TEST 16A

REPAIRING

(

RECLINER SENSOR OUT OF RANGE LOW

(

TROUBLE CODE

Perform TEST 1A Before Proceeding

FIG. 1

M

E

M

O

R

Y

S
Y
S

T

E

M

466

TEST 16A

REPAIRING

(

RECLINER SENSOR OUT OF RANGE LOW

(

TROUBLE CODE

Perform TEST 1A Before Proceeding

*Perform Verification TEST VER-4A.

**Check connectors - Clean / repair as necessary.

NOTE: FOR LOCATION
OF ALL COMPONENTS

START TEST 16A.

SEE GENERAL INFO 4.0

USING THE DRB

DISCONNECT THE

SELECT "BODY"

MHSMM "C1" HARNESS

"MEMORY SEAT

CONNECTOR.** MODULE" AND

"SENSORS".

READ THE RECLINER

IS THE VOLTAGE

NO

REPLACE THE MEMORY

POSITION SENSOR

BELOW 0.6 VOLTS?

HEATED SEAT/MIRROR

VOLTAGE.

MODULE.*

YES

DISCONNECT THE

USING AN OHMMETER,

REPAIR THE

RECLINER POSITION

MEASURE THE RECLINER

IS THE RESISTANCE

YES

RECLINER POSITION

SENSOR HARNESS

POSITION SIGNAL CKT

BELOW 1000 (1K)

SIGNAL CKT FOR A

CONNECTOR.**

(CAV B) TO GROUND.

OHMS?

SHORT TO GROUND.*

FIG. 1

NO

REPLACE THE TRACK
ASSEMBLY (RECLINER
MOTOR DEFECTIVE).*

M

E

M

O

R

Y

S
Y
S

T

E

M

467

TEST 17A

REPAIRING

(

RECLINER SENSOR OUT OF RANGE HIGH

(

TROUBLE CODE

Perform TEST 1A Before Proceeding

FIG. 1

M

E

M

O

R

Y

S
Y
S

T

E

M

468

TEST 17A

REPAIRING

(

RECLINER SENSOR OUT OF RANGE HIGH

(

TROUBLE CODE

Perform TEST 1A Before Proceeding

*Perform Verification TEST VER-4A.

**Check connectors - Clean / repair as necessary.

NOTE: FOR LOCATION
OF ALL COMPONENTS

START TEST 17A.

SEE GENERAL INFO 4.0

USING THE DRB

DISCONNECT THE

SELECT "BODY"

MHSMM "C1" HARNESS

"MEMORY SEAT

CONNECTOR.** MODULE" AND

"SENSORS".

READ THE RECLINER

IS THE VOLTAGE

NO

REPLACE THE MEMORY

POSITION SENSOR

ABOVE 4.8 VOLTS?

HEATED SEAT/MIRROR

VOLTAGE.

MODULE.*

YES

DISCONNECT THE

USING A VOLTMETER,

REPAIR THE

RECLINER POSITION

MEASURE THE RECLINER

IS THE VOLTAGE

YES

RECLINER POSITION

SENSOR HARNESS

POSITION SIGNAL CKT

ABOVE 0.2 VOLTS?

SIGNAL CKT FOR A

CONNECTOR.**

(CAV B) TO GROUND.

SHORT TO VOLTAGE.*

FIG. 1

NO

REPLACE THE TRACK
ASSEMBLY (RECLINER
MOTOR DEFECTIVE).*

M

E

M

O

R

Y

S
Y
S

T

E

M
