Fig. 2: Sensors (JL4)
Courtesy of GENERAL MOTORS CORP.
2008 Chevrolet Silverado 1500
2008 BRAKES Antilock Brake System - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 3: JF3/JF7
Courtesy of GENERAL MOTORS CORP.
2008 Chevrolet Silverado 1500
2008 BRAKES Antilock Brake System - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 4: JH6/JH7
Courtesy of GENERAL MOTORS CORP.
DIAGNOSTIC INFORMATION AND PROCEDURES
DIAGNOSTIC CODE INDEX
DIAGNOSTIC CODE INDEX
DTC
Description
DTC C0035 or C0040
(With JL4)
C0035 00: Left Front Wheel Speed Sensor Circuit
C0035 5A: Left Front Wheel Speed Sensor Circuit Plausibility
Failure
C0040 00: Right Front Wheel Speed Sensor Circuit
C0040 5A: Right Front Wheel Speed Sensor Circuit
Plausibility Failure
DTC C0035 or C0040
(With JF3/JF7 or
JH6/JH7)
C0035 02: Left Front Wheel Speed Sensor Circuit Short to
Ground
C0035 05: Left Front Wheel Speed Sensor Circuit Short to
Battery or Open
2008 Chevrolet Silverado 1500
2008 BRAKES Antilock Brake System - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
C0035 0F: Left Front Wheel Speed Sensor Circuit Erratic
C0035 18: Left Front Wheel Speed Sensor Circuit Signal
Amplitude Below Minimum
C0040 02: Right Front Wheel Speed Sensor Circuit Short to
Ground
C0040 05: Right Front Wheel Speed Sensor Circuit Short to
Battery or Open
C0040 0F: Right Front Wheel Speed Sensor Circuit Erratic
C0040 18: Right Front Wheel Speed Sensor Circuit Signal
Amplitude Below Minimum
DTC C0045 or C0050
(With JL4)
C0045 00: Left Rear Wheel Speed Sensor Circuit
C0045 5A: Left Rear Wheel Speed Sensor Circuit Erratic
Signal
C0050 00: Right Rear Wheel Speed Sensor Circuit
C0050 5A: Right Rear Wheel Speed Sensor Circuit Erratic
Signal
DTC C0055 or P0609
(With JF3 or JH6)
C0055 00: Rear Wheel Speed Sensor Circuit
C0055 5A: Rear Wheel Speed Sensor Plausibility Failure
DTC C0110
C0110 00: Pump Motor Circuit
C0110 03: Pump Motor Circuit Voltage Below Threshold
C0110 04: Pump Motor Open Circuit
C0110 61: Pump Motor Circuit Actuator Stuck
DTC C0131
C0131 00: ABS/TCS System Pressure Circuit Malfunction
C0131 3A: ABS/TCS Pressure Sensor Incorrect Component
Installed
C0131 5A: ABS/TCS Pressure Circuit Plausibility Failure
C0131 01: ABS Pressure Circuit Short to Battery
C0131 03: ABS/TCS Pressure Circuit Voltage Below
Threshold
C0131 06: ABS/TCS Pressure Circuit Short to Ground or
Open
C0131 55: ABS/TCS Pressure Sensor Expected Number of
Transitions or Events not Reached
C0131 0F: ABS/TCS Pressure Sensor Erratic
C0131 4B: ABS/TCS Pressure Sensor Calibration not Learned
DTC C0161
C0161 00: ABS/TCS Brake Switch Circuit
C0161 5A: ABS/TCS Brake Switch Plausibility Failure
DTC C0186
C0186 00: Lateral Accelerometer Circuit
C0186 5A: Lateral Accelerometer Circuit Plausibility Failure
