellites (long press on the SETUP button, then

select GPS coverage).

Depending on the geographical environment (tunnel...) or the weather,

the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system is
dependent on the conditions of reception of the

GPS signal.

The route is not
calculated successfully.

The exclusion criteria may conﬂ ict with the current location (exclusion of

toll roads on a motorway with tolls).

Check the exclusion criteria.

296

QUESTION

ANSWER

SOLUTION

There is a long waiting

time after inserting a CD.

When a new medium is inserted, the system reads a certain amount of

data (directory, title, artist, etc.). This may take a few seconds.

This phenomenon is normal.

I cannot connect my
Bluetooth telephone.

The telephone's Bluetooth function may be deactivated or the equipment
may not be visible.

Check that your telephone's Bluetooth
function is activated.

Check that your telephone is visible.

A telephone connected
by Bluetooth is inaudible.

The volume level depends on both the system and the telephone.

Increase the MyWay volume setting, possibly to

maximum, and increase the telephone volume
level if necessary.

297

AUDIO SYSTEM

Your Audio system is coded in such a way that it will
only operate in your vehicle. If it is to be installed in
another vehicle, contact your CITROËN dealer for

only operate in your vehicle. If it is to be installed in

conﬁ guration of the system.

For safety reasons, the driver must carry out operations

which require prolonged attention while the vehicle is

stationary.
When the engine is switched off and to prevent

discharging of the battery, the audio equipment may

switch off after a few minutes.

AUDIO SYSTEM/BLUETOOTH

  01  First steps
  02  Steering mounted controls
  03  Main menu
  04  Audio
  05  USB Player
  06  Bluetooth functions
  07  Configuration
  08  Trip computer
  09  Screen menu map
  Frequently asked questions

p.
p.
p.
p.
p.
p.
p.
p.
p.
p.

298
299
300
301
304
307
309
310
311
315

CONTENTS

298

FIRST STEPS

1.   On/Off and volume adjustment.
  2.   CD eject.
  3.   Selection of the display on the screen from

the following modes:

Audio (AUDIO), Trip Computer (TRIP) and
Telephone (TEL) functions.

4. Selection of source:

radio, audio CD/MP3 CD, USB, Jack

connection, Streaming.

5. Selection of FM1, FM2, FMast and AM

wavebands.

6. Setting audio options: front/rear fader,

left/right balance, loudness, sound

ambience.

7. Display the list of local stations, of the tracks

on the CD or of the MP3 folders.

8. Abandon current operation.
9. TA (Trafﬁ c Announcement) function on/off.

Long press: access to the PTY (Types of

radio programme) mode.

10. Conﬁ rmation.

11. Automatic search for a lower/higher

frequency.

Selection of previous/next CD, MP3 or
USB track.

12. Selection of a lower/higher radio frequency.

Selection of the previous/next MP3 folder.

Selection of the previous/next USB device

folder/genre/artist/playlist.

13. Display the general menu.

14. Buttons 1 to 6:

Selection of a stored radio station.

Long press: store a station.

15. The DARK button changes the display on the

screen to improve driving comfort at night.

1st press: lighting the upper band only.

2nd press: display of a black screen.

3rd press: return to the standard display.

299

LIST

MENU

STEERING MOUNTED CONTROLS

1. Activation/deactivation of the

Black Panel mode (night driving).

3. Access to the short-cut menus depending on the display on

the screen.

Conﬁ rmation of the function selected from a menu.

Rotation:

Selection of the previous/next stored RADIO station.

Selection of the previous/next CD or MP3 directory.

4. Abandon the current operation.

Reject an incoming call.

Long press: return to the main display.

  5.   Access to the main menu.
  6.   Volume increase.
  7.   Volume decrease.
  8.   Mute.
  9.   RADIO: automatic search for a lower/higher frequency.

CD/MP3:

selection of the previous/next track.

continuous press: fast forward/rewind play.

10. RADIO: display the list of stations available.

Long press: update the list of radio stations.

CD/MP3:

display the list of CD and folder tracks.

2. Pick up an incoming call/end a call

which is in progress.

Open the telephone menu and
display the calls list.

Long press: reject an incoming call.

300

AUDIO FUNCTIONS

radio, CD, USB, options.

TRIP COMPUTER

: entering of

distances, alerts, status of functions.

TELEPHONE

: Bluetooth

hands-free, pairing,

management of a call.

PERSONALISATION-
CONFIGURATION

: vehicle

parameters, display, languages.

> MONOCHROME SCREEN C

> MONOCHROME SCREEN A

For a detailed global view of the

menus available, refer to the
"Screen menu map" section.

Citroen C5 Dag (2010 year). Instruction - part 20
