Chevrolet Silverado / GMC Sierra. Manual - part 2563
Fig. 165: Snap Ring
Courtesy of GENERAL MOTORS CORP.
3. Using locking pliers, position the clutch taper snap ring.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 166: Reverse Synchronizer Ring
Courtesy of GENERAL MOTORS CORP.
4. Install the lubricated reverse gear synchronizer ring.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 167: Roller Cage
Courtesy of GENERAL MOTORS CORP.
5. Install the reverse gear roller cage.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 168: Reverse Gear And Synchronizer
Courtesy of GENERAL MOTORS CORP.
6. Install the reverse gear and synchronizer.
7. Turn the reverse gear and synchronizer in order to seat them into the insert grooves.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
