Chevrolet Silverado / GMC Sierra. Manual - part 2633
Fig. 143: Gear Train Spacer
Courtesy of GENERAL MOTORS CORP.
9. Install the gear train spacer.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 144: Gear Train Adjustment Shims
Courtesy of GENERAL MOTORS CORP.
10. In the gear train housing, temporarily install new shims until the axial play is correct.
Fig. 145: Installing Drive Shaft Bearing Race
Courtesy of GENERAL MOTORS CORP.
11. Using a hammer, install the drive shaft bearing race.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 146: Drive Shaft Adjusting Shims
Courtesy of GENERAL MOTORS CORP.
12. In the drive shaft housing, temporarily install new shims until the axial play is correct.
13. Install the roller cage inside the drive shaft.
MAIN SHAFT ASSEMBLE
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
