Chevrolet Silverado / GMC Sierra. Manual - part 2583
Fig. 246: Applying Gasket Maker
Courtesy of GENERAL MOTORS CORP.
34. Once the axial play is achieved, proceed to the final assembly. Clean the cover surface and
apply gasket maker.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 247: Rear Cover Bolts
Courtesy of GENERAL MOTORS CORP.
35. Apply a Teflon® sealer to the screw threads.
36. Install the screws and tighten.
Tighten: Tighten to 57-68 N.m (42-50 lb ft).
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 248: Main Shaft Nut & Yoke
Courtesy of GENERAL MOTORS CORP.
37. Install the main shaft yoke onto the main shaft.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 249: Main Shaft Nut
Courtesy of GENERAL MOTORS CORP.
38. Tighten the NEW main shaft nut.
Tighten: Tighten the nut to 150-170 N.m (110-125 lb ft).
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
