(12) Install 2/4 Accumulator components as shown
in (Fig. 363).
(13) Torque 2/4 Accumulator retainer to 5 N·m (45
in. lbs.) (Fig. 364).
(14) Install
Manual
Shaft/Rooster
Comb
and
Transmission Range Sensor (Fig. 365).
(15) Make sure Manual Valve control pin is con-
tained within the rooster comb slot (Fig. 366). Install
Transmission Range Sensor retaining screw (Fig.
366) and torque to 5 N·m (45 in. lbs.).
Fig. 363 2/4 Accumulator Assembly
1 - VALVE BODY
2 - RETAINER PLATE
3 - DETENT SPRING
4 - RETURN SPRINGS
5 - PISTON
Fig. 364 2/4 Accumulator Retaining Plate
1 - 2–4 ACCUMULATOR RETAINING PLATE
2 - DETENT SPRING
Fig. 365 Install Manual Shaft/Rooster Comb and
Transmission Range Sensor
1 - TRANSMISSION RANGE SENSOR
2 - MANUAL SHAFT
3 - ROOSTER COMB
Fig. 366 Install Transmission Range Sensor
Retaining Screw
1 - TRANSMISSION RANGE SENSOR
2 - MANUAL VALVE CONTROL PIN
3 - RETAINING SCREW
JR
40TE AUTOMATIC TRANSAXLE
21 - 193
VALVE BODY (Continued)
