Fig. 139: View Of Oil Filter Adapter/Oil Cooler
Courtesy of GENERAL MOTORS CORP.
3. Remove the five oil filter adapter and oil cooler assembly bolts.
4. Remove the oil filter adapter and oil cooler assembly.
CRANKSHAFT FRONT OIL SEAL REMOVAL
Tools Required
J 44644 Crankshaft Front Oil Seal Remover. See Special Tools .
Removal
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 140: Removing Crankshaft Front Oil Seal Using J 44644
Courtesy of GENERAL MOTORS CORP.
1. Install the J 44644 to the crankshaft front oil seal. See Special Tools .
2. Remove crankshaft front oil seal using J 44644 . See Special Tools .
ENGINE FRONT COVER REMOVAL
Tools Required
J 37228 Seal Cutter. See Special Tools .
Removal
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 141: View Of CKP Sensor & Bolt
Courtesy of GENERAL MOTORS CORP.
1. Remove the crankshaft position sensor bolt.
2. Remove the crankshaft position sensor.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 142: View Of Engine Front Cover
Courtesy of GENERAL MOTORS CORP.
3. Remove the engine front cover bolts.
4. Separate the engine front cover from the cylinder block using J 37228 . See Special Tools .
5. Remove the engine front cover.
OIL PUMP SUCTION PIPE AND SCREEN ASSEMBLY REMOVAL
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
