Citroen C4 Picasso (2017 year). Instruction

128

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Pairing a Bluetooth

Pairing a Bluetooth telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-
free system of your audio system must
be done with the

vehicle stationary

and the ignition on.

Procedure from the telephone

Select the name of the system in the
list of devices detected.

In the system, accept the connection request
from the telephone.

Procedure from the system

Press

Telephone to display the

primary page.

Press "

Bluetooth search ".

The list of telephones detected is
displayed.

If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
Bluetooth function in your telephone.

Depending on the type of telephone,
you may be asked to accept or not
the transfer of your contacts and
messages.

Select the name of the chosen
telephone in the list.

Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

129

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Press

Telephone to display the

primary page.

Press "

Bluetooth connection " to

display the list of paired devices.

On return to the vehicle, if the last
telephone connected is present again,
it is automatically recognised and
within about 30 seconds of switching
on the ignition, the connection is
established without any action on your
part (Bluetooth activated).

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check in your telephone's
manual and with your service provider
for the services available to you.

The ability of the system to connect with
just one profile depends on the telephone.
All three profiles may connect by default.

Go to the Brand's website for more information
(compatibility, additional help, ...).

To modify the connection profile :

Automatic reconnection

Press the "details" button of a paired
device.

Press the "

PHONE " button to go to

the secondary page.

Press "

OK " to confirm.

Select one or more profiles.

The profiles compatible with the system
are HFP, OPP, PBAP, A2DP, AVRCP,
MAP and PAN.

The system offers to connect the telephone
with 3 profiles:
-

Telephone " (hands-free kit, telephone

only),

Streaming " (wireless playing of the audio

files on the telephone),

Internet data ".

130

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted

PHONE button to accept an

incoming call.

Make a long press

on the steering mounted

PHONE

button to reject the call.

And

Press "

End call ".

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

  Press the basket at the top right
of the screen to display a basket
alongside the telephone chosen.
  Press the basket alongside the
telephone chosen to delete it.

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press

Telephone to display the

primary page.

Press the "

PHONE " button to go to

the secondary page.

Press "

Bluetooth connection " to

display the list of paired peripheral
devices.

Deleting a telephone

Using the telephone is not
recommended while driving.
Park the vehicle.
Make the call using the steering
mounted controls.

Making a call

Calling a new number

Press

Telephone to display the

primary page.

Enter the phone number using the
digital keypad.

Press "

Call " to start the call.

131

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

on the steering mounted button.

Calling a contact

Setting the ringtone

Press

Telephone to display the

primary page.

Or make a long press

on the steering mounted

PHONE

button.

Press "

Contacts ".

Select the desired contact from the list offered.

Press "

Call ".

Calling a recently used number

Press

Telephone to display the

primary page.

Make a long press

Press "

Recent calls ".

Select the desired contact from the list offered.

It is always possible to make a call
directly from the telephone; as a safety
measure, first park the vehicle.

Press

Telephone to display the

primary page.

Press "

Ring volume " to display the

volume bar.

Press the arrows or move the cursor
to set the ring volume.

Press the "

OPTIONS " button to go to

the secondary page.

133

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Settings

Brightness

Ambience

Move the cursor to adjust the brightness of the
screen and/or of the instrument panel.

Settings

Profiles

Profile 1

Select a profile.

Profile 2

Profile 3

Common profile

Name:

Profile name

modification

Configure the profiles.

Reset the profile

Yes / No

Profile activated

Activate/deactivate the profile selected.

Save the settings.

Settings

Dark

Function which switches off the lit display.
Pressing the screen reactivates it.

135

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Comments

Settings

Configuration

System configuration

Configure certain system parameters.

Ambience

Select an ambience for the screen integrated in
the system.

Language

Select the display language for the the screen
and/or the instrument panel.

Screen configuration

Set the configuration of the screen and/or the
instrument panel.

Customization

Configure the instrument panel for a personalised
display.

Date and time

Set the date and time and select the display
format.

137

8
9

10
11

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Settings

Configuration

System

configuration

Units

Distance and fuel

consumption

Configure the display units for the distance,
consumption and temperature.

Temperatures

Factory settings

Reset

Restore the original settings.

System info

View

Consult the version of the different modules
installed in the system.

Save the parameters.

Settings

Configuration

Ambience

Select an ambience for the screen integrated in
the system.

Confirm the selection and start the change of
ambience.

Settings

Configuration

Language

All

Select the display language for the screen and/or
the instrument panel.

Europe

Asia

America

Save the parameter.

139

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Level 2

Level 3

Comments

Settings

Configuration

Screen

configuration

Brightness

Select the display brightness level.

Animation

Automatic scrolling

Activate or deactivate the parameters.

Animated transitions

Save the parameters.

Settings

Configuration

Temperature conditioning

Customization

Choose and select the display information
required.

Confirm

Confirm the selections.

Settings

Configuration

Date and time

Time

Set the time.

Time Zone

Set the time zone.

Select the display format.

12h

GPS Synchronisation

Activate or deactivate the synchronisation with the
satellites.
Save the settings.

Date

Set the date and select the display format.

Setting the date

Save the settings.

140

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Press

Settings to display the primary

page.

Profile settings

Adjust the brightness

Press "

OK " to save.

Select "

Profile 1 " or " Profile 2 " or

Profile 3 " or " Common profile ".

Press "

Profiles ".

Press this button to enter a name for
the profile using the virtual keypad

As a safety measure and because it
requires the sustained attention of the
driver, changes to settings must only be
done with the

vehicle stationary .

vehicle stationary

Press this button to activate the
profile.

Press this button to initialise the
profile selected.

Press

Settings to display the primary

page.

Move the cursor to adjust the brightness
of the screen and/or of the instrument
panel (according to version).

Press

Brightness .

Press in the grey zone to confirm.

Press the back arrow to confirm.

Press the back arrow again to
confirm.

141

5
6

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Settings to display the primary

page.

Press

Settings to display the primary

page.

Press

Settings to display the primary

page.

Press "

Configuration " to go to the

secondary page.

Press "

Configuration " to go to the

secondary page.

Press "

Configuration " to go to the

secondary page.

Press "

System configuration ".

Press "

Screen configuration ".

Press "

Units " to change the units

for distance, fuel consumption and
temperature.

Select "

Language " to change the

language.

Activate or deactivate: "

Automatic

scrolling ".

Select "

Animated transitions ".

Move the cursor to set the brightness
of the screen and/or instrument panel
(according to version).

Press "

Factory settings " to return to

the initial settings.

Press "

System info " to display the

versions of the different modules
installed in the system.

Modifying system settings

Returning the system to factory settings
activates the English language by
default (according to version).

Press "

Animation ".

Press "

Brightness ".

Select the language

Press the back arrow to confirm.

142

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Press

Settings to display the primary

page.

Select "

Date ".

Select "

Time ".

Press "

Date and time ".

Adjustment of the time and date is only
available if "GPS Synchronisation:" is
deactivated.
The change between winter and
summer time is done by changing the
time zone.

The system does not automatically
manage the change between winter
and summer time (depending on the
country of sale).

Setting the time

Press this button to define the date.

Press this button to adjust the time
using the virtual keypad.

Press the back arrow to save the
date.

Press this button to define the time
zone.

Select the display format of the date.

Select the display format for the time
(12h / 24h).

Activate or deactivate
synchronisation with satellites (UTC).

Press

Settings to display the primary

page.

Press "

Date and time ".

Setting the date

Press "

Configuration " to go to the

secondary page.

Press "

Configuration " to go to the

secondary page.

Press "

OK " to save the time.

Press the back arrow to save the
settings.

Press the back arrow again to
confirm.

143

Audio and Telematics

Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016

Radio

QUESTION

ANSWER

SOLUTION

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 Mhz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the "RDS" function by means of the
upper band to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not indicate
a fault with the audio system.

The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park).

Have the aerial checked by a franchised dealer.

I cannot find some radio
stations in the list of
stations received.

The station is not received or its name has changed in the list.

Press the round arrow on the "List" tab of the
"Radio" page.

Some radio stations send other information in place of their name
(the title of the song for example).
The system interprets this information as the name of the station.

The name of the radio
station changes.

Frequently asked questions

The following table groups together the answers to the most frequently asked questions concerning your audio system.

Citroen C4 Picasso (2017 year). Instruction - part 31
