5. CHECK THE (R15) LEFT SIDE IMPACT SENSOR 1 GROUND CIRCUIT FOR AN OPEN OR HIGH Connect the 8443 Load Tool ORC Adaptor to the Occupant Control Measure the resistance of the (R15) Left Side Impact Sensor 1 Ground Is the resistance below 1 ohm? Yes >> Go To 6 No >> Repair the (R15) Left Side Impact Sensor 1 Ground circuit for an open or high resistance. Perform the ORC VERIFICATION TEST - VER 1. 6. CHECK THE (R13) LEFT SIDE IMPACT SENSOR 1 CIRCUIT FOR AN OPEN OR HIGH RESISTANCE Measure the resistance of the (R13) Left Side Impact Sensor 1 Signal Is the resistance below 1 ohm? Yes >> Go To 7 No >> Repair the (R13) Left Side Impact Sensor 1 Signal circuit for an open or high resistance. Perform the ORC VERIFICATION TEST - VER 1. 8O - 154 RESTRAINTS - ELECTRICAL DIAGNOSTICS LX |
