Fig. 59: View Of Crankshaft Position Sensor Electrical Connector
Courtesy of GENERAL MOTORS CORP.
9. Disconnect the crankshaft postion sensor electrical connector.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 60: View Of Fuel Pressure Control Valve Electrical Connector
Courtesy of GENERAL MOTORS CORP.
10. Disconnect the fuel pressure control valve electrical connector.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 61: View Of Oil Level Sensor Electrical Harness Connector
Courtesy of GENERAL MOTORS CORP.
11. Disconnect the oil level sensor electrical harness connector.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 62: View Of Fuel Temperature Sensor Electrical Connector
Courtesy of GENERAL MOTORS CORP.
12. Disconnect the fuel temperature sensor connector.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
