Citroen C-Crosser (2012 year). Instruction

III

A C C E S S

DOORS

From outside
) After unlocking the vehicle using the

remote control or the key, pull the

door handle.

From inside

) Pull the front or rear door control to

open the door.

The front passenger door or the rear

doors must fi rst be unlocked manually

using the locking control before being

opened.

Closing

If a door is not closed correctly,

this warning lamp comes on

in the instrument panel screen

until the door concerned is

closed.

Manual centralised control

System which provides full manual

locking or unlocking of the doors and

tailgate from the inside.

Locking
) Press the front of button A to lock

the vehicle.

If the driver's door is open when you

operate the central locking from in-

side, all of the doors lock with the ex-

ception of the driver's door.

Unlocking
) Press the rear of button A to unlock

the vehicle.

Opening

If the doors are locked, opening the

driver's door does not unlock the

other doors.

III

A C C E S S

Opening

) After unlocking the vehicle using the

remote control or the key, press the

handle A and raise the tailgate.

TAILGATE

Closing

) Pull the handle

B downwards to

guide the tailgate,

) release the handle and press the ex-

terior surface of the tailgate gently to

close it.

Emergency control

System which locks or unlocks mechan-

ically the driver's door only in the event

of a malfunction of the central locking.

Locking the driver's door
) Insert the key in the lock, then turn it

to the left.

Unlocking the driver's door
) Insert the key in the lock, then turn it

to the right.

Unlocking the front and rear doors

(from inside)
) Tilt the interior control B rearwards.

Using the key

Locking the front passenger door

and the rear doors (from inside)
) Tilt the interior control B forwards.

The other doors are not unlocked.

III

"Tailgate open" warning

This warning lamp comes on on

the instrument panel screen when

the tailgate is not closed correctly.

LOWER TAILGATE

Opening

) Push the handle C to the right and

tilt the tailgate D gently.

Closing

) Raise the tailgate D , push it to close

it, then check that it is secured

correctly.

Before opening the tailgate, ensure

that no one is within the radius of

opening.
For reasons of safety and correct op-

eration, do not drive with the tailgate

open.
If the battery is disconnected, the

tailgate cannot be opened.
Do not climb onto the lower tailgate

and do not subject it to heavy knocks,

it may be damaged.
Always close the lower tailgate and

check that it is secured correctly be-

fore closing the main tailgate.
When closing the lower tailgate, en-

sure that no person or object is in the

proximity of the moving parts to avoid

any risk of injury or damage.
Do not open the lower tailgate when

a towbar is fi tted.

Maximum authorised weight on the

lower tailgate when open: 200 kg .

Tailgate release

This enables the tailgate to be unlocked

in the event of a central locking fault.

Fold back the rear seats to gain ac-

cess to the tailgate release from in-

side the boot.

- Remove the plastic cap from the

opening

A in the tailgate interior

pillar.

- Move the control B to the right to

unlock and open the tailgate.

III

A C C E S S

SUNROOF

Complete closing
) With the ignition on, push the con-

trol forwards (in the direction 2 ).

The defl ector folds down gradually on

closing.

Complete opening
) With the ignition on, push the con-

trol rearwards (in the direction 1 ).

A defl ector is deployed gradually on open-

ing to prevent unwanted gusts of air.

Temporary stop
) To stop opening or closing, press

part 3 of the control or push the con-

trol in the opposite direction.

Partial opening
) To open , with the ignition on, press

part 3 of the control.

The rear part of the sunroof opens.
) To close , with the ignition on, press

part 3 of the control.

The rear part of the sunroof closes.

Safety anti-pinch and reinitialisation
If the roof meets an obstacle while it is

closing, it stops and opens again.

The sunroof stops automatically just

before complete opening. Push the

control again for complete opening.

Operation

In the event of unwanted opening of

the roof on closing (for example, in

the presence of ice) and immediately

after the roof has stopped, or after

the safety anti-pinch has been trig-

gered fi ve times in succession:
) press part 3 of the control several

times to partially open the roof,

) when the roof partially opens,

continue to press for more than

3 seconds ,

) open and close the sunroof com-

pletely.

The safety anti - pinch function is not

operational during t hese operations.

III

A C C E S S

BLIND

The blind is manual, slide it backwards

and forwards.
It opens automatically when the roof is

opened.

Check that the sunroof is not

open in tilt mode before clos-

ing the blind.

The blind cannot be closed when the

sunroof is open in sliding mode .

Always remove the key from the

ignition when leaving the vehi-

cle, even for a short time.

If the roof meets an obstacle dur-

ing operation, you must reverse the

movement of the roof. To do this,

press the control concerned.
When the driver operates the roof

control, they must ensure that no

one is preventing the roof from clos-

ing correctly.
The driver must ensure that passen-

gers use the sunroof correctly.
Be aware of children when operating

the roof.

III

A C C E S S

FUEL TANK

Opening the cap may cause an inrush

of air. This vacuum, which is completely

normal, is caused by the sealing of the

fuel system.
To fi ll the tank safely:
) the engine must be switched off,
) pull the control A located at the bot-

tom right of the driver’s seat to re-

lease the fuel fi ller fl ap,

) open the fuel fi ller fl ap B ,
) turn the fi ller cap C to the left,

When you have fi lled the tank:
) refi t the fi ller cap, inserting the up-

per part fi rst,

  )   screw in the fi ller cap to the right,
  )  close the fl ap.
Ensure that the fuel fi ller  fl ap is closed

correctly.

) remove the fi ller cap C ,
) fi ll the tank, but do not continue af-

ter the 3rd cut-off of the nozzle ;

this could cause malfunctions.

Low fuel level

Filling

A label, affi xed on the inside of the fl ap,

reminds you of the type of fuel to be

used according to your engine.
More than 5 litres of fuel must be add-

ed in order to be registered by the fuel

gauge.

When the low fuel level is

reached, this indication ap-

pears on the instrument

panel screen. When it fi rst

comes on, approximately

10 litres of fuel remain.

The symbol

fl ashes slowly (approxi-

mately once per second).

When the symbol begins to

fl ash rapidly (approximately

twice per second), there is not

much fuel remaining in your tank (ap-

proximately 5 litres).
You must fi ll the tank to avoid running

out of fuel.

This symbol indicates that the

fuel tank cap is located on the

left-hand side of the vehicle.

Location of the cap

1. Opening.
2. Closing.

Capacity of the tank: approximately

60 litres.

III

A C C E S S

Quality of the fuel used for

Diesel engines

The Diesel engines are perfectly com-

patible with biofuels which conform to

current and future European standards

(Diesel fuel which complies with stan-

dard EN 590 mixed with a biofuel which

complies with standard EN

14214)

available at the pumps (containing up

to 7 % Fatty Acid Methyl Ester).
The B30 biofuel can be used in cer-

tain Diesel engines; however, this use

is subject to strict application of the

special servicing conditions. Contact a

CITROËN dealer or a qualifi ed work-

shop.
The use of any other type of (bio)fuel

(vegetable or animal oils, pure or dilut-

ed, domestic fuel...) is strictly prohibited

(risk of damage to the engine and fuel

system).

petrol engines

The petrol engines are perfectly compat-

ible with E10 or E24 type petrol biofuels

(containing 10 % or 24 % ethanol), con-

forming to European standards EN 228

and EN 15376.
E85 type fuels (containing up to 85 %

ethanol) are reserved exclusively for ve-

hicles marketed for the use of this type

of fuel (BioFlex vehicles). The quality of

the ethanol must comply with European

standard EN 15293.
For Brazil only, special vehicles are

marketed to run on fuels containing up

to 100 % ethanol (E100 type).

V I S I B I L I T Y

LIGHTING STALK

Additional lighting

Other lamps are installed to fulfi l the re-

quirements of particular driving conditions:
-

rear foglamps to be seen from a distance,

front foglamps for even better visibility,

- daytime running lamps to be seen

during the day.

Certain functions of the lighting stalk

(automatic illumination of headlam-

ps, sensitivity) can be confi gured

via the colour screen "Equipment"

menu.

Manual controls

The lighting is controlled directly by the

driver by means of the ring A and the

stalk B .

Lamps off.

Automatic illumination of head-

lamps.

Sidelamps.

B. Stalk for switching headlamps: pull

the stalk towards you to switch the

lighting between dipped and main

beam headlamps.

In the lamps off and sidelamps modes,

the driver can switch on the main beam

headlamps temporarily ("headlamp

fl ash") by maintaining a pull on the

stalk.

Displays

Illumination of the corresponding indica-

tor lamp in the instrument panel confi rms

that the lighting selected is on.

A. Main lighting mode selection ring:

turn it to position the symbol re-

quired facing the mark.

Dipped headlamps or main

beam headlamps.

Main lighting

The various front and rear lamps of the

vehicle are designed to adapt the driv-

er's visibility progressively in relation to

the climatic conditions:
-

sidelamps, to be seen,

- dipped beam headlamps to see

without dazzling other drivers,

main beam headlamps to see clearly

when the road is clear.

V I S I B I L I T Y

Front and rear foglamps

C. foglamps selection ring.
The foglamps operate with the dipped

and main beam headlamps.

front and rear foglamps

) To switch on the front foglamps, turn

the ring C forwards once.

) To switch on the rear foglamps, turn

the ring C forwards twice.

) To switch off the rear foglamps, turn

the ring C rearwards once.

) To switch off the front foglamps, turn

the ring C rearwards twice.

The ring C returns to its initial position

automatically.
The front foglamps are switched on au-

tomatically when you switch on the rear

foglamps.
The rear foglamps are switched off

automatically when you switch off the

dipped/main beam headlamps or the

front foglamps.
On vehicles fi tted with daytime run-

ning lamps, the rear foglamps can be

switched on even if the lighting stalk is

in the "OFF" position.

In good or rainy weather, both

day and night, the front fo-

glamps and the rear foglamps

are prohibited. In these situations,

the power of their beams may dazzle

other drivers.
Do not forget to switch off the front fo-

glamps and the rear foglamps when

they are no longer necessary.

Lighting on reminder
An audible signal when the driver's door

is opened warns the driver if the vehicle

lighting is on, with the ignition off.
Switching off the lighting stops the

audible signal.

If condensation is present, switch the

headlamps on for a few minutes in

order to clear it.

V I S I B I L I T Y

Automatic illumination of headlamps

Daytime running lamps *

* According to country.

Automatic switching off

When the lights stalk is at "dipped head-

lamps or main beam headlamps", if the

ignition switch is at "LOCK" or "ACC" or

if the key has been removed from the

ignition switch, the lights switch off auto-

matically

when the driver's door is

opened .

On vehicles which are equipped with day-

time running lamps, the dipped beam head-

lamps come on when the vehicle is started.

This warning lamp comes on

in the instrument panel.

The instruments and controls (instrument

panel, multifunction screen, air condition-

ing control panel, ...) are illuminated.

The sidelamps and the dipped beam

headlamps come on automatically, with-

out any action on the part of the driver,

if a low level of exterior light is detected

or if the wipers are switched on.
When the light returns to a suffi cient

level or the wipers are switched off, the

lighting is switched off automatically.
The sensor is located at the base of the

windscreen.
Contact a CITROËN dealer or a qualifi ed work-

shop to adjust the sensitivity of the sensor.

In foggy weather or in snow, the

sunshine sensor may detect suf-

fi cient light. The lighting will not

come on automatically.

Do not cover the sunshine sensor, the

associated functions will no longer be

controlled.

The sensitivity of the automatic illumina-

tion of headlamps can be confi gured via

the colour screen "Equipment" menu.

V I S I B I L I T Y

MANUAL HEADLAMP
ADJUSTMENT

To avoid dazzling other road users,

the height of the headlamps must be

adjusted in relation to the load in the

vehicle.

AUTOMATIC HEADLAMP
ADJUSTMENT

On vehicles with xenon bulbs:

when

stationary , the system automatically

corrects the height of the beam, what-

ever the load of the vehicle. The driv-

er is then assured of having optimum

lighting and not causing a nuisance to

other road users.

In cases of malfunction ,

this message appears in

the multifunction screen.

7-seat version

0. Driver only or Driver + 1 passenger

in the front.

1 or 2. Driver + 1 passenger in the front

+ 2 passengers on the third

bench seat.

3. 7 occupants (including the driver

with or without maximum authorised

load).

4. Driver + maximum authorised load.

5-seat version

Driver only or Driver + 1 passenger

in the front.

1 or 2. 5 occupants (including the driver).
3.

5 occupants (including the driver) +

maximum authorised load.

Driver + maximum authorised load.

Do not touch the xenon bulbs. Contact

a CITROËN dealer or a qualifi ed work-

shop.

V I S I B I L I T Y

WIPER CONTROLS

Manual controls

The wiper commands are issued direct-

ly by the driver by means of the stalk A

and the ring B .

single wipe.

Windscreen wipers
A.

wiping speed selection stalk:

park.

intermittent (the speed can be

set manually),

slow.

fast.

B. intermittent operation or rain sensor

sensitivity adjustment ring.

You can increase or decrease:
● the wiping frequency when the in-

termittent mode is active,

● the sensitivity of the rain sensor

when the automatic mode is active.

- "+": high sensitivity.
- "-": low sensitivity.

Headlamp wash

Press the end of the lighting stalk to

activate the headlamp wash, when the

dipped beam headlamps are on.

Programming
An automatic control mode is also avail-

able, the automatic rain sensitive wind-

screen wipers.

Windscreen wash
Pull the wiper stalk towards you. The wind-

screen wash then the wipers operate for a

set time.
The headlamp wash is also activated if

the dipped beam headlamps are on .

Certain windscreen wiper func-

tions (intermittent operation, ...) can

be confi gured via the colour screen

"Equipment" menu.

Model with intermittent wiping

Model with AUTO wiping

automatic rain sensitive wipers

(the speed can be set manually).

V I S I B I L I T Y

B. rear wiper selection ring:

park.

intermittent wipe.

wipe with screen wash.

Rear wiper

The wiper wipes twice then switches to

intermittent mode with an interval of a

few seconds.

Keep the ring in this position to operate

the screen wash with several wipes of

the wiper.

The intermittence of the rear wip-

er can be confi gured via the colour

screen "Equipment" menu.

Automatic rain sensitive wipers

The windscreen wipers operate auto-

matically, without any action on the part

of the driver, if rain is detected (sensor

behind the rear view mirror), adapting

their speed to the intensity of the rain-

fall.

Activation
) Move the stalk A to the "AUTO" po-

sition.

A message appears on the multifunction

screen.

Deactivation
) Move the stalk A to the "OFF" posi-

tion.

A message appears on the multifunction

screen.

Operating fault
Do not cover the rain sensor, linked

with the sunshine sensor and located in

the centre of the windscreen behind the

rear view mirror.

Switch off the automatic rain

sensitive wipers when using an

automatic car wash.

To protect the rubber of the wiper, it is

advisable to deactivate the automatic

mode when the vehicle is parked and

when the ambient temperature is be-

low 0 ° C.
In winter, it is advisable to wait until

the windscreen is completely clear

of ice before activating the automatic

rain sensitive wipers.

V I S I B I L I T Y

COURTESY LAMPS

Front courtesy lamp

Map reading lamps

There are two map reading lamps, one

on each side of the courtesy lamp.
Press the corresponding lamp lens A .

Position 1
The courtesy lamp comes on when a

door or the tailgate is opened.
When the door or the tailgate is closed

again, the lighting gradually dims for a

few seconds before switching off.
However, the courtesy lamp is switched

off automatically in the following cases:
- When the doors and the tailgate

are closed and the ignition switch is

placed in the "ON" position.

When the doors and the tailgate are

closed and you lock the vehicle from

inside or using the remote control.

Position 2
The courtesy lamp is off, regardless of wheth-

er the doors or tailgate are open or closed.

The durations of lighting of the front

courtesy lamps can be confi gured

via the colour screen "Equipment"

menu.

V I S I B I L I T Y

Position 1 "ON"
The courtesy lamp is permanently on.

Position 2 "●"
The courtesy lamp comes on when a

door or the tailgate is opened. When

the door or the tailgate is closed again,

the lighting gradually dims for a few

seconds before switching off.
However, the courtesy lamp is switched

off immediately in the following cases:
- When the doors and the tailgate

are closed and the ignition switch is

placed in the "ON" position.

When the doors and the tailgate are

closed and you lock the vehicle from

inside or using the remote control.

Position 1 "ON"
The boot lamp is on, regardless of

whether the tailgate is open or closed.

Position 2 "●"
The boot lamp comes on if the tailgate

is opened and switches off when the

tailgate is closed.

Position 3 "OFF"
The courtesy lamp is permanently off.

Boot lamp

Position 3 "OFF"
The boot lamp is off, regardless of

whether the tailgate is open or closed.

Courtesy lamps automatic

switch off

To prevent discharging of the battery,

the courtesy lamps, map reading lamps

and boot lamp switch off automatically

after 30 minutes.
The courtesy lamps are switched on

again if the ignition switch is placed

in the "ON" or "ACC" position, if you

open then close a door or the tailgate or

if you use the remote control.

The duration of lighting of the rear

courtesy lamps can be confi gured

via the colour screen "Equipment"

menu.

Rear courtesy lamp

C H I L D S A F E T Y

"Rearwards-facing"

"Forwards-facing"

* The rules for carrying children are

specifi c to each country. Refer to the

current legislation in your country.

GENERAL POINTS RELATING
TO CHILD SEATS

Intermediate longitudinal position

CITROËN recommends that children

should travel in the rear seats of your ve-

hicle:
-

"rearwards-facing" up to the age of 2,

"forwards-facing" over the age of 2.

When a "rearwards-facing" child

seat is installed on the

front

passenger seat , it is essential

that the passenger airbag is deacti-

vated. Otherwise,

the child would

risk being seriously injured or

killed if the airbag were to infl ate .

CHILD SEAT IN THE FRONT

When a "forwards-facing" child seat is

installed on the front passenger seat ,

adjust the vehicle's seat to the interme-

diate longitudinal position with the seat

back upright and leave the passenger

airbag activated.

Although one of CITROËN's main cri-

teria when designing your vehicle, the

safety of your children also depends on

you.

For maximum safety, please observe

the following recommendations:
- in accordance with European reg-

ulations,

all children under the

age of 12 or less than one and a

half metres tall must travel in ap-

proved child seats suited to their

weight , on seats fi tted with a seat

belt or ISOFIX mountings * ,

statistically, the safest seats in

your vehicle for carrying children

are the rear seats,

a child weighing less than 9 kg

must travel in the "rearwards-

facing" position both in the front

and in the rear.

Citroen C-Crosser (2012 year). Instruction - part 6
