Chrysler 300/300 Touring/300C, Dodge Magnum. Manual - part 2052

Drive

-

Direct

Gear

EMCC

21 - 742

AUTOMATIC TRANSMISSION 42RLE - SERVICE INFORMATION

LX

Drive

-

Fourth

Gear

(Overdrive)

LX

AUTOMATIC TRANSMISSION 42RLE - SERVICE INFORMATION

21 - 743

Drive

-

Fourth

Gear

(Overdrive)

EMCC

21 - 744

AUTOMATIC TRANSMISSION 42RLE - SERVICE INFORMATION

LX

SPECIFICATIONS

42RLE AUTOMATIC TRANSMISSION

GENERAL SPECIFICATIONS

Transmission Type

Four-Speed Automatic, Electronically Controlled, Fully

Adaptive, Electronically Modulated Torque Converter

Lubrication Method

Pump (internal - external gear-type)

Cooling Method

Water Heat Exchanger and/or Air-to-Oil Heat Exchanger

GEAR RATIOS

1st Gear

2.84:1

2nd Gear

1.57:1

3rd Gear (Direct)

1.00:1

4th Gear (Overdrive)

0.69:1

Reverse Gear

2.21:1

BEARING PRELOAD (Drag Torque)

Description

Metric

Standard

Output Shaft

0.22-0.903 N·m

1-8 in. lbs.

CLUTCH PACK

Description

Metric

Standard

Low/Reverse Clutch (Select

Reaction Plate)

0.84-1.60 mm

0.033-0.063 in.

Two/Four Clutch (No Select)

0.76-2.64 mm

0.030-0.104 in.

Reverse Clutch (Select Snap Ring)

0.89-1.37 mm

0.035-0.054 in.

Overdrive Clutch (No Select)

1.07-3.25 mm

0.042-0.128 in.

Underdrive Clutch (Select Reaction

Plate)

0.94-1.50 mm

0.037-0.059 in.

INPUT SHAFT

Description

Metric

Standard

End Play

0.127-0.635 mm

0.005-0.025 in.

OIL PUMP CLEARANCES

DESCRIPTION

METRIC

STANDARD

Outer Gear-to-Crescent

0.060-0.298 mm

0.0023-0.0117 in.

Inner Gear-to-Crescent

0.093-0.385 mm

0.0036-0.0151 in.

Outer Gear-to-Pocket

0.089-0.202 mm

0.0035-0.0079 in.

Outer Gear Side Clearance

0.020-0.046 mm

0.0008-0.0018 in.

Inner Gear Side Clearance

0.020-0.046 mm

0.0008-0.0018 in.

LX

AUTOMATIC TRANSMISSION 42RLE - SERVICE INFORMATION

21 - 745
