Fig. 106: View Of Engine Front Cover 4. Install the engine front cover. 5. Install the engine front cover bolts. Tighten: Tighten the engine front cover bolts to 25 N.m (18 lb ft). NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 107: View Of CKP Sensor & Bolt 6. Install a new O-ring to the crankshaft position sensor spacer. 7. Lubricate the O-ring with engine oil. 8. Install the crankshaft position sensor spacer. 9. Install the crankshaft position sensor spacer bolts. Tighten: Tighten the crankshaft position sensor spacer bolts to 10 N.m (89 lb in). 10. Install a new O-ring to the crankshaft position sensor. 11. Lubricate the O-ring with engine oil. 12. Install the crankshaft position sensor.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
13. Install the crankshaft position sensor bolt. Tighten: Tighten the crankshaft position sensor bolt to 10 N.m (89 lb in). CRANKSHAFT FRONT OIL SEAL INSTALLATION Tools Required J 44645 Crankshaft Front Oil Seal Installer. See Special Tools . Installation Fig. 108: Pressing Crankshaft Front Oil Seal On Using J 44645
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Courtesy of GENERAL MOTORS CORP. 1. Lubricate the crankshaft sealing surface with engine oil. 2. Place the crankshaft front oil seal onto the crankshaft. 3. Install the J 44645 to the crankshaft. See Special Tools . 4. Press the crankshaft front oil seal onto the crankshaft with the J 44645 until the tool bottoms out. See Special Tools . 5. Remove the J 44645 . See Special Tools . OIL FILTER ADAPTER AND OIL COOLER ASSEMBLY INSTALLATION Fig. 109: Oil Cooler
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
|
|
