Fig. 156: View Of Exhaust Outlet Clamp
Courtesy of GENERAL MOTORS CORP.
28. Loosen the exhaust outlet clamp.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 157: View Of Exhaust Outlet
Courtesy of GENERAL MOTORS CORP.
29. Remove the exhaust outlet.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 158: View Of Right Exhaust Pipe
Courtesy of GENERAL MOTORS CORP.
30. Remove the right exhaust pipe to turbocharger bolts.
31. Remove the right exhaust pipe.
32. Remove and discard the gasket.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 159: View Of Left Exhaust Pipe
Courtesy of GENERAL MOTORS CORP.
33. Remove the left exhaust pipe to turbocharger bolts.
34. Remove the left exhaust pipe.
35. Remove and discard the gasket.
