Fig. 47: View Of Turbocharger Coolant Outlet Hose & Clamps
Courtesy of GENERAL MOTORS CORP.
18. Remove the turbocharger coolant outlet hose and clamps.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 48: View Of Water Pump Inlet Pipe
Courtesy of GENERAL MOTORS CORP.
19. Remove the water pump inlet pipe.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 49: View Of Fuel Pipe Bracket Bolt
Courtesy of GENERAL MOTORS CORP.
20. Remove the fuel pipe bracket bolt.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 50: View Of Thermostat Housing
Courtesy of GENERAL MOTORS CORP.
21. Remove the thermostat housing bolts.
22. Remove the thermostat housing.
ENGINE WIRING HARNESS ASSEMBLY REMOVAL
