Citroen C4 (2016 year). Instruction - part 24

Audio and Telematics

367

C4-2_en_Chap10c_RD5_ed02-2015

Streaming - Playing audio
files via Bluetooth

Pair/connect the telephone then play the files:
see the "Pairing" section.

The telephone connection
automatically includes hands free
operation and audio streaming.
The ability of the system to connect
to just one profile depends on the
telephone. Both profiles may connect
by default.

Indicates that a device is connected.

Indicates connection of the audio
steaming profile.

Indicates connection of the hands-
free profile.

Press MENU

Managing connections

Select "Bluetooth connection" and
confirm.

Select "Connections management"
and confirm. The list of paired
telephones is displayed.

Select a telephone and confirm.

Audio and Telematics

368

C4-2_en_Chap10c_RD5_ed02-2015

To display the "TELEPHONE

" menu:

Make along press on SOURCE or
SRC

Or, press OK to display the
contextual menu. Select "Call"
and confirm.

Or, press MENU, select
"Telephone

" and confirm.

Select "Call

" and confirm.

Select "Dial

" to enter a number and

confirm.

Select OK

and confirm to start the

call.

Select numbers one at a time using
the 7 and 8

buttons and confirm.

Making a call - Dialling

Correction allows numbers to be deleted one
at a time.

Then select and confirm:
- "Connect telephone

" /

"Disconnect telephone

to connect / disconnect the
telephone or the hands-free
connection only.

- "Connect media player

" /

"Disconnect media player

to connect / disconnect only
streaming.

- "Connect telephone +

media player

" / "Disconnect

telephone + media player

to connect / disconnect the
telephone (hands-free and
streaming).

- "Delete connection

": to delete

the pairing.

Audio and Telematics

369

C4-2_en_Chap10c_RD5_ed02-2015

To display the "TELEPHONE

" menu:

- Make a long press on SRC/TEL.
-

Or, press the dial to display the
contextual menu. Select "Call"
and confirm.

Or, press MENU, select
"Telephone

" and confirm. Select

"Call

" and confirm.

To display the "TELEPHONE

" menu:

- Make a long press on SRC/TEL.
-

Or, press the dial to display the
contextual menu. Select "Call"
and confirm.

Or, press MENU, select
"Telephone

" and confirm. Select

"Call

" and confirm.

Select "Calls list

" and confirm.

Select "Directory

" and confirm.

Select the number and confirm to
start the call.

Making a call - Recently
called numbers*

Making a call - From the
directory of contacts

The calls list includes calls sent and
received in the vehicle using the
connected telephone.

It is possible to make a call directly
from the telephone; park the vehicle
first as a safety measure.

* Depending on the compatibility of the

telephone.

Audio and Telematics

370

C4-2_en_Chap10c_RD5_ed02-2015

During a call, press OK to display the
contextual menu.

A long press on ESC or on TEL,
SOURCE or SRC

also rejects an

incoming call.

Select a contact then confirm.

Select the number and confirm.

"YES" to accept the call is selected
by default.
Press OK

to accept the call.

Select "NO

" and confirm to reject

the call.
or
Press one of these buttons to accept
the call.

In the contextual menu,
select "Hang up

" to end the call.

A long press on one of these buttons
also ends the call.

Home

Receiving a call

An incoming call is announced by a ring and
a superimposed display in the multifunction
screen.

Business

Mobile
(depending on the information
available in the contact
records of the telephone
connected).

Managing calls

Hang up

Audio and Telematics

371

C4-2_en_Chap10c_RD5_ed02-2015

(so that the caller cannot hear)

In the contextual menu:
-

select "Micro OFF" to switch off
the microphone.

deselect "Micro OFF" to switch
the microphone on.

In the contextual menu:
-

select "Telephone mode" to
transfer the call to the telephone.

deselect "Telephone mode" to
transfer the call to the vehicle.

From the contextual menu,
select "DTMF tones

" and confirm to

use the digital keypad to navigate in
the interactive voice response menu.

From the contextual menu,
select "Switch

" and conform to

return to a call left on hold.

Secret - Mute

Combined mode

Interactive voice response

Consultation call

In certain cases, the combined mode has to
activated from the telephone.
If the contact has been cut off, when you
reconnect on returning to the vehicle,
the Bluetooth connection will be restored
automatically (depending on the compatibility of
the telephone).

(to leave the vehicle without ending the call)

Audio and Telematics

372

C4-2_en_Chap10c_RD5_ed02-2015

To modify the contacts saved in
the system, press MENU then
select "Telephone

" and confirm.

Select "Directory management"
and confirm.
You can:
- "Consult an entry",
- "Delete an entry",
- "Delete all entries

Make a long press on SOURCE or
SRC for access to the directory
or press OK, and
select "Call

" and confirm.

The system accesses the telephone's
contacts directory, depending on
its compatibility, and while it is
connected by Bluetooth.

With certain telephones connected
by Bluetooth you can send a contact
to the directory of the audio system.
Contacts imported in this way are
saved in a permanent directory
visible to all, whatever the telephone
connected.
The menu for the directory is not
accessible if it is empty.

Select "Directory" to see the list of
contacts.

Directory

Audio and Telematics

373

C4-2_en_Chap10c_RD5_ed02-2015

The Ambience, Treble and Bass audio
settings are different and independent
for each sound source.

On-board audio: Arkamys

Sound

Staging optimises sound distribution in
the the passenger compartment.

The distribution (or spatialisation using
the Arkamys

system), is an audio

process which allows the sound quality
to be improved according to the setting
chosen, corresponding to the position
of the listeners in the vehicle.

Audio settings

Screen C

Screen A

Press ¯

to display the audio settings

menu.

Press ¯

to display the audio settings

menu.

Press 7 or 8

to modify the selected

setting.

Press 5 or 6 for the previous or
next setting in the list.

The settings available are:
-  Ambience,
- Bass,
- Treble,
- Loudness,
-  Distribution: Personalised or Driver,
-  Left / right balance,
-  Fader (front / rear balance),
-  Auto. volume.

Select and confirm "Other
settings…

" to display the next

setting in the list.

The Ambience, Treble and Bass audio
settings are separate and independent
for each sound source.

Audio and Telematics

374

C4-2_en_Chap10c_RD5_ed02-2015

Screen menu map(s)

Option A

Option A11

Option B...

DATE AND TIME

TRIP COMPUTER

RADIO

LANGUAGES

VEHICLE PARAM*

MEDIA

Diagnostics

RDS options

Infotext

Radiotext

Français

Portuguès-brasil

Nederlands

English

Cestina

Italiano

Deutsch

Portuguès

Español

Hrvatski

Magyar

Read mode

Option A1

Normal

Random all

Random

Main function

Screen A

* Depending on vehicle equipment.

Audio and Telematics

375

C4-2_en_Chap10c_RD5_ed02-2015

Media parameters

MEDIA

TELEPHONE

Choice of playback mode

Choice of track listing

Normal

By folders

Random all

By genres

Random

By artists

Repeat

By playlists

Call

Radio parameters

Directory

Calls list

Voice mail box

Dial

Directory management

Telephone management

Hang up

Vehicle diagnosis

TRIP COMPUTER

Delete an entry

Delete all entries

Consult an entry

Telephone status

Screen C

Audio and Telematics

376

C4-2_en_Chap10c_RD5_ed02-2015

Search for a device

Connections management

BLUETOOTH CONNECTION

Define the vehicle
parameters*

Choice of sounds

Choice of language

Display configuration

* Depending on vehicle equipment.

Choice of units

Date and time adjustment

Display parameters

Brightness

PERSONALISATION -
CONFIGURATION

Audio and Telematics

377

C4-2_en_Chap10c_RD5_ed02-2015

QUESTION

ANSWER

SOLUTION

There is a difference in
sound quality between the
different audio sources
(radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass,
Treble, Ambience, Loudness) can be adapted to the different sound
sources, which may result in audible differences when changing
source (radio, CD...).

Check that the audio settings (Volume, Bass,
Treble, Ambience, Loudness) are adapted to
the sources listened to. It is advisable to set
the AUDIO functions (Bass, Treble, Front-Rear
Fader, Left-Right Balance) to the middle position,
select the musical ambience "None" and set the
loudness correction to the "Active" position in CD
mode or to the "Inactive" position in radio mode.

If the bass and treble
settings are modified,
the ambience selected is
cancelled.

The selection of an ambience imposes specific bass and treble
settings.

To obtain the desired sound quality, modify the
treble and bass settings or select a pre-defined
ambience setting.

If the ambience setting
is changed, the previous
settings for treble and
bass are cancelled.

If the "Driver" / "All
passengers" distribution
is modified, the balance
settings are cancelled.

Choosing a distribution setting imposes a specific balance setting.
Modifying one without the other is not possible.

Modify the balance setting or the distribution
setting to obtain the desired sound quality.

When changing the
balance setting, the
"Driver" / "All passengers"
distribution is cancelled.

Frequently asked questions

The following tables contain answers to the most frequently asked questions.

Audio and Telematics

378

C4-2_en_Chap10c_RD5_ed02-2015

QUESTION

ANSWER

SOLUTION

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 MHz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going
through an automatic car wash or in an underground car park).

Have the aerial checked by a CITROËN dealer.

Sound cut-outs of 1 to
2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for another
frequency giving better reception of the station.

Deactivate the RDS function if the phenomenon
is too frequent and always on the same route.

The traffic announcement
(TA) is displayed. I do
not receive any traffic
information.

The radio station does not broadcast traffic information.

Tune to a radio station which broadcasts traffic
information.

The stored stations are not
found (no sound, 87.5 MHz
is displayed...).

An incorrect waveband is selected.

Press the BAND button to return to the waveband
on which the stations are stored.

Audio and Telematics

379

C4-2_en_Chap10c_RD5_ed02-2015

QUESTION

ANSWER

SOLUTION

The CD is ejected
automatically or is not
played by the player.

The CD is inserted upside down, is unplayable, does not contain
any audio data or contains an audio format which the player cannot
play.
The CD is protected by an anti-pirating protection system which is
not recognised by the audio equipment.

- Check that the CD is inserted in the player

the right way up.

- Check the condition of the CD: the CD

cannot be played if it is too damaged.

- Check the content in the case of a recorded

CD: consult the advice in the "Audio" section.

- The audio equipment's CD player does not

play DVDs.

- Due to their quality level, certain writeable

CDs will not be played by the audio system.

The CD player sound is
poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in
suitable conditions.

The audio settings (bass, treble, ambience) are unsuitable.

Set the treble or bass level to 0, without selecting
an ambience.

I am unable to connect my
Bluetooth telephone.

It is possible that Bluetooth is switched off on the telephone or that
the telephone has not been made not visible.

- Check that your telephone has Bluetooth

switched on.

- Check in the telephone's settings that it is

"Visible to all".

The Bluetooth telephone is not compatible with the system.

You can check the compatibility of your
telephone on www.citroen.co.uk (services).

The Bluetooth connection
is cut.

The battery of the peripheral may not be sufficiently charged.

Recharge the battery of the peripheral device.

Audio and Telematics

380

C4-2_en_Chap10c_RD5_ed02-2015

QUESTION

ANSWER

SOLUTION

The message "USB
peripheral error"
or "Peripheral not
recognised" is displayed in
the screen.

The USB memory stick is not recognised.
The memory stick may be corrupt.

Reformat the memory stick (FAT32).

A telephone connects
automatically,
disconnecting another
telephone.

Automatic connection overrides manual connection.

Modify the telephone settings to remove
automatic connection.

The Apple

player is

not recognised when
connecting to the USB
port.

The Apple

player is of a generation that is not compatible with a

USB connection.

Connect the Apple

player to the AUX Jack

socket using a suitable cable (not supplied).

The hard disk or device
is not recognised when
connecting to the USB
port.

Some hard disks and devices need a power supply greater than is
provided by the audio system.

Connect the device to the 230 V socket, the 12 V
socket or an external power supply.
Caution

: ensure that the device does not

transmit a voltage greater than 5 V (risk of
destruction of the system).

When streaming, the
sound cuts momentarily.

Some models of telephone prioritise connection with the "hands-
free" profile.

Delete the "hands-free" connection profile to
improve streaming.

In "Random all" play, not
all of the tracks are played.

In "Random all" play, the system can only take into account up to
999 tracks.

Audio and Telematics

381

C4-2_en_Chap10c_RD5_ed02-2015

QUESTION

ANSWER

SOLUTION

With the engine off, the
audio system switches off
after a few minutes of use.

When the engine is switched off, the audio system operating time
depends on the state of charge of the battery.
The switch-off is normal: energy economy mode is activated
automatically to preserve the state of charge of the vehicle's
battery. (See the "Energy Economy Mode" section).

Start the vehicle's engine to increase the battery
charge.

The message "the audio
system is overheated"
appears on the display.

In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction of the volume or stopping of
the playing of the CD.

Switch the audio system off for a few minutes to
allow the system to cool.

Alphabetical index

382

C4-2_en_Chap11_index-alpha_ed02-2015

ABS and EBFD systems .............................. 140
Accessories

................................................. 236

Accessory position

.......................................173

Accessory socket, 12V .................................117
Additive, AdBlue

..................................... 23, 232

Adjusting headlamps ................................... 132

Adjusting

head restraints

............................................. 83

Adjusting seats ..........................................81, 82

Adjusting the date .............................. 40 , 42 , 51

Adjusting the height and reach

of the steering wheel ................................... 86

Adjusting the seat belt

height ................................................. 143, 145

Adjusting the time ......................... 37, 41, 46, 51

Advice on driving ................................. 166, 167

Airbags ................................................... 22, 147

Airbags, curtain .................................... 149, 150

Airbags, front........................................ 148, 150

Airbags, lateral ..................................... 149, 150

Air conditioning ........................................ 10, 91

Air conditioning, automatic ............................ 95

Air conditioning, manual ................................ 93
Air vents

......................................................... 90

Alarm ...............................................................71

Anti-lock braking system (ABS) ................... 140
Anti-pinch

............................................... 76, 107

Anti-theft

................................................ 66, 168

Armrest, front ........................................ 110, 111

Armrest, rear .................................................117
Assistance call

..................................... 139, 280

Audible warning ........................................... 139

Audio streaming

(Bluetooth) ................................. 314, 364, 367

Battery

.......................................... 230, 265-268

Battery, charging .................................. 267, 268

Battery, remote control .......................61, 66-68

Black panel..................................................... 39

Blanking screen (snow shield) ......................213

Blind, panoramic roof ................................... 107
Blind spot sensors

....................................... 195

BlueHDi

........................................................ 232

Bluetooth (hands-free) .........................340, 366

Bluetooth (telephone) ........................... 340, 341
Bonnet

.......................................................... 223

Boot

................................................................ 79

Brake discs ................................................... 231

Brake lamps ................................................. 257

Brake pads ................................................... 231

Braking assistance

system ........................................................ 140

Braking, dynamic emergency .......................178

Bulbs (changing) ................................... 251-259

Audio system .................................... 40, 42, 353

Audio system pre-equipment ....................... 220

Auxiliary ....................................... 104, 312, 364

Cable, audio

......................................... 312, 364

Capacity, fuel tank ....................................... 209
CarPlay connection

..............................333, 334

.........................................................312, 361

CD, MP3 ....................................... 312, 361, 362

Central locking ................................... 56, 62, 69
Centre console

............................................. 108

Changing a bulb .................................... 251-259

Changing a fuse ....................................260 -264

Changing a wheel .................................244-250

Changing a wiper blade ........................137, 221

Changing the remote

control battery

.................................. 61, 66, 67

Checking the engine oil level ................. 29, 266

Checking the levels ...............................226-229

Checking tyre pressures

(using the kit) ............................................. 243

Checks ..................................................224-231

Checks, routine .................................... 230, 231

Child lock ...................................................... 165

Children (safety) .................... 146, 148, 151 -165
Child seats

........... 146, 151, 152, 156 -158, 164

Child seats, conventional

............................. 157

Child seats, ISOFIX

......................................161

CITROËN

Connect Box ............................................. 280

CITROËN Localised

Emergency Call ......................................... 280

Clock .............................................................. 37

Closing the boot ....................................... 58, 79

Closing the doors ............................... 58, 63, 78

Configuration, vehicle ........................ 41 , 44, 4 9
Connected services

..................................... 324

Connection, Bluetooth

................................. 340

Content .. 22 23 24 25 ..
