383

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

As a safety measure and because it
requires the sustained attention of
the driver, using a smartphone when
driving is prohibited.
Operation must be with the vehicle
stationary

The synchronisation of a
smartphone allows applications on a
smartphone that are adapted to the
MirrorLink

technology to be displayed

in the vehicle's screen.
The principles and standards
are constantly evolving. For the
communication process between
the smartphone and the system to
work correctly, the smartphone must
be unlocked; update the operating
system of your smartphone as
well as the date and time in the
smartphone and the system

For the list of eligible smartphones,
connect to the brand's internet website
in your country.

The "MirrorLink

" function requires

the use of a compatible smartphone
and applications.

There may be a wait for the availability
of applications, depending on the
quality of your network.

When connecting a smartphone to
the system, it is recommended that
Bluetooth

be started on the smartphone

Depending on the smartphone, it may be
necessary to activate the "MirrorLink

" function.

During the procedure, several screen
pages relating to certain functions
are displayed.
Accept to start and end the
connection.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

Press "MirrorLink

" to start the

application in the system.

Once connection is established, a page
is displayed with the applications already
downloaded to your smartphone and adapted
to MirrorLink

technology.

Access to the different audio sources remains
accessible in the margin of the MirrorLink

display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons

From the system, press on
"Connectivity to display the primary
page.

As a safety measure, applications
can only be viewed with the vehicle
stationary; display is interrupted once
the vehicle is moving.

384

12:13

23 °C

531 kHz

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Level 3

385

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Level 3

Comments

Connectivity

MirrorLink

Go to or return to the applications already
downloaded to your smartphone and adapted to
MirrorLink

technology.

Go to a menu list depending on the application
chosen.
"Back": abandon the current operation, go up
one level.
"Home": go to or return to the "Car mode" page
on your smartphone.

Go to the primary page of the "Connectivity"
menu.

386

12:13

23 °C

531 kHz

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

CarPlay

smartphone connection

387

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

As a safety measure and because it
requires the sustained attention of
the driver, using a smartphone when
driving is prohibited.
Operation must be with the vehicle
stationary

The synchronisation of a
smartphone allows applications on a
smartphone that are adapted to the
CarPlay

technology to be displayed

in the vehicle's screen, having first
activated the CarPlay

function in your

smartphone.
As the principles and standards
are constantly changing, it is
recommended that you keep your
smartphone's operating system
updated

For the list of eligible smartphones, go
to the brand's internet website in your
country.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

Press "Telephone" to display the
CarPlay

interface.

Press "CarPlay" to display the
CarPlay

interface.

On connecting the USB cable, the
CarPlay

function deactivates the

system's Bluetooth

mode.

In the system, press "Connectivity"
to display the primary page.

388

FM/87.5 MHz

87.5MHz

12:13

23 °C

87.5 MHz

FM/87.5 MHz

87.5MHz

12:13

87.5 MHz

23 °C

AM/531 kHz

kHz

12:13

23 °C

531 kHz

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Radio Media

Level 1

Level 2

Radio stations

389

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Comments

Radio Media

Source

Radio

Select change of source.

USB

iPod

AUX

Bluetooth

Radio Media

Frequency /

Presets

Frequency

Carry out an automatic or manual search for
radio stations.

Presets

Make a long press on an empty location to preset
a station.

Radio Media

Band

Press Band to change waveband.

DAB

Radio Media

List

Radio stations

Open the list of radio stations and press on a
radio station to select it.

390

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Radio-media options

Audio settings

Radio settings

Radio stations

391

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Comments

Radio Media

Secondary page

Audio settings

Ambience

Select the sound ambience.

Distribution

Sound distribution by the Arkamys

system.

Sound

Adjust the volume or activate volume linked to
speed.

Voice

Adjust the voice volume.

Ringtone

Adjust the ringtone volume.

Confirm

Save settings.

Radio Media

Secondary page

Radio settings

General

Activate or deactivate settings.

Announcements

Confirm

Save settings.

Radio Media

Secondary page

Radio stations

Display the list of radio stations for the band
selected.

DAB

Presets

Select a preset radio station.

Frequency

Enter a frequency manually.

Change the screen display mode.

Update the list according to reception.

392

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Radio-media options

Photos

USB

393

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Comments

Radio Media

Secondary page

Music files

Albums

Choose a selection mode.

Artists

Genres

Playlists

Folders

Radio Media

Secondary page

Managing photos

USB

Display photos.
The system supports the following image
formats: .gif, .jpg, .jpeg, .bmp, .png, .raw and .tiff
with a maximum file size of 10 Mb per image.

394

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Press Radio Media to display the
menu.

Press the "OPTIONS

" button to go to

the secondary page.

Press "Frequency

Enter the values using the virtual
keypad.
First enter the units then click on the
decimals zone to enter the figures
after the decimal point.

Press one of the buttons for an
automatic search for radio stations.

Press Radio Media to display the
primary page.

Radio

Selecting a station

Radio reception may be affected by
the use of electrical equipment not
approved by the brand, such as a USB
charger connected to the 12 V socket.
The exterior environment (hills,
buildings, tunnel, car park, below
ground...) may prevent reception,
even in RDS station tracking mode.
This phenomenon is normal in the
propagation of radio waves and is in no
way indicative of a fault with the audio
system.

Select "Radio stations" in the
secondary page.

Move the cursor for a manual search
for frequencies up or down.

Select a radio station or frequency (refer to the
corresponding section).

Press "Presets

Make a long press on one of the
buttons to preset the station.

Preset a station

Press "Confirm

395

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Press Radio Media to display the
primary page.

Press the "OPTIONS

" button to go to

the secondary page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "Radio settings

Select "General

Select "Announcements

Activate/deactivate "Station follow".

Activate / Deactivate "Display radio
text

Activate / Deactivate "Traffic
announcement

Activate/ Deactivate RDS

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies. However,
in certain conditions, coverage of an RDS
station may not be assured throughout the
entire country as radio stations do not cover
100 % of the territory. This explains the loss
of reception of the station during a journey.

Press "Confirm

The "radiotext" function allows
information transmitted by the radio
station and related to the station or the
song playing to be displayed.

Display text information

Play TA messages

The TA (Traffic Announcement)
function gives priority to TA alert
messages. To operate, this function
needs good reception of a radio station
that carries this type of message. While
traffic information is being broadcast,
the current media is automatically
interrupted so that the TA message can
be heard. Normal play of the media
previously playing is resumed at the
end of the message.

396

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Display of options:
if active but not available,
the display will be greyed
out.
if active and available, the
display will be clear.

Display "Radiotext" for the
current station.

Switch between the page with the presets and the page
with the frequencies.

Change of band.

Display of the name of the current station
and "multiplex" being listened to, also
called an "ensemble".

Display of the list of radio
stations.

Next "multiplex".
Next radio station.

Secondary page.

Select audio source.

Previous "Multiplex".
Previous radio station.

DAB radio (Digital Audio Broadcasting)

Terrestrial Digital Radio

If the current "DAB" station is not available on
"FM" the "DAB/FM" option is greyed out.

397

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Select the audio source.

Press Radio Media to display the
primary page.

Press "Band" to select the "DAB"
waveband.

Press Radio Media to display the
primary page.

Press the "OPTIONS

" button to go to

the secondary page.

DAB / FM auto tracking

Digital radio

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
"DAB/FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station
(if there is one).

If "DAB / FM auto tracking" is activated,
there is a difference of a few seconds
when the system switches to "FM"
analogue radio with sometimes a
variation in volume.
Once the digital signal is restored,
the system automatically changes back
to "DAB".

Digital radio provides higher quality
reception.
The different multiplexes offer a
choice of radio stations arranged in
alphabetical order.

If the "DAB" station being listened to
is not available on "FM" ("DAB/FM"
option greyed out), or "DAB/FM auto
tracking" is not activated, the sound
will cut out while the digital signal is too
weak.

Select "Radio settings

Select "General

Activate / Deactivate "Station
follow

Press "Confirm

398

Audio and Telematics

Jumpy_en_Chap10b_NAC-1_ed01-2016

Media

USB player

Selecting the source

Select "Source

Press Radio Media to display the
primary page.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or connection of a USB
memory stick. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Insert the USB memory stick into the USB port
or connect the USB device to the USB port
using a suitable cable (not supplied).

Auxiliary (AUX) socket

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

This source is only available if "Auxiliary input"
has been checked in the audio settings.

Connect the portable device (MP3 player…) to
the auxiliary Jack socket using an audio cable
(not supplied).

Choose the source.

Bluetooth

audio streaming

Streaming allows you to listen to music from
your telephone.
The Bluetooth profile must be activated. First
adjust the volume on your portable device (to a
high level).
Then adjust the volume of your audio system.

If play does not start automatically, it may be
necessary to start the audio playback from the
telephone.
Control is from the portable device or by using
the audio system buttons.

Once connected in streaming mode,
the telephone is considered to be a
media source.

Content .. 23 24 25 26 ..
